Skid system lpg with automobile lpg gas dispenser is used for refilling of liquified petrol gas (LPG). As a major equipment of the LPG station, it is equipped with high-accuracy positive displacement flowmeter,microcomputer control, large LCD counter and various control valves and protection devices assuring operation safety.With advanced manufacturing technique, the dispenser has reliable quality and excellent performance with characteristics of precise ration, easy maintainance and centralized control. Each gun connects to an independent flow and metering system which prevents interference.
Skid system lpg with automobile lpg dispenser can fill not only the domestic gas cylinders, but also automobiles, mainly city buses, just to adjust the nozzles.
There are various models available with LPG storage tank capacity ranging from 3000 Liters to 120000 Liters and with the choice of single or double nozzle LPG dispensers.
The unit comes with all safety features as per norms.
The unit is easy to install and operate and much cheaper as compared to other plants.
2.Standard features of skid lpg gas plants as below
1) Minimum Installation Area.
2) Self Filling System.
3) Available for 24hrs.
4) Lowest Installation Cost.
5) Portable System.
3．Technical data
1) Delivered product: LPG
2) Temperature range: -20℃～50℃
3) Design pressure:1.8Mpa
4) Flow rate: depending on the type of pump installed
5) Tension: 380V/50Hz
4. LPG Skid Equipment
1) LPG storage tank
2) LPG pump
3) LPG ball valves
4) other equipments
If you're interested in our skid lpg gas station, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat: +86 13329899995.
Website: www.trucksinchina.com
More pictures of hot sale mobile skid lpg gas refilling station with lpg gas dispenser as below
main technical parameters of hot sale 10m3 skid lpg gas station as below
| 10 CBM LPG TANK DIMENSIONS |
| Volume of Tank |
10,000L |
|
| Filling Weight |
5,000kgs |
|
| Tank Weight |
2950 kg |
|
| Thickness of Shell (mm) |
10mm |
|
| Thickness of Endplate (mm) |
10mm |
|
| Tank Diameter (mm) |
1600 mm |
|
| Tank Dimensions (mm) (length x width x height) |
6000x 1620 x 2910 mm |
|
| External Dimensions (mm) (length x width x height) |
To be designed to be loaded in a 40’container |
|
| Material of Tank |
Carbon Steel Q345R |
|
| Filling Medium |
Liquefied Petroleum Gas ( Propane) |
|
| Design Pressure |
1.77 Mpa |
|
| Corrosion Allowance |
1 mm |
|
| Medium Density |
420-520 kg/ cbm |
|
| Manufacturing Standard: Pressure vessels, Supervision Regulation on Safety Technology for Stationary Pressure Vessels of China. |
|
| Main parts of LPG Tank |
|
| Item |
Specification/ mm
|
|
| Discharge Pipe |
DN50 |
|
| Inflow Pipe |
DN50 |
|
| Outlet |
DN50 |
|
| Gas phase balance pipes |
DN50 |
|
| Manhole |
DN450 |
|
| Drain Hole |
DN50 |
|
| Other accessories: Cut-off Valve, Needle Valve, Safety Valve, Liquid level meter, Pressure gauge, Temperature Gauge. |
|
| LPG Pump & Motor Specification |
| |
Pump Brand |
Chinese brand lpg gas pump |
| Model |
YQB15-5 |
| Medium |
Liquid petroleum gas |
| Working pressure differential |
≤0.5Mpa |
| Inlet pressure |
≤1.0Mpa |
| Flow Speed |
15.5m3/h |
| Applied Power |
5.5kw |
| Inlet & Outlet Flange |
2”NPT / 2" NPT |
| Revolution |
780r/min |
| mass |
166kgs |
| Motor |
Chinese brand |
| Specification |
7.5HP(5.5KW), Explosive Proof,
Dual Frequency 220V to 690V, 50Hz and 60Hz supplies applicable |
| LPG Skid Parts list |
| Item |
Model Number |
Quantity |
| LPG Tank |
10,000L |
1 piece |
| Lpg Pump |
2" inlet & 2" outlet |
1 Piece |
| Explosive-proof Motor |
380V with 220V adapter |
1 Piece |
| Automatic lpg dispenser |
double nozzles, filling automobiles or domestic gas cylinders to adjust nozzles, |
1 |
| Pipes |
/ |
1 Sets |
| Cut-off Valve |
J41N-40 DN50 |
| J41N-40 DN15 |
| Safety Valve |
A42F-25 DN50 |
| Pipe Safety Valve |
A21F-25 DN15 |
| Level Gauge |
Float ball type |
| Discharging pipe |
L=4M DN50/DN25 |
| Shock-absorbing Tube |
L=500mm DN50 |
| Flange |
2.5MPaDN15 |
