Fuel tank truck is also called oil transportation tank truck, fuel truck, fuel tank truck ,oil truck, oil tank truck, oil delivery truck, fuel tanker , oil tanker truck, etc. The oil delivery truck is mainly used to transport oil, fuel, gasoline, diesel, etc. It can be equipped refueling machine and fuel pump to refuel for other automobile.
The shape of the fuel tank is elliptical or rectangular and the material can be high quality carbon steel plate Q235 , stainless steel or aluminium alloy. Whole tank was divided into two compartments or more compartments with several inner baffles to reinforce the tank strength and prevent longitudinal surge during move.
Last month, we received an order of one unit of CLW LHD 5,000L fuel dispensing trucks from client from Africa.
This CLW 4*2 oil dispensing truck is with the shape of ellipse, adopts 4mm high quality GB carbon steel, with four compartments and several anti-wave sheets. And the fuel tanker volume is 3-5cbm, equipped with special carbon steel fuel pump, one manhole, one self-discharging valve at the tanker bottom, one aluminum ally emergency shutoff device, one unit aluminum alloy elevating guardrail, one unit of China-made refueling dispenser and 15m self-return Refueling reel and refueling nozzle, pipeline, ladder, one toolbox, etc.
If you're interested in our CLW brand fuel tanker truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat: +86 13329899995
Website: www.trucksinchina.com
More pictures of hot sale CLW brand 5,000Liters fuel tank truck as below
HOT SALE! CLW 5,000Liters fuel tank truck
high quality and competitive price CLW brand refueler truck for sale
factory sale best price CLW oil dispensing truck
main technical parameters of CLW brand 5,000Liters oil tank truck manufactured by Chengli Special Automobile Co., Ltd. as below
| ⅠVehicle parameters |
| Model and name |
CLW refueler truck |
| Manufacturer |
Chengli Special Automobile Co., Ltd. |
| Overall dimension(L*W*H)mm |
5990*2000*2350 |
Curb weight |
3300kgs |
| Tank volume |
5,000Liters |
Tank material |
Carbon steel Q235 |
| Cab seats |
3 |
Max speed(km/h) |
80 |
| Transmission |
5 forward gear, 1 reverse gear |
Brake system |
Air cut brake |
| Approach/departure angle |
17/12 |
Front/rear suspension(mm) |
1032/1658 |
| Steering type |
Left Hand Drive |
| Cabin |
White(other colors are available). Single row cab can be tippable forwardly, with power steering. Air conditioner is optional. |
| Performance |
A, With multiple baffle plates inside the tank, the tank with the advantages of high intensity, stability, transporting safety, etc.
|
| |
B, oil pump is installed to suck or discharge or, with high suction pressure and speed. |
| |
C, computer refueling machine is installed, with a 15m automatic return oil pipe and refueling nozzle, achieving mobile refueling function. |
| |
D, according to users’ needs, the tank can be designed as a single compartment or several compartments to contain different oils. |
| |
E, according to users’ needs, the side or the rear of the tank canbe installed 1-3 self-flowing valves. |
| Ⅱchassis parameter |
| Chassis model |
EQ1060TJ20D3 |
Brand name |
Dongfeng |
| Driving type |
4*2 |
Wheelbase |
3300mm |
| Front tread(mm) |
1506mm |
Rear tread(mm) |
1466mm |
| Tire specification |
7.00R16 |
Tire nos. |
6 |
| Axle load(kgs) |
2275/4220 |
Axle nos. |
2 |
| Ⅲ engine parameter |
| Engine model |
CY4102-C3F |
| Engine manufacturer |
Chaochai |
|
|
| Engine displacement(ml) |
3856ml |
Engine rated power |
70KW |
| Fuel type |
Diesel |
Emission standard |
Euro Ⅲ |
