Factory customized high quality and lower price JAC 4*2 LHD 5m3 vacuum tank truck for sale, sludge tank truck for sale
Sewage suction truck is mainly used for suction, transportation and discharge of sewage from septic tank and sludge from drains.Widely used by municipal environment and sanitation department and residential management.
And CLW brand sewage suction truck is made up of Imported vacuum pump, power-take off, hydraulic cylidners, control valves, pressure gauge, water-gas separator, oil water separator, level inspection window, suction hose, pipeline system, etc.
As a professional special sewage truck manufacture in China,We Chengli Special Automobile Co., Ltd. can design and manufacture sewage suction trucks from 3000 liter to 16000 liters.
CLW brand septic tank trucks is with self-suction and self-unloding function. The tank can be lifted by hydraulic cylinder to 45° and the rear door of the tank cal also be hydraulically open. So the sewer can be discharged from the tank completely. This is also convenient for you to maintenance and clean the tank.
Overfill system with music horn is equipped to prevent the vacuum pump damage from sewage water into vacuum pump when the tank is full.
Super power of vacuum pump, seamless die casted sheel cover, designing for container with high ability of pressure-resistance, double hydraulic jack system, more strength than the cesspit emptier.
If you're interested in our CLW Brand vacuum tank truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995
Website: www.trucksinchina.com
Basic Equipment of CLW Brand vacuum tank truck manufactured by Chengli Special Automobile Co., Ltd. as below.
Imported vacuum pump, Powe-take-off, hydraulic cylinders, multi-way valve , pressure gauges, water-gas seperator , oil-gas seperator, level inspection window, suction hose
Advantages:
1.Tank can be lifted hydraulically to 40-45 degree.Rear door can be opened&closed hydraulically. With full opening design, discharge can be very quick&complete.
2.Overfill system with music horn is euipped to prevent the vacuum pump damage from sewage water into vacuum pump when the tank is full.
| Chassis |
Chassis make |
JAC |
| model |
HFC1081P91K1C5
|
| Drive type |
4x2 |
| Wheel base (mm) |
3815 |
| Dimension & weight parameter |
Whole vehicle dimension |
6600×2170×2750 |
| Total mass (kg) |
8495 |
| Curb weight (kg) |
4150 |
| Rated payload weight (kg) |
4150 |
| Engine |
Model |
CY4102-C3C |
| Make |
DongFeng Chaoyang Diesel |
| Rated power |
88 kw / 120 hp |
| Displacement |
3856 ml |
| Emission standard |
Euro 2/Euro 3/Euro 4/ Euro 5 |
| Truck performance |
Max speed |
90km/h |
| Track span (front/rear) |
1665/1600 |
| Approach/departure angle (°) |
24/15 |
| Leaf spring number |
9/11+8 |
| Tire type |
8.25-16 |
| Tank performance |
Tank capacity: 6 cbm
Equipped with vacuum pump(rating rotate speed=1400r/m,min rotate speed800r/m, max suction lift6m, vacuum500mmHg, clockwise)
Equipped with power take off, transmission shaft,fecal tank, pipe network, fecal pipe for observing and cleanout equipment
|
More pictures of hot sale customized JAC brand vacuum tank truck manufactured by Chengli Special Automobile Co., Ltd. as below
customized JAC brand 5,000Liters vacuum tank trucks for sale
high quality and competitive price JAC brand sludge tank truck for sale
HOT SALE! JAC brand 5m3 sewage suction truck
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of sewage suction trucks in China since 2004s. With many years'experience in developing, Chengli Special Automobile Co., Ltd. could supply 2cbm-16cbm sludge tank truck, such as dongfeng brand sewage suction truck, ISUZU septic tank truck, FAW vacuum truck, forland sewage suction truck, JMC liquid wastes truck, Yuejin cesspit empiter truck, HOWO vacuum truck, etc. More information, please contact Ms. Anita.
