The high altitude operation truck manufactured by Chengli Special Automobile Co., Ltd. can be designed and produced as 12m, 14m, 16m, 18m, 20m, 22m, 24m, etc. However, for the electronic power industry, the 14m bucket truck is enough. Dongfeng 14m high altitude operation truck is with 4 sets of H shape hydraulic outriggers, which can be elevating at the same time or independently. The outriggers and the working arms are interlocked, avoiding over operation, assuring the safety and reliability when operation. The high altitude operation trucks manufactured by Chengli Special Automobile Co., Ltd. can be operated up-down, choosing to install crane with the max loading capacity of 1,000kg. The working arms of CLW overhead working truck is with 3 sections knuckle boom, 360 degree full rotation, etc.
1. Aerial platform vehicles is also named high-altitude operation truck, refers to the special vehicles for aerial operation with the delivery of staff and the equipment to the scene.
2. We are professional factory, supply Dongfeng aerial vehicles, JMC aerial working vehicles, JAC aerial platform vehicles, Qingling high-altitude working truck, Foton aerial platform operating vehicles, etc., working height of 8-24 meters for choose.
3. Produced by the high-altitude operation vehicles, using double lift hydraulic cylinder, up and down a total of four hydraulic cylinders, the conventional aerial vehicles only two lifting cylinders, double lift hydraulic cylinder in the lift, rotation process does not tremble, do not shake, stability Sex, safety is better.
4. High-altitude operation vehicles using domestic or imported reversing valve and hydraulic cylinder, for the balance, flexible and convenient operation, outrigger and work arm interlocking, outrigger and work arm interlock to prevent misuse over.
5. Installed four hydraulic legs, to ensure vehicle stability and safety in operation.
6. Optional aerial crane hook, hook hanging 1 ton and the electronic control system.
7. Aerial platform vehicles can be up and down operation, 360-degree rotation, install the hand throttle.
8. If you have any special requirements for the aerial vehicles, please let us know, we can design for you.
If you're interested inour aerial working platform truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995
Website: www.trucksinchina.com
Specifications of dongfeng 14-16m3 aerial working platform truck manufactured by Chengli Special Automobile Co., Ltd. as below.
| Item |
Unit |
Specification |
| Product name |
|
CLW5070JGKD4 high-altitude operation truck |
| Chassis model |
|
DFA1080LJ12D3 |
| |
Gross weight |
kg |
7545 |
| Curb weight |
7350 |
| Overall dimension |
mm |
8460x2280x3400 |
| wheelbase |
3800 |
| Approach/departure angle |
° |
24/13 |
| Engine model |
|
CY4102-CE4C |
| Engine manufacturer |
|
Dongfeng Chaoyang Diesel Co.,Ltd |
| Transmission |
|
5 forward gear,1 reverse gear |
| Cabin |
|
With flip forward single cab, air conditioning can be
equiped if customer requires.
|
| Emission standard |
|
Euro IV |
| Displacement / Power |
ml/kw |
3856/91 |
| Tire specification / Number |
pcs |
7.50R16/6 |
| Max speed |
km/h |
80 |
| Max working height |
m |
18 |
| Rated platform load |
kg |
200 |
| Rated manned platform |
man |
2 |
| Slewing angle(Left,Right) |
° |
360 |
| Outrigger type / Q'ty |
pcs |
H-type, 4 pcs |
| Remark |
The whole truck is operated through upper and lower hydraulic operation, equipped with hook. |
More pictures of hot sale CLW brand 16m aerial working platform truck as below
high quality and competitive price Dongfeng 16m aerial working platform truck for sale
HOT SALE! dongfeng 16m high altitude operation truck
Chengli Special Automobile Co., Ltd. is the leading mnaufacturer and supplier of aerial working platform trucks in China since 2004s. We can design and produce 12m overhead working truck, 14m-16m aerial working platform truck, 18m-20m high altitude operation truck, 20m-22m aerial working truck, etc.More information, please feel free to contact with Ms. Anita Deng.
