Dayun 4x2 16cbm 2 ton freezer box truck, is also called freezing truck, refreshment truck, refrigerated and insulated truck, medicine and vaccine carrier, is a kind of used to transport frozen or fresh goods enclosed van truck, is a special transport vehicle equipped with refrigeration unit and polyurethane insulating box. It is commonly used to transport frozen food, dairy products, seafood, vegetables, fruits, vaccines, drugs, etc., mostly used in pharmaceutical companies, supermarkets, cold storage, food factory, pharmaceutical factory.
Product notes:
1. We can produce various load capacity refrigerated truck from 540kg to 20000kg, from 6m3 to 50m3.
2. Cooling temperature can reach +5 to -18 degrees.
3. you can choose well-known domestic and imported refrigeration units, such as America Thermo king, America Carrier, China HANA, China Kaixue, China Songhan, etc.
4. Factory direct sale, low price and high quality.
Our factory passed ISO9001-2008 quality system, our products all passed 3C certificate, it’s well-known products.Our company have more than 10 year professional experience.
If you'e interested in our cold room truck, please send email to truck0011@163.com or call +86 13329899995.
Website: www.trucksinchina.com
Main parameters of Dayun 4x2 16cbm 2 ton freezer box truck:
| product name:Dayun 4x2 16cbm 2 ton freezer box truck |
| Item |
detail |
parameter |
| Vehicle |
Model |
Dayun brand 4*2 LHD cold room truck for sale |
| Overall dimensions(L*W*H/mm) |
5990*2220*3350 |
| Upper box body size(L*W*H/mm) |
4050*2050*2200 |
| passenger allowed in cab |
2 person |
| Gross weight(kgs) |
4375 |
| Payload(kgs) |
1120 |
| Curb weight(kgs) |
3125 |
| Front overhang/rear overhang(mm) |
1150/1540 |
| Approach/departure angel(°) |
22/17 |
| Axle load(kgs) |
1750/2625 |
| Traction system |
4*2 |
| wheel base(mm) |
3300 |
| Max speed(km/h) |
90 |
| Chassis |
Brand |
Chengdu Dayun automobile group co. LTD |
| model |
CGC1040HDD33E1 |
| Tire specification |
7.00R16 8PR |
| Tire no. |
6 |
| Front wheel distance(mm) |
1680 |
| Rear wheel distance(mm) |
1600 |
| Transmission |
manual |
| Engine |
Model |
D25TCIE1 |
| manufacturer |
Kunming Yunnei Power Co., Ltd |
| fuel type |
diesel |
| Horse Power(kw/hp) |
105/143 |
| Exhaust(ml) |
2499 |
| Emission standard |
Euro 3/4/5 |
| Body parameter |
Dimension of panel |
Length 0-18000mm
Width 0-3000mm
Height 0-3000mm
|
| Standard thickness |
Our standard thickiness is 80mm. But the thickness can be changed according to customer's requirements, like 60mm and 100mm |
| Body material |
inside and outside:FRP/color steel panel/aluminium alloy/Stainless steel
middle:80mm polyurethane foam/XPS
|
| Compartment structure |
Don’t open at the top, rear door opening , with one side door, with stainless door frames and door accessory |
| Advantage |
1)It is good at strength and long life
2)Non-corrosion, non-pollution, anti-brine, acid and soda-resisting
3)Easy to be assembled and repaired at site
|
| Refrigerated unit parameter |
Refrigerator brand |
Thermo king, origin USA
Carrier, origin USA
HANA,origin China
Kaixue, origin China
Songhan,origin China
etc. |
| Cooling temperature |
+5 celsius~-18 celsius |
More pictures of hot sale Dayun brand refrigerator truck as below
HOT SALE! Dayun brand cold room truck
High quality and competitive price Dayun brand 4*2 LHD refrigerator truck for sale
Factory sale Dayun brand reefer van truck for sale
Chengli Special Automobile Co., Ltd manufactures refrigerator trucks since 2004s in China. With so many years’ experience in manufacturing, we Chengli Special Automobile Co. Ltd could manufacture and sell vaccine delivery vehicle, meat hook refrigerated truck, fruit and vegetables refrigerated truck, milk food transport refrigerator truck, insulation van truck, van refrigerated truck, freezer minibus, small refrigerated truck, medium freezer van truck, big refrigerated truck, refrigerator semi-trailer, freezer refrigerated vehicles, dongfeng brand cold room truck, ISUZU brand refrigerated truck, FAW refrigerated truck, FOTON refrigerated truck, Chang’an freezer van truck, Yuejin refrigerated truck, JMC refrigerated truck, CMAC refrigerator truck, Aoling refrigerated truck, the smallest refrigerated truck, etc. More information, please feel free to contact with Ms. Anita.
