Factory customized dongfeng 4*2 RHD 10,000L gasoline tank delivery truck for sale,cheapest dongfeng 10m3 fuel tank truck
Fuel tank tank mainly used for oil derivatives’s (gasoline, diesel, crude oil, lubricating oil and coal tar oil) transport and storage. Chengli special automobile co.,ltd. ,which is a famous manufacturer producing all kinds of special trucks.it can offer many kinds of oil tank trucks from 2000 liters to 40000 liters. Such as oil tank truck, fuel tanker truck, heavy oil tank truck, fuel oil tank truck,liquid tanker truck, gallon fuel tank truck,diesel oil tank truck,oil transportation tank truck,fuel tank cap truck, etc. And also support Customized. Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of fuel tank in China since 2004s. With many years' development, Chengli Special Automobile Co., Ltd. could supply Dongfeng fuel tank, ISUZU refueler truck, HOWO oil truck, Forland fuel dispenser truck, etc.
Main technical parameters of dongfeng 4*2 RHD 10,000Liters fuel tank delivery truck manufactured by Chengli Special Automobile Co., Ltd. as below.
| Dongfeng 4*2 RHD 145 170hp 10m3 oil tank delivery truck (CLW5124GYYT3) |
| Total mass(kg) |
12450 |
Tank volume |
11,000L |
| Rated mass(kg) |
5990 |
Overall dimension(L*W*H)(mm) |
7300*2470*2800 |
| Curb mass(kg) |
5445 |
Cargo body dimension |
XX |
| Driver cab person |
3 |
Max speed(km/h) |
80 |
| Approach/departure angle |
28/20 |
Front/rear suspension(mm) |
1250/2100 |
| Axle nos. |
2 |
wheelbase |
3950 |
| Axle load(kg) |
4850/7600 |
Driver cab |
Dongfeng 145 one row and a half flathead driver cab |
| Chassis main parameters |
| Chassis model |
EQ1121 |
Manufacturer |
Dongfeng |
| Transmission |
6 speed manual gearbox |
Tyre specification |
9.00-20*6 |
| Steel spring |
8/10+8 |
Front tread(mm) |
1900 |
| Fuel type |
Diesel |
Rear tread(mm) |
1800 |
| Traction system |
4*2 RHD |
Operation control system |
Steering wheel |
| Braking system |
Air braking |
Electric system |
24 V |
| Emission standard |
Euro Ⅲ |
| Engine model |
Manufacturer |
Displacement(ml) |
Power((KW) |
| B170 33 |
Cummins |
5900 |
125 |
| Standard equipments |
1. The fuel tanker shape is ellipse, adopts high quality GB 5mm thickness carbon steel, And the tanker volume is 11,000L.
2, carbon steel gear oil pump with the function of pump-out and pump-in.
3, One Euro standard aluminum alloy manhole
4, one aluminum alloy bottom subway valve (also called pneumatic emergency short-off valve)
5, single compartment with several anti-wave sheets.
6, top mounted anti-slip walkway and elevating guardrail,
7, rear part of the fuel tank with ladder
|
| Others |
Clients choose to install one set of bottom loading system, loading diesel/fuel/oil from the bottom. Otherwise loading the fuel from the top manhole. |
More pictures of hot sale Factory customized dongfeng 4*2 RHD 10m3 oil tank delivery truck as below
Factory customized dongfeng 4*2 RHD oil tank delivery truck for sale
HOT SALE! dongfeng 4*2 RHD gasoline delivery truck
high quality and competitive price dongfeng 4*2 LHD oil tank truck for sale
Chengli Special Automobile Co., Ltd is the leading manufacturer and supplier of fuel tank in China. With many years’ development, Chengli Special Automobile Co., Ltd. could offer 3m3 to 30m3 fuel tank truck, oil dispensing trucks, and fuel tank trailer, etc. More information, please feel free to contact with Ms. Anita.
