high quality and competitive price customized CLW brand 4 axles 30,000Liters vacuum tank semitrailer for sale,
One customized CLW brand 4*FUWA axles 30,000Liters vacuum tank semitrailer manufactured by Chengli Special Automobile Co., Ltd. as below.
High quality and competitive price CLW brand 30m3 VACUUM TANK TRAILER
high quality 4 sets*FUWA axles
customized CLW brand 30,000Liters 4 axles sludge tank semitrailer for sale
main technical parameters of CLW brand 30m3 4 axles vacuum tank semitrailer manufactured by Chengli Special Automobile Co., Ltd. as below
| No.1 |
Main Components |
Detail Descriptions |
| 1 |
Product name |
Vacuum tank semitrailer |
| 2 |
Overall dimension(L*W*H) |
13.5*2.5*3.5(m) |
| 3 |
Vacuum tank volume |
30m3 |
| 4 |
Vacuum tank |
1,Vacuum tank volume: 30m3
2,Tank material: 6mm thickness carbon steel/304 stainless steel
3,Vacuum tank dimension(Diameter*Length): 1.8*11(m)
4,Vacuum pump model: water ring vacuum pump(pump model: SK-30)
5,Front-installed Hydraulic lifting cylinder to tip the tank
6,Secondary Engine: weichai power 4102(secondary engine drives the vacuum pump and hydraulic system)
7, without tipping, choose to tipping function: the back door can be hydraulic opened and tipped(the back door can be operated by the hydraulic switch with self-discharging function)
8,Sucking hose: one 8m length sucking hose |
| 5 |
Driving system |
4*13ton Fuwa axles, 12pcs *10.00R20 radial tyres with 12pc rims, merchanicl steel spring suspension,,28tons landing outriggers, 50#/90# tractor kingpin. |
| 6 |
Special parts |
The special parts of the vacuum tank semitrailer are vacuum pump, PTO, shaft, water separator, oil separator, multi-way valve, vacuum tanker, discharging valve, sewer view window, vacuum pressure gauge, pipelines, hydraulic system, side water tanker with high pressure pump, |
| 7 |
Brake system |
Double line air brakes |
| 8 |
Electronic system |
Complete 24V system in water proof installation,rear lighting with rear, stop, parking, direction, fog, reverse lights, side lights, etc. |
| 9 |
Remark |
The production time is about 50days.
The price is valid for one month. |
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of sewage suction trucks in China since 2004s. With many years'experience in developing, Chengli Special Automobile Co., Ltd. could supply 2cbm-16cbm sludge tank truck, such as dongfeng brand sewage suction truck, ISUZU septic tank truck, FAW vacuum truck, forland sewage suction truck, JMC liquid wastes truck, Yuejin cesspit empiter truck, HOWO vacuum truck, vacuum tank semitrailer, etc.
