HOT SALE! new best price Dongfeng 120HP diesel road washing sweeper truck, street washing and sweeping vehicle for sale
The standard devices of dongfeng duolika street washing sweeper truck are as below.
2 middle-installed sweeping disks, middle-installed wider sucking nozzles, JMC 64KW super-charged auxiliary engine, Taiwan hydraulic valves, dali motor, German high pressure water pump, weilong low-pressure pump, 3mm thickness stainless steel dust tank+ 3mm stainless steel water tank, German controller, rear part arrow light; oil, dust tank, and water tank are with anti-overflow or low alarm device; Reversing and washing state monitor; Multiple voice instructions, Anti-dumping garbage rollover protection and Overhaul safety protection; 20m high pressure flushing reel; Brush arm rotation mechanism uses German imported high-tech wear-resistant engineering spacer, free butter; Precision cold bending seamless hydraulic hose; Motion controller one-button computer control.
If you're interested in our CLW Brand road sweeping and washing truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
More pictures of dongfeng brand 4*2 LHD/RHD road sweeping and washing vehicle manufactured by Chengli Special Automobile Co., Ltd. as below.
main technical parameters of dongfeng road sweeping and washing truck as below
|
Main parameters of dongfeng duolika road washing and sweeping vehicle manufactured by Chengli Special Automobile Co., Ltd.
|
|
Truck model
|
dongfeng road washing and sweeping vehicle for sale
|
Remark
|
|
Truck chassis model
|
EQ1110SJ8BDC
|
|
|
Wheelbase
|
3800 mm
|
|
|
Front/rear suspension
|
1130/2070,1150/2050 mm
|
|
|
Engine model
|
Chassis engine
|
CY4SK251；YC4S150-50；ISF3.8s5154；
4DX23-140E5；YN38CRE1; CY4102
|
|
|
Auxiliary engine model
|
JE493ZG5
|
|
|
Engine rated power
|
Chassis engine
|
115；110；115；105；95 ; 88kW
|
|
|
Auxiliary engine
|
64 kW
|
|
|
Max grade
|
30%
|
|
|
Mini turning diameter
|
≤16m
|
|
|
Emission standard
|
Euro Ⅴ/Euro Ⅲ
|
|
|
Accelerate the noise outside the car
|
≤84dB(A),Meet the noise two-stage requirements
|
|
|
Max speed
|
103 km/h
|
|
|
Approach/departure angle
|
21°
|
|
|
Departure angle
|
11°
|
|
|
Braking distance
|
≤10 m
|
|
|
Mass
|
Curb mass
|
7045 kg
|
|
|
Max total mass
|
11450 kg
|
|
|
Dimension
|
Overall dimension(L*W*H)
|
7000×2200×2700 mm
|
|
|
Mini ground clearance
|
250 mm
|
|
|
High pressure washing
|
Speed
|
3~20 Km/h
|
|
|
Width
|
3 m
|
|
|
Water pressure
|
12 MPa
|
|
|
Water pump flow
|
115 L/min
|
|
|
Sucking and sweeping
|
Sweeping effectiveness
|
≥95%
|
|
|
Maximum inhalation particle size
|
110 mm
|
|
|
Sucking and sweeping width
|
3 m
|
|
|
Max sweeping ability
|
60000 m2/h
|
|
|
Disc-shaped brush overhang size
|
≥400 mm
|
|
|
|
Driving speed when sucking-washing
|
3-20 km/h
|
|
|
Water Tank
|
volume
|
5 m³
|
|
|
Dust tank
|
Volume
|
5 m³
|
|
|
Discharge door opening angle
|
≥45°
|
|
|
Hydraulic system
|
Type
|
Open-type, electrical controlling
|
|
|
Main units
|
Gear pump, hydraulic motor, hydraulic cylinder, electromagnetic valve
|
|
|
System pressure
|
16 MPa
|
|
|
Hydraulic oil tank volume
|
60 L
|
|
|
Oil temperature
|
60 ˚C
|
|
|
Electrical system
|
Type
|
DC12 V
|
|
|
Voltage
|
12 V
|
|
|
Storage batteries
|
12 V
|
|
|
High pressure water system
|
Type
|
Piston pump
|
|
|
Model
|
German PT36
|
|
|
System pressure
|
10 MPa
|
|
|
Rotating speed
|
1150 r/min
|
|
|
Water valve type
|
Hydraulic high pressure ball valve
|
|
|
Water valve pressure
|
7 MPa
|
|
|
Sprayers type
|
High pressure washing type
|
|
|
Water-filter
|
Filter type
|
|
|
Sprinkling system
|
Main units
|
Electric diaphragm pump, water filter, nozzle, etc.
|
|
|
Low-pressure water system
|
Model
|
Weilong 40/50
|
|
|
Flow
|
40 m3/h
|
|
|
Head
|
50
|
|
|
Sweeping disk device
|
Type
|
Middle-installed two sweeping disks, hydraulic motor drive, adjustable rotated speed, separated controlled, Automatic avoidance function
|
|
|
Sweeping disk diameter
|
850 mm
|
|
|
Sweeping disk speed
|
high:110; medium:80; low:50
|
|
|
Sweeping disk angle
|
Forward leaning:4-6°; Extravert:4-7°
|
|
|
Sucking disk
|
Type
|
Double suction, hydraulic control, spring suspension
|
|
|
Diameter
|
180 mm
|
|
|
Width
|
1800 mm
|
|
|
Side spraying staff
|
V type spraying staff with the function of automatic avoidance function
|
|
| |
|
|
|
|
2, vehicle tools
| List |
Name |
No. |
Remark |
| 1 |
Fire hose |
2 |
One for filling water, another for discharging sewage |
| 2 |
Fire wrench |
1 |
Used for removing hydrant |
| 3 |
Water filter wrench |
1 |
Used for removing water filter |
| 4 |
High pressure spraying gun |
1 |
Used for high pressure spraying gun |
| 5 |
Spare tire |
1 |
|
| 6 |
manual hydraulic pump joystick |
1 |
Used for start manual hydraulic pump |
3, spare parts
| List |
Name |
No. |
|
| 1 |
Brush |
1 |
|
| 2 |
Rear door seal |
1 |
|
| 3 |
Fan seal |
1 |
|
| 4 |
Duster seal |
2 |
|
5, the imported devices for the CLW brand road sweeping and washing vehicle manufactured by Chengli Special Automobile Co., Ltd.
| List |
Name |
Model |
Manufacturer name |
| 1 |
High pressure water pump |
PT36 |
German PINFL |
| 2 |
Automatic discharging valve |
VB200/150 |
German PINFL |
| 3 |
Overflow valve |
VS200-180 |
German PINFL |
| 4 |
Electric control box controller |
|
German STW |
| 5 |
Knob switch |
|
Japan hequan |
| 6 |
Sewerage sensor |
|
America Danaher |
| 7 |
Hydraulic valve |
SWH-G02-C4-D2H |
Northman Co., Ltd. |
More information, please feel free to contact with Ms. Anita.
Whatsapp/Wechat/Mob.: +86 13329899995
Skype: truck0011
Email: truck0011@163.com
Road Sweeper Truck Foton Dongfeng Road Sweeper Cheap Price Good Quality Hot Sale For Sale Street Sweeper Brooms
Features:
1.Main material of tank use Q345 steel,high strength,compared with ordinary steel materials,under the same thickness
increase 60% strength than ordinary low carbon steel;Tank use epoxy anti-corrosion material handling,
great corrosion resistance, greatly extending the life of tanker.
2.Using Hangzhou Veyron sprinkler pumps,with characteristics of output power
and high pressure .
3.Sprinkler system install manual valves and pneumatic valves,both manual and automatic control can be used,tank Install alarm system of
low water level to prevent damage to the pump because of water shortage.
4.Tank is equipped with a spacious rear platform, people can operate on thestage, the use of high-pressure spray gun with a long-range, can do long-range spraying operations,High pressure spray gun nozzle can be
achieved by manually adjusting the water column, mist spray, mist,heavy rain and
light rain to meet different needs.
high-pressure water system:
Before cleaning device’s cleaning width 2.5m ~ 3.5m, we can control, when the adjustable spray rod shrink,
to achieve enhanced the dual water wash.
Using natural gas vice engine to drive high pressure pumps and working device hydraulic system, high pressure cleaning
speed can be controlled at will.
Liquid, gas central control, has good man-machine interface, operation can be convenient and flexible.
Use of international brand-name high-pressure pumps, reliable performance,
long life, ensuring the cleaning effect; inlet nozzle, jet stability, low pressure loss.
Using modular combination design, implement a variety of cleaning functions and auxiliary work function, a multi-purpose machine.
Spray on left and right angle is suitable for efficient water-saving ground pavement,
curbs, guardrails isolation belt, sidewalks.
High pressure spray gun not only can be use clear signs, billboards, etc.; but also can spray dust,adjust air
humidity and spray air disinfectant.
