Product Description of CLW brand surface lpg gas storage tanker manufactured by Chengli Special Automobile Co., Ltd. as below.
|
|
LPG STORAGE TANK SPECIFICATION |
|
Capacity
(CBM)
|
Diameter
DN
|
Shell thickness
(mm)
|
Head thickness
(mm)
|
Kerb weight
(kg)
|
Loading
Weight
(kg)
|
Overall dimension(mm) |
| 5 |
1600 |
10 |
10 |
2030 |
1995 |
3070*1620*2210 |
| 8 |
1600 |
10 |
10 |
2540 |
3192 |
4270*1620*2210 |
| 10 |
1600 |
10 |
10 |
2950 |
3990 |
5260*1620*2210 |
| 12 |
1800 |
10 |
12 |
3360 |
4788 |
5034*1820*2410 |
| 15 |
1800 |
10 |
12 |
3920 |
5985 |
6224*1820*2410 |
| 20 |
1800 |
10 |
12 |
4820 |
7980 |
8174*1820*2410 |
| 25 |
2200 |
12 |
14 |
6020 |
9975 |
7008*2224*2814 |
| 32 |
2400 |
14 |
14 |
7710 |
12768 |
7508*2428*3018 |
| 50 |
2600 |
14 |
16 |
10910 |
19950 |
9912*2628*3218 |
| 50 |
2700 |
14 |
16 |
10640 |
19950 |
9182*2728*3318 |
| 80 |
3100 |
16 |
18 |
17000 |
31920 |
11166*3132*3722 |
| 80 |
3200 |
18 |
18 |
18140 |
31920 |
10516*3236*3826 |
| 100 |
3100 |
16 |
18 |
20410 |
39900 |
13866*3132*3722 |
| 100 |
3200 |
18 |
18 |
21800 |
39900 |
13016*3236*3826 |
| 120 |
3400 |
18 |
20 |
24960 |
47880 |
13820*3436*4026 |
| Design pressure |
1.77MPa |
| Corrosion allowance( mm) |
1mm |
| Medium density (kg/m3) |
420kg/m3 |
| Material of tank and main pressure parts |
Q345R |
| Carried standard |
Pressure vessels,supervision regulation on safety technology
for stationary pressure vessels
|
| Safety valve of selection fitting |
Safety valve, column magnetic reversible level meter,pressure gauge,
thermometer,cut-off valve
|
Remark:
1 The safety valve is designed under the condition that the tank is placed under spray device whose flow is larger than 10L/m.min
2 The location dimension of pipe orifice can be setted by the user's actual place .
3 We can change reversible level meter to magnetic float ball type according to the user's requirement.
4 The data list is only for reference ,take the drawing as accuracy.
