Hydraulic lifting platform truck, also called high altitude operation truck, is specially designed and produced for aerial work or operation, such as repairing road lights, maintain high buildings, windows, hanging ad boards, power grid maintenance, etc.
The technical advantages of CLW brand aerial platform vehicle manufactured by Chengli Special Automobile Co., Ltd. as below.
1. Aerial platform vehicles is also named high-altitude operation truck, refers to the special vehicles for aerial operation with the delivery of staff and the equipment to the scene.
2. We are professional factory, supply Dongfeng aerial vehicles, JMC aerial working vehicles, JAC aerial platform vehicles, Qingling high-altitude working truck, Foton aerial platform operating vehicles, etc., working height of 8-24 meters for choose.
3. Produced by the high-altitude operation vehicles, using double lift hydraulic cylinder, up and down a total of four hydraulic cylinders, the conventional aerial vehicles only two lifting cylinders, double lift hydraulic cylinder in the lift, rotation process does not tremble, do not shake, stability Sex, safety is better.
4. High-altitude operation vehicles using domestic or imported reversing valve and hydraulic cylinder, for the balance, flexible and convenient operation, outrigger and work arm interlocking, outrigger and work arm interlock to prevent misuse over.
5. Installed four hydraulic legs, to ensure vehicle stability and safety in operation.
6. Optional aerial crane hook, hook hanging 1 ton and the electronic control system.
7. Aerial platform vehicles can be up and down operation, 360-degree rotation, install the hand throttle.
8. If you have any special requirements for the aerial vehicles, please let us know, we can design for you.
If you're interested in our hydraulic platform truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995
Website: www.trucksinchina.com
Parameters of 10m Hydraulic Platform Trcuk manufactured by Chengli Special Automobile Co., Ltd. as below.
| Product name |
CLW5041JGKJX3 hydraulic platform truck |
Options |
| Producer |
ChengLi Special Automobile Co.,Ltd |
|
| Brand |
CLW |
|
| Max Working Height |
10 meters |
|
| Overall dimention |
5995x2000x2690(mm) |
|
| Man-stand platform |
1800x850x800(mm) |
|
| Type |
Hydraulic lifting up and down |
12~32m |
| Chassis Brand |
JMC |
Dongfeng, Forland,Sinotruk,etc |
| Drive cab |
Single cab, LHD |
Double cab option |
| Engine |
77hp Euro 3 diesel engine |
|
| Brake |
Oil brake |
|
| Steering |
Power steering |
|
| Transmission |
MT, 5 forward gears and 1 rear gear |
|
| Wheelbase |
3360mm |
|
| Tire |
7.00R16 radial tire, 6+1 |
|
| Max speed |
90km/h |
|
| Main Safety System |
| Emergency pump |
Included, When the engine and main pump fail, workers can be sent back to the ground |
| Engine on/off on basket |
Included |
| Automatic interlock device |
Basket and gound control lock, the two can’t operation at same time |
| Level detection function |
Real-time detection of wh the vehicle is horizontal |
| Emergency stop device |
For emergency stop operation |
| Night safety warning device |
There are engineering strobes and lights on the vehicle |
| Vehicle level status tester |
Can detect the horizontal and vertical tilt of the vehicle |
