The vacuum sewage suction truck is also called sewage truck,vacuum pump sewage truck,
sewer vacuum truck, sewer tanker truck,vacuum sewage suction truck, sewage suction tanker truck, etc. It mainly used for for suction,transportation and discharge of sewage
from septic tank and sludge from drains.Widely used by municipal environment and
sanitation department and residential management.
As a professional sewage vacuum truck manufacturer in China, the sewage tanker truck capacity is from 3000 liter to 16000 liters.
The septic tanker truck is with self-suction and self-unloding function. The tank can be lifted by
hydraulic cylinder to 45° and the rear door of the tank can also be open by hydraulic.So the sewage can be discharged from the tank completely. This is also convenient for you to maintenance and clean the tank.
Overfill system with music horn is equipped to prevent the vacuum pump damage from sewage
water into vacuum pump when the tank is full.
Super power of vacuum pump, seamless die casted sheel cover, designing for container with high ability of pressure-resistance,double hydraulic jack system, more strength then cesspit emptier.
The suction depth of our vacuum tanker is more than 7 meter and sewage truck capacity is from 10000L to 16000 liters sewage truck is with double famous Weilong pump.It is high
efficiency and manpower saved.
Sewage truck Basic Equipment
Imported vacuum pump, power-take-off, hydraulic cylinders, control valves , pressure gauge,
water gas separator , oil water separator, level inspection window, suction hose,pipeline system,etc.
Chengli sewage suction truck advantages
1.Tank can be lifted hydraulically to 40 to 45 degree.Rear door can be opened&closed
hydraulically. With full opening design, discharge can be very quick&complete.
2.Overfill system with music horn is equipped to prevent the vacuum pump damage from sewage water into vacuum pump when the tank is full.
3.Super power of vacuum pump, seamless die casted sheel cover, designing for container with high ability of pressure-resistance,double hydraulic jack system, morestrength then cesspit
emptier.
If you're interested in our CLW brand vacuum tanker truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995
Website: www.trucksinchina.com
More pictures of CLW brand sewage suction truck as below.
Technical Paramters of clw brand new sewage drainage truck 10m3 manufactured by Chengli Special Automobile Co., Ltd. as below.
| Items |
Descriptions |
Specifications and Types |
| General |
Truck Name |
Vacuum Sewer truck |
| Drive Type |
4*2 |
| Gross Vehicle Weight(kg) |
16000 |
| Loading Capacity (kg) |
10000 |
| Overall Dimensions L*W*H(mm) |
8480×2500×3250 |
| Engine |
Engine Model |
WD615.97 |
| Engine Brand |
SINOTRUK |
| Fuel Type |
Diesel |
| Power |
290HP |
| Emission Standard |
Euro II |
| Displacement(ml) |
9726 |
| Engine Type |
6 cylinders,turbo-charged diesel engine,inter-cooling,high common rail |
| Chassis |
Chassis Brand |
HOWO |
| Front/Rear Axle |
STR/ST16 |
| Tire No. |
6 |
| Tire Specification |
295/80R22.5 Tubeless tire |
| Wheelbase (mm) ; |
4600 |
| Axle No. |
2 |
| Gear Box |
HW19710,10 speed forward with 2 reverse |
| Brake |
Air brake |
| Steering Wheel |
Left hand drive with power-assisted |
| Air conditional |
Suitable for tropical climate |
| Tank and Pump |
Sewage Tank Volume(L) |
10000 |
| Tank Material |
5mm carbon steel |
| Tank Shape |
Cylindrical |
| Suction Depth |
≥6m |
| Vacuum pump |
Double Weilong pump |
