The fuel trucks is also called refuel truck, fuel dispenser truck, refuel tanker truck, oil dispensing truck, oil tanker truck, oil delivery truck, etc. The oil tanker truck is mainly used to transport oil, fuel, gasoline, diesel, etc. It can be equipped fuel dispenser and fuel pump to refuel for other automobile. The shape of the fuel tanker is elliptical or rectangular and the material can be high quality carbon steel plate Q235 , stainless steel or aluminium alloy. Whole tank was divided into two compartments or more compartments with several inner baffles to reinforce the tank strength and prevent longitudinal surge during move.
In order to prevent corrosion, the surface of the tank was printed anticorrosive paint and decorative paint. The middle side of the tank was equipped indicator which can indicate the filled oil volume when pump oil. As a professional mobile oil tank trucks manufacturer, the mobile refueling trucks for sale is from 5000 liters to 45000 liters. They are from 4*2 fuel trucks to 6x4 fuel tank trucks. Besides oil tanker truck, our factory also produce fuel tanker trailer and the fuel tank capacity is from 30000 liters to 60000 liters.
all wheel drive 5k liters diesel fuel refilling oil refuel mobile fuel dispenser tank truck for hot sale
Competitive advantage fuel tanker truck series
1 Applied carbon steel sheet Q235-A that in accordance with the international standard. Thickness is 5-10mm.
2 Apply the famous pump.
3 The main parts implements automatic welding, while the accessories apply carbon dioxide welding to ensure the tank in good performance.
4 Sub crossbeam apply rectangle steel sheet that thickness 5mm, stick out in one time.
5 Fire extinguisher replaced on the back of the truck for the emergency.
Painting held more tolerance and coherence, can make sure the tank in good situation within 5 years.
6 According to customer’s needs:
A> The pump can be designed to pump in and out throw meter, or not through meter, self-flow through or not through meter.
B> The tank can be designed as a single compartment or several compartments.
C> You can choose to install heating pipes, insulation layer. The Insulation material is generally 50-100 mm thickness, insulation can be used rockwool, glasswool, polyurethane foam, aluminum silicate. The cladding can be used 1.8-2mm thick white (RAL9003) glass reinforced plastic, 1.2mm cold carbon steel, 1.00mm stainless steel sub-mirror or matter board.
D> At the end or side of tank, It can be installed 1-3 self-flow valve.
If you're interested in our fuel tanker truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995
Website: www.trucksinchina.com
More pictures of CLW brand fuel tanker truck as below.
Main specification for est price 6w smart all wheel drive 5k liters diesel fuel refilling oil refuel mobile fuel dispenser tank truck for hot salefor hot sale as below:
| Item |
Unit |
Parameter |
| Vehicle model |
oil tank truck |
| Chassis model |
CLW5074GJYD4 |
| Overall dimensions |
mm |
5995*1960*2300 |
| Fact cubage |
L |
4000 |
| Gross weight |
kg |
7300 |
| Curb weight |
3865 |
| Payload capacity |
3305 |
| Axle load |
2920/4380 |
| Body internal dimensions |
mm |
3050x1750x1150 |
| Wheelbase |
3300 |
| Front/Rear track base |
1032/1663 |
| Front/Rear overhang |
1506/1466 |
| Approach/Departure angle |
° |
13/14 |
| Exhaust/Power |
ml/hp |
3856/99 |
| Max speed |
km/h |
80 |
| Engine model |
cy4102 |
Electric system |
24V |
| Traction system |
4X2 |
Number of axles |
2 |
| Tire specifications |
7.00-16 or 7.00R16 |
Number of tires |
6+one spare tire |
| Operation control system |
Electrically hydraulic control |
Allowable passengers in cab |
2 |
| Equipment |
Meterial:5-6mm carbon steel or stainless steel with oil pump, can choose flow meter, tankerpiston and bobbin disk, for more details please cotact with me, skype:weitruck. |
| Tank can be separated to several unattached small tanks to fill different fuels |
| Equipped with fuel dispenser, fire extinguisher, ladder, grouding wire |
| Engine |
diesel engine |
