best seller- FOTON XIANGLIN M1 gasoline refrigerated truck for sale, Factory sale cheapest refrigerated minivan for sale
Chengli Special Automobile Co., Ltd manufactures refrigerator trucks since 2004s in China. With so many years’ experience in manufacturing, we Chengli Special Automobile Co. Ltd could manufacture and sell vaccine delivery vehicle, meat hook refrigerated truck, fruit and vegetables refrigerated truck, milk food transport refrigerator truck, insulation van truck, van refrigerated truck, freezer minibus, small refrigerated truck, medium freezer van truck, big refrigerated truck, refrigerator semi-trailer, freezer refrigerated vehicles, dongfeng brand cold room truck, ISUZU brand refrigerated truck, FAW refrigerated truck, FOTON refrigerated truck, Chang’an freezer van truck, Yuejin refrigerated truck, JMC refrigerated truck, CMAC refrigerator truck, Aoling refrigerated truck, the smallest refrigerated truck, etc. More information, please feel free to contact with Ms. Anita.
FOTON XINGLIN M1 gasoline refrigerated truck adopts FOTON XIANGLIN 1520mm truck body, 2750mm wheelbase, DAM15KL 116hp diesel engine, DAT18R-5 speed manual gear, 175R14 tires*6, 121 rear axle, power steering, air conditioner, ABS, etc.
And the cold room box body dimension (L*W*H) of this FOTON XIANGLIN M1 gasoline refrigerated truck is 3120*1580/1620*1560 (mm); while the overall dimension (L*W*H) of this FOTON refrigerated truck is 5070*1765/1780*2490 (mm). Exterior and interior with FRP(Fiber Reinforced Plastic), and the middle with PU slices with vacuum negative pressure one-formed casting as the insulation layer, approved the related Ministry of Health of food grade requirements, etc. just like sandwich structure. Baseboard adopts anti-skipping diamond board, which assuring the insulation ability and the compact resistance of the baseboard. double rear door opened. Choose high quality China-made self-powered frozen refrigerating reefer, the lowest temperature is up to -5℃ to 15℃. And the reefer can be adjusted at the driver cab.
If you're interested in our refrigerated truck, please send email to truck0011@163.com or talk o Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
More pictures of FOTON XIANGLIN M1 gasoline refrigerated truck as below.
Main technical parameters of FOTON XIANGLIN M1 gasoline refrigerated truck manufactured by Chengli Special Automobile Co., Ltd. as below.
| Items |
Descriptions |
Specifications and Types |
| General |
Truck Name |
FOTON XIANGLIN M1 4*2 LHD gasoline refrigerated truck |
| Drive Type |
4*2 LHD, |
| Payload (kg) |
1.5T |
| Seating person |
2 |
| GVW (kg) |
1615 |
| Curb Weight (kg) |
1750 |
| Overall Dimensions (L*W*H) (mm) |
5070*1765/1780*2490 |
| Insulation van dimension(L*W*H)(mm) |
3120*1580/1620*1560 |
| Driver cab |
FOTON XIANGLIN 1520mm truck body |
| Engine |
Engine Model |
DAM15KL |
| Engine Brand |
Dong’an |
| Fuel Type |
Diesel |
| Max output (hp/rpm) |
85KW/116hp |
| Emission Standard |
Euro Ⅵ |
| Capacity (cc) |
1498 |
| Chassis |
Chassis Brand |
FOTON |
| Tire Specification |
175R14LT 8PR*6 |
| Wheelbase (mm) |
2750 |
| Axle No. |
2 |
| Steering Wheel |
Left hand drive, |
| Gear Box |
5 speed gearbox, manual |
| Brake |
Air brake |
| Air-conditioner |
No, can be installed |
| Cold Room |
Box inner dimension(mm) |
3120*1580/1620*1560 |
| Box Side |
Exterior and interior with FRP( fiber reinforced plastic), and the middle with 80mm PU slices with vacuum negative pressure one-formed casting as the insulation layer, approved the related Ministry of Health of food grade requirements, etc. just like sandwich structure. |
| Box Floor |
Baseboard adopts aluminum alloy anti-skipping diamond board, which assuring the insulation ability and the compact resistance of the baseboard. |
| Doors |
Frame of standard rear double doors adopts the stainless steel structure frame with light mass and perfect corrosive resistance, etc.
The door edgings frames are sealed with the imported high quality epdm rubber, making sure the van insulation stability.
Door edgings, door locks and accessories use stainless steel materials.
|
| Refrigeration unit |
Choose high quality China-made self-powered frozen refrigerating reefer, the lowest temperature is up to -5℃ to 15℃. And the reefer can be adjusted at the driver cab.
|
| Remark |
The refrigerated truck can choose to install meat hangers, vent-slots, etc. and side doors. |
