customized aluminum alloy material 20cbm bulk oil transported tanker truck for sale, HOT SALE! DONGFENG fuel tanker vehicle
Customized dongfeng Tianjin 6*4 LHD 20CBM oil tanker deliver truck adopts dongfeng Tianjin luxurious driver cab, 4350+1300mm wheelbase, Cummins 210hp diesel engine or Yuchai 240hp diesel engine, 10.00R20 rail tires*10+1, 5tons front axle/10tons*2 rear axles, air cut braking, 8 speed gearbox, etc.
The volume of dongfeng tianjian 6*4 LHD fuel tanker truck is 20cbm, adopts high quality aluminum alloy material. (stainless steel material/ carbon steel material is selective)
Product Notes of CLW Brand fuel tank truck manufactured by Chengli Special Automobile Co., Ltd. as below.
1.We can supply fuel truck, refueling truck from 4000L to 40000L.
2. According to your requirements, it has functions of oil-absorbing, oil-pumping, separation variety of oil, separation packing of oil.
3. The tank material can choose carbon steel or 304 stainless steel or aluminum alloy.
4.Optional Chassis Brand: Dongfeng, Fonton, WUSHILIN, JMC,JAC, Chang'an,Sinotruk,Steyr,Shacman,FAW, Iveco, Auman and North BENCHI etc.
5. Factory direct sale, high quality and good price.
If you're interested in our oil tanker truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995
Website: www.trucksinchina.com
More picures of dongfeng tianjin 6*4 LHD 20CBM oil tanker truck manufactured by Chengli Special Automobile Co., Ltd. as below.
main technical parameters of dongfeng tianjin 20cbm fuel tanker truck as below.
| Main technical parameters |
| Dongfeng TIANJIN 6*4 LHD 20,000Liters oil tanker truck for sale |
| Total mass(Kg) |
26000 |
Tank volume(L) |
20,000Liters |
| Rated mass(Kg) |
16000 |
Overall dimension(mm) |
9600×2550×3390 (mm) |
| Curb mass(Kg) |
9805 (Kg) |
Driver cab person |
3 |
| Approach/departure angle(°) |
22/12 (°) |
Front/rear suspension(mm) |
1480/2170 (mm) |
| Axle nos. |
3 |
Wheelbase(mm) |
4350+1300 |
| axle load (Kg) |
7000/19000(double axles) |
Max speed (Km/h) |
80 |
| Chassis main parameters |
| Chassis model |
dfl |
Chassis manufacturer |
Dongfeng |
| Tyre specification |
10.00R20 rail tires |
Tyre nos. |
10+1 |
| Steel spring |
3/- |
Front tread(mm) |
2030(mm) |
| Fuel type |
Diesel |
Rear tread(mm) |
1860/1860 (mm) |
| Transmission |
8 speed transmission |
Air-conditioner |
No, choose to install |
| Power steering |
Yes |
Front/rear bridge |
5tons/double rear 10tons |
| Electronic line |
24V |
Exhaust braking |
Yes |
| brake |
Air brake |
Driver cab |
Dongfeng 153 6*4 RHD driver cab |
| Emission standard |
Euro 3 |
| Engine model |
Manufacturer |
Displacement (ml) |
Power (Kw) |
| B210 33 |
DONGFENG CUMMINS |
5900 |
155 |
| Engine type |
6 cylinders in line, Turbocharged and intercooled diesel engine |
| Standard devices |
1. The fuel tanker shape is ellipse, adopts high quality carbon steel/stainless steel material, with single one compartment and several anti-wave sheets. And the tanker volume is 22,500L.
2, special carbon steel oil pump, pump-out and pump-in.
3, One Euro standard manhole
4, one aluminum alloy bottom subway valve (also called pneumatic emergency short-off valve).
5, single compartment with several anti-wave sheets.
6, top mounted anti-slip walkway and elevating guardrail,
7, rear part of the fuel tank with ladder
|
| Others |
Clients choose to install one set of bottom loading system to loading diesel/fuel/oil from the bottom. Otherwise loading the fuel from the top manhole. |
Oil tanker truck also called fuel tank truck, fuel tanker truck, fuel oil delivery trucks, oil transport tanker truck, mobile refueling truck, oil fueling vehicles, oil bowser trucks, petrol/diesel carrying vehicles, fuel bowser truck, oil tank trailer, fuel tanker semi trailers, mobile oil tank trucks, etc.
Optional tank capacity: 3 - 35 m3 (3,000 - 35,000 liters) for oil fuel truck
30 - 60 m3 (30,000 - 60,000 liters) for oil fuel trailer
Optional truck brand: DFAC, Dongfeng, JAC, JMC, HOWO, FAW, SHACMAN, YUEJIN, FOTON, ISU-ZU, HINO, etc.
Optional wheel drive: 4x2, 4x4, 6x4, 6x6, 8x4, left hand drive or right hand drive
