The poultry transported truck for day old chicks is mounted on the truck chassis, choosing high quality, high strength FRP materials with high-tech Sandwich crafts working.
The advantages of the day old ducks truck are rainproof, dustproof, theft-proof, environmental protection, high efficiency, ventilating, insulation, large loading capacity, etc.
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of van truck in China. With many years’ development, Chengli Special Automobile Co., Ltd. could supply refrigerated truck, insualtion body van box, cargo van truck, baby chick transported truck, etc. And our CLW brand van truck have been exported to many countries all over the world. More information, please feel free to contact with Ms. Anita.
Day old chick truck is also called baby chick truck, young chicks transported truck. There are several electronic ventilator fans on the top, and the left-right sides with several slidable windows to keep air ventilated. There is cooling reefer, adjusted the temperature freely, suitable for transporting farm poultry, etc.
It is mainly for professional transporting day old chicks, day old ducks, baby goose, flowers, seedlings, etc. a good tools to improve efficiency and reduce transporting cost.
If you're interested in our day old chick transported truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
Customized ISUZU brand day old chick truck, adopts ISUZU 100P single row driver cab, 3360mm wheelbase, 4JB1CN Isuzu 98hp Euro 4 diesel engine, 7.00-15 tires, 2-2.5tons front axle/3-4.5tons rear axle, etc.
More picture of ISUZU brandlivestock poultry day old chick transported van truck manufactured by Chengli Special Automobile Co., Ltd. as below.
The specification of ISUZU Brand day old chick transported vehicle manufactured by Chengli Special Automobile Co., Ltd. as below.
| Product name |
ISUZU 4*2 LHD day old chick transported truck |
| Overall dimension(L*W*H)(mm) |
5995×1910×2790 |
Chick van box dimension(L*W*H)mm |
4100×1740×1750 (mm). |
| Drive type |
4*2 LHD |
Total mass |
4475 |
| Gearbox |
5 speed transmission, manual |
Tyre specification |
7.00-16 rail tyres *6+1 |
| Power steering |
Yes |
Exhaust braking |
Yes |
| Oil cut braking |
Yes |
Driver cab |
ISUZU 100P single row driver cab |
| Engine |
4JB1CN |
Emission standard |
Euro 4 |
| Rater power |
72KW/98hp |
Displacement (ml) |
2771 |
Main technical parameters of day old chick van body
| Performance and consumption |
| Heating system |
Watering system |
Without, client choose to install |
| Cooling system |
One refrigerated reefer |
China made high quality vehicle-powered refrigerated reefer( the lowest temperature inside the cold room box up to -10℃, adjusted at the driver cab) |
| Ventilation system |
Air duct installed on the floor for air flow |
three line as the pictures show |
| Cold air ducts on the two sides of the van body |
Two cold air ducts for the refrigerated reefer |
| Blind windows |
4 sets of blind windows for the left and right van sides (as the pictures show); one bigger water-proof blind window at the front van plate.
Blind Windows: 4*2+1=9
|
| electronic ventilator fans |
1, 4 sets of electronic ventilator fans with sliding doors for the rear plate door; 4 sets of electronic ventilator fans for the van top
Electronic fans: 4+4=8
|
| Sky-window |
Top mounted sky windows*2 Sky-windows: 2*1=2 |
| Sliding window |
One sliding window at the front van plate(as the picture show) |
| Dimension |
| Chick van box body |
Length |
4100mm |
| Width |
1740mm |
| Height |
1750mm |
| Refrigerated van box |
Exterior and interior with FRP( fiber reinforced plastic), and the middle with 80mm PU slices;
Aluminum-patterned baseplate;
|
