Mobile crane is also called truck crane, a kind of crane mounted on general truck chassis or special purpose truck chassis. The driving cabin and lifting operation cab are setted separately. The advantage of this kind of mobile truck crane is flexibility and moving quickly; while the weakness is work must be outrigger, cannot load driving and at the same time cannot work on the a soft or muddy field. And this kind of mobile truck crane is widely used for Engineering Constructions, such as Roads, bridges, buildings, emergency services, etc. The general engineering team, the construction industry and the electric power installment department, all needs the automobile crane.
If you're interested in our mobile crane truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
Today, we will introduce dongfeng 4*2 LHD 12T mobile truck crane as below.
Total mass: 16000kgs
Overall dimension (L*W*H): 10230×2330×3330(mm)
Wheelbase: 4200mm
Engine model: YCS04180-68 yuchai 180hp
Main/auxiliary hoist: 10T/5T
More pictures of dongfeng 4*2 12T sink-style mobile crane truck as below.
Main technical parameters of Dongfeng 4*2 LHD 12T sink-style mobile crane truck manufactured by Chengli Special Automobile Co., Ltd. is as below.
| Main technical parameters of dongfeng sink-style mobile crane truck as below. |
| Total mass |
18000kg |
Total mass(kg) |
120000 |
| Engine model |
YCS04180-68 yuchai 180hp diesel engine |
Main/auxiliary hoist |
12T/12T |
| Displacement/ power (ml/kw) |
4156/132 |
Crane boom |
8m 5 sections veneer arm |
| Gearbox |
Fastgear |
Full crane boom length (m) |
33 |
| Overall dimension(L*W*H)(mm) |
10600*2350*3250 |
Big boom dimension(mm) |
580*460 |
| Wheelbase |
4200mm |
Back displacement top |
Standard |
| Tires pec |
1000R20 rail tires |
Slewing bearing |
external gear |
| Front/rear axle(kgs) |
6500/11500 |
Slewing mechanism |
360°Arbitrary rotation |
| Outrigger Longitudinal/transverse span(mm) |
6000/6800 |
Beam |
new torque-fighting van beam |
| Steering type |
Hydraulic steering |
Power pump |
Triple-pump |
| Braking |
Air cut braking |
Operation room |
Advanced operation room |
| Others: double Legs, Fully covered floor, double-sided operation, negative angle, electronic throttle |
| Chosen part: motor, computer, weighing apparatus, camera, rotating basket, air conditioning, level |
| Main technical parameters |
| Product name |
Dongfeng brand 4*2 LHD 12T sink-style mobile crane truck for sale |
| Total mass(Kg) |
18000 |
Overall dimension(L*W*H)(mm) |
10600×2400×3250 |
| Total mass(Kg) |
17805 |
Driver cab seated person |
3 |
| Approach/departure angle(°) |
23/9 |
Front/rear suspension(mm) |
2150/2670 |
| Axle nos. |
2 |
wheelbase(mm) |
4200 |
| Axle load(Kg) |
6500/11500 |
Max speed(Km/h) |
89 |
| Truck chassis |
| Truck chassis |
EQ5183GSZ6DJ |
manufacturer |
Dongfeng |
| Approach/departure angle(°) |
23/20 |
Tire specification |
10.00R20 18PR*6+1 |
| Steel spring |
8/10+8 |
Front tread(mm) |
1800 |
| Fuel type |
diesel |
Rear tread(mm) |
1700 |
| Emission standard |
Euro Ⅵ |
| Engine model |
Manufacturer |
displacement(ml) |
power(Kw) |
| YCS04180-68 |
Yuchai |
4156 |
132 |
