Factor sale good price Customized HOWO RHD street sweeping vehicle for sale, HOT SALE! road sweeper
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of road sweeper trucks in China. With many years’ development, we Chengli Special Automobile Co., Ltd. could offer ISUZU road sweeper truck, forland street sweeper truck, dongfeng brand road cleaning vehicle, JMC brand road sweeping vehicle, JAC brand street sweeper, FAW brand street sweeping vehicle, etc. More information, please feel free to contact with Ms. Anita.
the introduction function of road sweeper truck
1, CLW brand road sweeper truck adopts the mixing way of sucking-sweeping to collect wastes, wet-dust removal, electro-hydraulic control, finished the sweeping work by the working way of hydraulic tipping and discharging.
2, CLW brand road sweeper truck, adopts auxiliary engine specially drives the fan and hydraulic system, assuring keeping working during driving and Continuity of the sweeping process.
3, CLW brand street sweeper adopts the structure layout of “middle installed 4* sweeping brushes+ spraying and dust-removal device+ Center partition+ rear installed nozzle”, which makes non-splashing of sand and gravel during cleaning. This kind of sweeping layout is easy to adjust and maintain the sweeping and sucking devices. Perfect vehicle passivity in transit operations.
4, The transmission between the auxiliary engine and the fan is equipped with an automatic clutch, making sure automatic disconnection of the secondary engine from the fan when starting and stopping the engine without load, reducing the impact on the secondary engine, improving the reliability and service life of the auxiliary engine
5, Sweeping disk has the functions of automatic obstacle avoidance and automatic reset; obstacles automatically retract and automatically return to obstacles.
6, The rotating speed of the pan can be adjusted according to various cleaning conditions to ensure good cleaning effect under various pollution conditions.
7, CLW brand road sweeper adopts advanced, high-efficiency dedicated fans and fully floating nozzles that can be automatically leveled along the road providing good cleaning and long service life.
If you're interested in our road sweeper truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
The upper parts of SINO TRUK HOWO 4*2 LHD/RHD road sweeper truck as below.
Truck chassis: ZZ1107
Driving type: 4*2 LHDF/ RHD
Engine model: YN4102QBZL
Engine power: 85KW/116hp diesel engine
Overall dimension: 7930×2400×3000
Working width:2.6m
Inhalation granularity:φ120mm.
Water tank volume:2m³ carbon steel material
Dust tank volume:6m³ stainless steel material
Max working ability:13000㎡/h-52000㎡/h
the new standard devices of the high-class road sweeping vehicle manufactured by Chengli Special Automobile Co., Ltd. as below.
4sets * road sweeping brushes; Sweeping speed realizes independent 3-speed speed regulation, JIANGXI WUSHILING 87hp diesel auxiliary engine; DALI motor; Schneider control switches; Taiwan solenoid valve groups; Brand famous hydraulic pump and water pump ; Maintenance-free self-detaching clutch; Maintenance-free fan; stainless steel water tank + stainless steel dust tank; Tail LED arrow light； Manual pump emergency system；Brush arm rotation mechanism with high-tech wear-resistant engineering spacer; butter-free; Precision cold bending seamless hydraulic hose.
Main technical parameters of SINO TRUK HOWO 116hp diesel road sweeper truck as below
| Main technical parameters |
| Product name |
SINO TRUK HOWO 4*2 LHD/RHD Road sweeper truck |
| Total mass(kgs) |
11200 |
Driver cab seated person |
2-3 |
| Rated mass(kgs) |
3965 |
Overall dimension(L*W*H) |
7930×2400×3000 |
| Curb mass(kgs) |
7040 |
Cargo body dimension |
×× |
| Axle nos. |
2 |
Wheelbase(mm) |
3800 |
| Gearbox |
6 speed gearbox, manual |
Power steering |
Yes |
| Axle load(kgs) |
4000/7200 |
Max speed(km/h) |
90 |
| Main technical parameters |
| Truck chassis model |
Z1107 |
Manufacturer name |
SINO TRUK HOWO |
| Approach/departure angle |
18/16 |
Tire specification |
8.25R20*6 |
| Steel spring |
3/3+2, |
Front tread(mm) |
1776 |
| Fuel type |
Diesel |
Rear tread(mm) |
1595 |
| Emission standard |
Euro Ⅲ |
| Engine model |
Manufacturer |
Displacement(ml) |
Power(KW) |
| YN4102QBZL |
YUCHAI |
3760 |
85 |
