new designed 13.3m length refrigerated container semitrailer for sale, Factory sale best price big capacity 73.4cbm refrigerated van trailer for sale,
HOT SALE! CLW brand refrigerated van semitrailer for sale,
New manufactured refrigerated van semitrailer is with the model of CLW9401XLC. And the overall dimension(L*W*H) is 13500x2600x3995 (mm); while the dimension(L*W*H) of the refrigerated container semitrailer is 13300X2400X2300(mm). High quality new processed refrigerated van body is with interior and exterior of high quality glass fiber-reinforced plastic (FRP). And the middle layer is with high quality 100mm thickness PU FOAM material. One side door(left or right is ok). The floor base adopts high quality aluainum alloy air trunking. Equipped with high quality Chinamade or USA Brand CARRIER independent self-powered reefer unit(the lowest temperature is up to -15 ℃).
The driving part of this CLW brand refrigerated container semitrailer is as below.
1, 13TONS FUWA axles*3,
2, 12R22.5 tires*12,
3, 28T outriggers.
The refrigerator van adopts both exterior and interior with stainless steel sheets, and the middle is PU slices with vacuum negative pressure one-formed casting, and the thickness is 8mm, approved the related Ministry of Health of food grade requirements, etc. just like sandwich structure. The refrigerated van has the advantages of high strength; strong anti-corrosion and aging resistance, low heat-conducting property, non-pollution, non-easy destroy, etc. And the baseboard is aluminum alloy anti-skipping diamond board, which assuring the insulation ability and the compact resistance of the baseboard. There are aluminum alloy ventilation slots on the baseboard. The frame of standard rear double doors adopts the stainless steel structure frame with light mass and perfect corrosive resistance, etc. The door edgings frames are sealed with the imported high quality epdm rubber, making sure the van insulation stability. Door edgings, door locks and accessories use stainless steel materials.
If you're interested in our refrigerated container semitrailer, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
More pictures of CLW Brand 13.3m length refrigerated van trailer manufactured by Chengli Special Automobile Co., Ltd. is as below.
Customized refrigerated container semitrailer for Sudan
factory sale good price refrigerated van semitrailer for sale
Main technical parameters of CLW brand 13.3m refrigerated container semitrailer manufactured by Chengli Special Automobile Co., Ltd. is as below.
| Main technical parameters |
| Product name |
CLW9401XLC refrigerated container semitrailer for sale |
| Total mass(Kg) |
40000 |
Overall dimension(L*W*H)(mm) |
13500×2600×3995 |
| Rated mass(Kg) |
29600 |
Van dimension
(L*W*H)(mm)
|
13000×2400×2300 |
| Curb mass(Kg) |
10400 |
Wheelbase(mm) |
7350+1310+1310 |
| Approach/departure angle(°) |
-/12 |
Tire specification |
12R22.5 12PR*12 |
| Steel spring |
-/8/8/8 |
Tires nos. |
12 |
| Axle load(Kg) |
-/24000(triples axles) |
Axle nos. |
3 |
| Front tread(mm) |
- |
Rear tread(mm) |
1840/1840/1840 |
The technical advantages of CLW brand refrigerated van semitrailer manufactured by Chengli Special Automobile Co.,Ltd. is as below.
First, the tightness. The van box of chengli refrigerated truck asks for strict tightness, decreasing the heat-exchange with the outside, then to make sure the lower temperature of the freezer trucks.
Second, the cooling system. The equipped cooling system connected with the box van, and provides continuous supply of cooling, making sure the van temperature in a certain range.
Third, the portability. The goods refrigerated truck transported cannot store a long time. Though there is cooling system, it also need to delivery quickly.
Fourth, the heat-insulating. The refrigerated van is just like the container. But because of manufacturing with heat-insulating materials, the refrigerated truck decreasing heat-exchange.
