China supplier Dongfeng diesel engine P6 mobile LED advertising truck for sale, Factory sale good price colorful LED screen vehicle for sale,
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of Outdoor mobile LED advertising display truck, LED truck, digital advertising truck, LED screen truck, outdoor full color LED advertising truck, LED box truck, etc. With many years' experience in supplying, Chengli Special Automobile Co., Ltd. could design and produce ISUZU led truck, Dongfeng Outdoor mobile LED advertising display truck, forland digital advertising truck, Karry billboard advertising LED display truck, Chang'an LED display truck, JAC mobile advertising truck, HOWO scrolling advertising truck, trailer-type mobile outdoor LED truck, etc. More information, please feel free to contact with Ms. Anita Deng.
main technical advantages of customized 3 sides P5 LED billboard LED mounted on truck chassis as below.
1. Our LED display vehicles can be customizable. We provide LED display trucks, LED display trailer, LED display semi-trailer, etc.
2. One side waterproof P4/P5/P6/P8 full color led screen. The other side advertising light box with subtitle. The rear side monochrome screen to display text.
3. Optional1-side, 2-sides or 3 sides full-color led screens. Brightness can be adjusted automatically according to different surroundings.
4. Widely used for outdoor commercial advertising, stage rental, traffic advertising, mobile truck advertising, sports stadium advertising etc.
5. The pixel's pitch for the LED screen could be P6, P5, P4 etc.
6. The area of the left or right screen mainly ranges from 3.22 m3 to 12.2 m3.
The basic equipment includes silent generator, aluminum checkered plate wall, waterproof leather or wooden floors, safe and intelligent switch power distribution system, integrated electromechanical control, lighting, circulating ventilation fans, shockproof computers, and gigabit media control system, stereos, one amplifier, four waterproof column loud speakers, and other tiny accessory facilities within the body.
If you're interested in our mobile LED advertising truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
Truck model: CLW5040XXCE6
overall dimension(L*W*H): 5995*2100*3050(mm).
main technical parameters of Dongfeng 4*2 LHD diesel P6 LED advertising truck as below.
| Dongfeng 4*2 LHD mobile LED vehicle for sale(with two sides P6 LED screens) main parameters |
| Product name |
New dongfeng 4*2 LHD Mobile LED advertising truck |
| Overall dimension(L*W*H) |
5995x2100x3050(mm) |
Truck chassis model |
EQ1045SJ3CDF |
| Total mass(kgs) |
4495kgs |
curb mass(kgs) |
4365kg |
| Axle nos. |
2 |
Wheelbase(mm) |
3308mm |
| Front/rear suspension(mm) |
1032/1663 |
Front/rear tread(mm) |
1525/11498 |
| Rated person |
2 (driver included) |
Tyre specification |
7.00R16 |
| Max speed(km/h) |
110 |
Approach/departure angle |
19/16(°) |
| Axle load(kgs) |
1795/2695 |
Steel spring |
6/6+5 |
| Gearbox |
5 speed transmission, manual |
Power steering |
Yes |
| brake |
Air cut braking |
Driver cab |
Dongfeng 4*2 LHD single row driver cab |
| Engine model |
D20TCIFI |
Emission standard |
Euro 6 |
| Displacement(ml) |
1999 |
Rated power |
93KW/126hp |
| Fuel type |
Diesel |
| Truck mounted LED screen |
|
1
|
two sides(left and right sides) of the driver cab are with high quality HD waterproof and shake-proof full color outdoor P6 LED screens ( One side P6 screen area: 3840*1728=6.63㎡) |
| 2 |
The rear back face is also with single color word screen(screen area: 1280*1440=1.84㎡) |
| 3 |
Truck mounted silence diesel generator adopts high quality OUMA 15KW diesel generator unit. |
| 4 |
5cm composited steel box body frame, FRP material body, wooden floor, 4 sets of waterproof Audios, one set amplifier, intelligent Mechatronics controlling system, Circulating ventilation cooling system, safety intelligent Automatic switching system for inside and outside of the network, Gigabit flow Media control system, etc. |
| Remark: the computer is with English words, English operation system and Software playback system |
