Customized SINO TRUK HOWO 4*2 RHD 16M telescopic aerial platform truck for sale, 16m truck mounted aerial platform

Customized SINO TRUK HOWO 4*2 RHD 16M telescopic aerial working platform truck for sale, 16m working height truck mounted aerial working platform

One unit of customized SINO TRUK HOWO 4*2 RHD 16M working height telescopic aerial workiong platform truck for overseas client.,

Customized SINO TRUK HOWO 4*2 RHD 16M telescopic aerial working platform truck for sale, adopts SINO TRUK HOWO 1880mm4*2 RHD single row driver cab, 3360mm wheelbase, YN4102QBZL 116hp diesel engine, 2.4T front axle/4.2T rear axle, WLY646 6 speed gearbox, 7.00R16 rail tires,

The devices of the HOWO brand telescopic aerial working platform truck adopts 3 sections quadrilateral telescopic crane boom, the max working range is 9.1m, the max working height is 16m; the working range is 4.4m at the max working height, 360°full rotation; front V type outriggers and rear H type outriggers, Horizontal span of the outrigger is 3605mm, 3670mm;the Longitudinal span of the outriggers is 4000mm, 3810mm.the rated loading capacity of the high altitude bucket ≤200㎏; while the dimension of the bucket is 1100X650X1150 (mm). Static leveling, with the function of Oil Tank locking, Manual and remote control, With emergency power unit.

Production of HOWO telescopic type truck mounted aerial working platform is as below.
1. The SINO TRUK HOWO 16-meter high-altitude operating vehicle adopts a telescopic working arm structure. The operating arm is a 3 section telescopic type. The turntable can be operated or remotely operated. It can rotate 360 ​​degrees, four hydraulic outriggers, and the maximum load-bearing bucket. 200 kg, stainless steel hoarding, pattern anti-skid walking platform.
2. The working bucket adopts mechanical self-balancing design, its function is that the working bucket is always in a balanced state when working. The maximum extension angle of the forearm is up to 80° in order to adjust to the best working position.
3. Night work lights, operation lights can be installed on the operating table according to the customer's operating environment, making night work safer.
4. Computer control, automatic limit, dangerous work alarm, excellent safety performance. There is a display when getting off the car, which can display the working conditions of the whole car in real time.
5. The hexagonal working arm increases the strength, synchronously expands and contracts, the structure is compact, the working efficiency is high, and the working range is large. The telescopic oil cylinder is installed externally, and the chain telescopic mechanism is easier to observe the fault point and convenient for maintenance.
6. The outrigger adopts the front V and rear H-shaped structure, which has a larger bearing surface and higher stability; it can prevent the car beam from being deformed or broken. The outriggers are individually adjustable, and each outrigger can be adjusted separately according to the working ground environment. Even if the ground is uneven, the whole vehicle can be adjusted to a stable state. All outriggers are equipped with outrigger flashing lights for supporting during operation. The legs are profiled and a light alarm signal is issued.
7. The four vertical outrigger cylinders and the upper arm, lower arm, and forearm cylinders are all equipped with two-way hydraulic locks. The function is to lock the cylinders in place after reaching the required position to prevent accidents. The working arm is equipped with a two-way balance valve to make the working arm run more smoothly.
8. The main components of the vehicle including two-way hydraulic lock, two-way lock balance valve, hydraulic flow valve, hydraulic cylinder, engine start-stop emergency pump, operating system and control computer are all domestic well-known brands, and the core components are imported. Stable commutation, flexible and convenient operation; outriggers and working arms are interlocked, safe and reliable, to prevent mis-operation.

If you're interested in our aerial working platform truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: 0086 13329899995

Website: www.trucksinchina.com

More picutres of HOWO RHD 16m telescopic aerial working platform mounted on truck is as below.

HOT SALE! SINO TRUK HOWO 4*2 RHD 16m truck mounted aerial working platform truck for sale

good price 16m telescopic aerial working platform truck for sale

Customized SINO TRUK HOWO 4*2 RHD 16m telescopic high altitude operation truck for sale

main technical parameters of SINO TRUK HOWO RHD 16m working height telescopic truck mounted aerial working platform truck is as below.
