HOT SALE! JMC brand 4*2 LHD 14m telescopic truck mounted aerial working platform, Good price overhead working platform truck for sale,
Aerial work platform truck, also called high altitude operation truck, is specially designed and produced for aerial work or operation, such as repairing road lights, maintain high buildings, windows, hanging ad boards, power grid maintenance, etc.
Chengli Special Automobile Co., Ltd. is the leading mnaufacturer and supplier of aerial working platform trucks in China since 2004s. We can design and produce 12m overhead working truck, 14m-16m aerial working platform truck, 18m-20m high altitude operation truck, 20m-22m aerial working truck, etc.More information, please feel free to contact with Ms. Anita Deng.
The technical advantages of CLW brand aerial platform vehicle manufactured by Chengli Special Automobile Co., Ltd. as below.
1. Aerial platform vehicles is also named high-altitude operation truck, refers to the special vehicles for aerial operation with the delivery of staff and the equipment to the scene.
2. We are professional factory, supply Dongfeng aerial vehicles, JMC aerial working vehicles, JAC aerial platform vehicles, Qingling high-altitude working truck, Foton aerial platform operating vehicles, etc., working height of 8-24 meters for choose.
3. Produced by the high-altitude operation vehicles, using double lift hydraulic cylinder, up and down a total of four hydraulic cylinders, the conventional aerial vehicles only two lifting cylinders, double lift hydraulic cylinder in the lift, rotation process does not tremble, do not shake, stability Sex, safety is better.
4. High-altitude operation vehicles using domestic or imported reversing valve and hydraulic cylinder, for the balance, flexible and convenient operation, outrigger and work arm interlocking, outrigger and work arm interlock to prevent misuse over.
5. Installed four hydraulic legs, to ensure vehicle stability and safety in operation.
6. Optional aerial crane hook, hook hanging 1 ton and the electronic control system.
7. Aerial platform vehicles can be up and down operation, 360-degree rotation, install the hand throttle.
8. If you have any special requirements for the aerial vehicles, please let us know, we can design for you.
If you're interested in our truck mounted aerial working platform, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: 0086 13329899995
Website: www.trucksinchina.com
More pictures of JMC brand 14m truck mounted aerial working plaform is as below.
High quality and best price 14m working height telescopic aerial working platform truck for sale
HOT SALE! JMC brand 14m telescopic aerial working platform truck
Main technical parameters of 14m telescopic aerial working platform truck manufactured by Chengli Special Automobile Co., Ltd. as below.
| Item |
Name |
Specification /model |
| 1 |
Truck name |
CLW brand telescopic aerial working platform truck for sale |
| 2 |
Truck model |
CLW5046JGKJ6 |
| 3 |
Truck chassis |
JX1041TG26 JIANGLING |
| 4 |
Working height |
14m |
| 5 |
Main technical parameters |
Flatform ground height≥12.3m
Flatform max working range: Open-ended
Flatform working height at the max working range: Open-ended
Platform max working range at the max working height: Open-ended
Plafrom max working Angle of Tilt: 80°
Rated mass of the working bucket: 200kg
|
| Outriggers |
Type: Front V + rear H type, Individually control
Outriggers nos. : 4
Control: Individually control or Linkage control
Transverse Span of front outriggers: 4170mm
gradient:120°
Transverse Span of rear outriggers: 3930mm
|
| Main operation |
Operation positio: revolving stage,Teleoperation.
Control type:ZYK Bus control system,electro-hydraulic proportional control system, realize stepless speed regulation
|
| 6 |
Coaming and platform |
Stainless steel fence and Non-slip platform |
| 7 |
Boom construction mode |
Three-section six-sided working arm,Synchronous scaling |
| 8 |
Rotator device |
Two-way 360° continuous rotation, 360° hanging basket |
| 9 |
Engine model |
JX4D30B6H 85KW/116hp diesel engine
JX4D30A6H/129hp diesel engine
|
| 10 |
Overall dimension(L*W*H) |
5998×2000×2900 |
| 11 |
Total mass |
4495kg |
| 12 |
Curb mass |
4365kg |
| 13 |
wheelbase |
3360mm |
JMC brand 4*2 LHD diesel telescopic aerial working platform truck, adopts JMC single row driver cab, JX1041TG26 model, JX4D30B6H 85KW/115hp diesel engine, 3360mm wheelbase, 7.00R16 rail tires, 5 speed gearbox, power steering, oil cut braking, air conditioner, etc.
The upper part of JMC brand telescopic hydraulic bucket truck as below.
The working height is 14 meters, the color of the upper part is engineering yellow according to the announcement, with four hydraulic telescopic legs (up and down extension and horizontal extension), a total of 12 oil cylinders, the legs are front V and rear H type, emergency pump, bucket belt 360 degrees Rotation, wireless remote control, and others are prepared according to factory standards.
