Customized good price dongfeng double cabs 14m truck mounted aerial working platform for sale, Factory sale 14m working height hydraulic bucket mounted on truck
Dongfeng 4*2 double cabs LHD 14-meter high-altitude operating vehicle adopts a folding crank arm structure, the operating arm is three-section folding, the working bucket and the turntable have double working positions, up and down operation, electro-hydraulic control, 360-degree rotation, four hydraulic outriggers, inside the working bucket It can control the start and stop of the engine, the boom has a hoisting hook system, the hook lifting weight is ≤900kg, the manned working bucket is 200kg, the steel tool box and the pattern anti-skid platform, and the stainless steel fence.
The chassis hydraulic outrigger balance system is equipped with a two-way hydraulic lock as standard, the working arm cylinder is equipped with a two-way balance valve as standard, and the working arm balance structure is an external balance lever.
The main components of Chengli aerial vehicle hydraulic cylinders, hydraulic tubing, hydraulic locks, balance valves, gear pumps, power take-offs, multi-way valves, etc., all adopt well-known domestic brands. The hydraulic system of the vehicle has stable reversing and flexible and convenient operation; The working arms are interlocked, safe and reliable, to prevent misoperation; H-shaped outriggers have a large span and good stability.
The outriggers can be independently retractable and linked. The rear outriggers are equipped with outriggers and flashing lights for operation. When the outrigger is profiled, it sends out a light alarm signal.
main technical parameters of Dongfeng 4*2 LHD double cabs 14m working height truck mounted aerial working platform truck manufactured by Chengli Special Automobile Co., Ltd. is as below.
| Item |
Name |
model/specification |
| 1 |
Truck brand |
CLW brand truck mounted aerial working platform for sale |
| 2 |
Truck model |
CLW5060JGKD6 |
| 3 |
Truck chassis model |
EQ1075DJ3CDF |
| 4 |
Overall dimension(L*W*H)(mm) |
7400×2000×3100 |
| 5 |
Total mass(kgs) |
5520 |
| 6 |
Curb mass(kgs) |
5195 |
| 7 |
Wheelbase(mm) |
3308 |
| 8 |
Engine model |
H20-120E60 / 90kw 122hp |
| 9 |
Working parameters |
Max working height: 14m( person height:1.7m included)
The distance between ground and working platform: 12.3m
Max working range of the working platform≥6.46m
Working range at the working platform max working≥2.05m
Working height at the working platform max working range≥8.6m
Max loading capacity of the working bucket: 200kgs
|
| Working bucket |
Max loading capacity of the working bucket: 200kgs
Working bucket dimension(L*W*H): 1200*600*1100mm
|
| Outriggers |
type:H type outriggers
Nos.:4
Operating way:Independently adjustable and can also be linked
Horizontal span:2680mm
Longitudinal span:3000mm
|
| hook |
Safety value mass≤900kg
Max lifting height: 7.2m
|
| Operation system |
Operation position: turntable, double working position operation of hanging bar-two operation systems
Operation mode: electronic control operation
|
| Hoarding and platform board |
Steel toolbox and hoarding, Pattern non-slip walking board, |
| Boom structure mode |
3 sections folded boom |
| Boom material |
Q345B Steel alloy structural steel |
| Balance device |
External balance rod |
| Slewing device |
Two-way 360° continuous rotation |
| Safety device |
The outrigger cylinder is equipped with a hydraulic lock, and the working arm cylinder is equipped with a two-way balance valve. |
If you're interested in our truck mounted on aerial working platform truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: 0086 13329899995
Website: www.trucksinchina.com
More pictures of Dongfeng 4*2 LHD double cabs 14m aerial working platform truck manufactured by Chengli Special Automobile Co., Ltd. as below.
HOT SALE! Dongfeng 14m working height working platform truck for sale
HOT SALE!Good price Dongfeng double cabs 14m folded truck mounted overhead working platform for sale
The technical advantages of CLW brand truck mounted aerial working platform truck is as below.
1. The working bucket adopts mechanical self-balancing design, and its function is that the working bucket is always in a balanced state when working.
2. The rear outriggers of the vehicle are equipped with warning outline lights to improve the safety of warnings during vehicle operation.
3. The upper and lower operating systems can complete various operations on the working bucket and on the turntable.
4. The working bucket is equipped with night operation lights to make night operation safer.
5. The outriggers are individually adjustable. Each outrigger can be adjusted separately according to the working ground environment. Even if the ground is uneven, the whole vehicle can be adjusted to a stable state.
6. The outrigger adopts front and rear H-shaped structure, which has larger bearing surface and higher stability.
7. The hydraulic system is equipped with a hydraulic locking system, whose function is to lock the cylinder in place after reaching the required position to prevent accidents.
