The max working height of ISUZU double cabs folded truck mounted aerial working platform is 18m( person height of 1.7m included). 3 sections folded boom, The working bucket and the turntable are operated by dual working positions, electro-hydraulic control, with remote flameout. The working arm rotates 360 degrees, four hydraulic outriggers, with hooks, a safe lifting weight of 900kg, a working bucket with a load limit of 200kg, and a lighting lamp inside the bucket. Steel toolbox, pattern anti-skid walking table, stainless steel fence.
The chassis hydraulic outrigger balance system is equipped with a two-way hydraulic lock as standard, the working arm cylinder is equipped with a two-way balance valve as standard, and the working arm balance structure is an external balance lever.
The main components of Chengli aerial vehicle hydraulic cylinders, hydraulic tubing, hydraulic locks, balance valves, gear pumps, power take-offs, multi-way valves, etc., all adopt well-known domestic brands. The hydraulic system of the vehicle has stable reversing and flexible and convenient operation; The working arms are interlocked, safe and reliable, to prevent misoperation; H-shaped outriggers have a large span and good stability. The outriggers can be independently retractable and linked. The rear outriggers are equipped with outriggers and flashing lights for operation. When the outrigger is profiled, it sends out a light alarm signal.
1. The working bucket adopts mechanical self-balancing design, and its function is that the working bucket is always in a balanced state when working.
2. The rear outriggers of the vehicle are equipped with warning outline lights to improve the safety of warnings during vehicle operation.
3. The upper and lower operating systems can complete various operations on the working bucket and on the turntable.
4. The working bucket is equipped with night operation lights to make night operation safer.
5. The outriggers are individually adjustable. Each outrigger can be adjusted separately according to the working ground environment. Even if the ground is uneven, the whole vehicle can be adjusted to a stable state.
6. The outrigger adopts front and rear H-shaped structure, which has larger bearing surface and higher stability.
7. The hydraulic system is equipped with a hydraulic locking system, whose function is to lock the cylinder in place after reaching the required position to prevent accidents.
If you're interested in our ISUZU 4*2 double cabs 18m aerial working platform truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: 0086 13329899995
Website: www.trucksinchina.com
More pictures of ISUZU brand double cabs 18m truck mounted aerial working platform is as below.
HOT SALE! ISUZU 18m truck mounted aerial working platform
Main technical parameters of ISUZU 18m truck mounted aerial working platform truck is as below.
| 1 |
CLW5072JGK6HX truck mounted aerial working platform truck for sale(18m) |
|
2
|
Driver cab |
Flathead double-cab, 2+3 seats in the driver cab |
| Truck chassis model |
QL1070BUKWY |
| Engine |
Model |
Power (KW/hp) |
| 4KH1CN6LB |
88/120 |
| Overall dimension(L*W*H) (mm) |
8600×2000×3200 |
| Total mass(kg) |
6625 |
Curb mass(kg) |
6300 |
| wheelbase(mm) |
3815 |
Front/rear suspension(mm) |
1015/2470,1015/2450 |
| 3 |
Max working height(m) |
18.5m |
| Working range at the max working height(m) |
2.3m |
| Max working range(m) |
8.2m |
| Working height at the max working range(m) |
10.1m |
| Outriggers type |
H |
| Outriggers Longitudinal span(mm) |
3650mm |
| Outriggers Horizontal span (mm) |
3550mm |
| Max lifting height(hook center)(m) |
8.4m |
| Max lifting mass(kg) |
1000kg |
| Working bucket dimension(L*W*H)(mm) |
1200mm×610mm×1100mm |
| |
|
|
|
|
|
