The foam tank fire truck is also called fire rescue truck, fire truck for sale, fire fighting truck,
fire engine,fire pumper, etc. As a professional fire truck manufacturer in China, the fire truck for sale are water tanker fire truck, foam fire truck, emergency rescue fire truck,etc.
The fire engine truck is mainly refitted on Dongfeng, HOWO,HINO and other chassis.It is max.
keeping the original capability of chassis, and have the advantage of the advanced technology, reliable capability, easily operate and so on. The fire truck is the perfect fire fighting equipment for special fire team.
The fire truck is consisted of truck chassis, water tank, fire pump, fire monitor, pipeline system,
sandwich power take off, storage compartment, electric system,etc.
Main feature of fire engine supplied by chengli fire truck factory
1.The special part of fire fighting truck include Liquid tanker, pump compartment, equipment compartment, pipe system, electrical system and so on.
2.The fire truck is double integral structure, broad view, 5 to 6 passengers, the fire fighting truck
can be put the fire during driving, long range, fire fighting force.
3.The tank inner is with anti-wave plate and tank top is anti-skid checkered plate. Also, the
manhole is with fast lock setup and open device.
4.optional: normal fire pressure pump, middle-low pressure fire pump, high-low pressure fire
pump.
5.The compartment using high-quality steel, high strength aluminum alloy profiles, inner and
outside using corrugated aluminum, multi-channel inside of tanker body.
6.Perfect electrical equipment:cab top alarm lamp, courtesy lamp, both sides flashing light, 100wsiren, vacuum gage, pressure gage, content gage, etc.
More pictures of water tanker firefighting truck, please send email to truck0011@163.com or talk to Anita by Whatsapp: 0086 13329899995.
Website: www.trucksinchina.com
More pictures of Dongfeng water tanker firefighting truck is as below.
HOT SALE!Dongfeng water tanker firefighting vehicle for sale
Technical Parameters of dongfeng fire fighting sprinkler truck 5 ton
| Items |
Descriptions |
Specifications and Types |
| General |
Truck Name |
Water truck |
| Drive Type |
4*2 |
| Curb Weight (kg) |
5000 |
| Overall Dimensions L*W*H(mm) |
7100×2100×2800 |
| Engine |
Engine Brand |
YuChai |
| Fuel Type |
Diesel |
| Power |
120HP |
| Emission Standard |
Euro III |
| Displacement(ml) |
3760 |
| Engine Type |
4 cylinders in line, water cooling, turbo-charged diesel engine, inter-cooling |
| Chassis |
Chassis Brand |
Dongfeng |
| Tire No. |
6+1 |
| Tire Specification |
7.50R16 steel tire |
| Wheelbase (mm) |
3300 |
| Axle No. |
2 |
| Steering Wheel |
Left hand drive with power-assisted |
| Gear Box |
6 speed forward with 1 reverse, manual |
| Brake |
Air brake |
| Front/rear suspension(mm) |
1430/2270 |
| Tank |
Tank Volume(L) |
5000 |
| Tank Shape |
Elliptical |
| Tank Material |
Carbon Steel Q235 |
| Fire Pump |
Fire pump model |
CB10/30 |
| Flow |
30L/S |
| Fire Monitor |
Fire monitor model |
SP30 |
| Range |
More than 55m |
| Others |
Basic equipment: front rushing sprinkler, side spraying sprinkler, rear sprinkling sprinkler, water cannon, fire fighting pump, manhole, ladder, etc. |
