Factory sale Good price SHACMAN 10T telescopic crane boom mounted on cargo truck for sale, HOT SALE! 10T cargo truck with crane boom for sale
The specification of SHACMAN brand 6*4 LHD 10tons telescopic crane boom mounted on truck as below
| Product name |
SHACMAN brand 8*4 LHD 14tons telescopic crane boom mounted on cargo truck for sale |
| Chassis type |
SX1255 |
| Parameters |
Overall dimension length/width/height (mm) |
11750×2500×3720,3500 |
| Cargo body dimension (L*W*H)(mm) |
8200,8000×2300,2450×800,600 |
| GVW(kg) |
25000 (Kg) |
| curb Mass(kg) |
13000(Kg) |
| Rated mass(kg) |
11870 (Kg) |
| Approach angle/ Departure angle(mm) |
16/11(°) |
| Front suspension/rear suspension(mm) |
1525/3250 |
| Fuel Type |
diesel |
| Max Speed |
90 |
| Engine |
Type |
WP10.340E22 |
| Displacement/Power(kw) |
9726ml/250KW/340hp |
| Manufacturer |
WEICHAI |
| Chassis |
Drive Type |
6*4 |
| Wheelbase(mm) |
5775+1400mm |
| Tread(front/rear) |
2036, 1860/1860 (mm) |
| Transmission |
RTD-11509C 9 speed manual gearbox |
| Cab |
SHACMAN H3000 luxurious driver cab |
| Number of spring axle(front/rear) |
4/4 |
| Tire Type |
12.00R20 |
| Upper part(cargo van and crane boom) main parameters |
| Upper body |
Cargo body dimension |
8200,8000x2300, 2450x600 |
| Material |
Carbon steel |
| Painting |
Upon request |
| Crane boom main parameters |
| Crane boom |
Choose to install XCMG brand 10T 4 sections telescopic crane boom |
| Lifting height |
14m |
| Working radius |
12.3m |
| Crane boom |
Full hydraulic, full rotation, aerial working seat, auto- retract hook hanger, |
| The color of the whole truck is upon request. |
HOT SALE! Customized SHACMAN brand 6*4 LHD/RHD H3000 12T telescopic crane boom mounted on cargo truck for sale, adopts SHACMAN brand 6*4 LHD H3000 one row and a half driver cab, 5775+1400mm wheelbase, WP10.340E22 weichai 340hp Euro 2 diesel engine, RTD-11509C 9 speed manual gearbox, MAN 7.5T front axle/MAN 16T dual-grade double rear axles, 400L aluminum alloy material oil tanker, 12.00R20 rail tires, etc.
The overlal dimension(L*W*H) of SHACMAN Brand 6*4 heavy duty 12T telescopic cargo truck with crane boom is 11750×2500×3720,3500(mm); cargo body dimension(L*W*H) of SHACMAN 12T cargo truck with crane boom is 8200×2300×800(mm). The telescopic crane boom choose to install High quality China-famouse XCMG brand 12T telescopic crane boom.
The volume of the cargo box body is 15cbm.
If you're interested in our truck with crane, please send email to truck0011@163.com or talk to Anita by Whatsapp: 0086 13329899995.
Website: www.trucksinchina.com
More pictures of SHACMAN brand 6*4 LHD 10T cargo truck with telescopic crane boom manufactured by Chengli Special Automobile Co., Ltd. is as below.
HOT SALE! shacman 10T Mobile cargo truck with crane
High quality and best price SHACMAN 10T cargo truck with crane for sale
The cargo crane is also called truck mounted crane, crane truck, truck with crane, etc. The truck with crane is mainly used to lift and transport the constuction material, equipment or other large goods by municipal corporation, mining engineering department, plant department,etc
As a professional cargo truck crane supplier in China, we Chengli Special Automobile Co., Ltd. manufacture the crane boom is from 2 ton to 160 ton. The drive type of our truck crane for sale are 4x2, 6x2, 6x4,8x4,etc. The truck mounted crane for sale are telescopic boom truck mounted crane, knuckle boom truck mounted crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc. The crane for truck can be crane, chengli crane, sany crane, unic crane, kanglim crane, etc.
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of truck mounted crane in China. With many years'experience in supplying, Chengli Special Automobile Co., Ltd. can supply Dongfeng truck mounted crane, Foton crane truck, HOWO truck with crane, ISUZU cargo truck with crane, FAW truck with crane, etc. More information, please feel free to contact with us. The hot sale line is 0086 13329899995.
