Good price ISUZU brand FTR 4*2 LHD 205hp diesel 5T cargo truck with knuckle crane for sale,
The cargo crane is also called truck mounted crane, crane truck, truck with crane, etc. The truck with crane is mainly used to lift and transport the constuction material, equipment or other large goods by municipal corporation, mining engineering department, plant department,etc.
Crane Features is as below.
- Single cylinder synchronization guy cable technology makes work efficiency much higher than before.
- Advanced development means make sure that the design is very reliable.
- The more symmetrical center design of pentagon & hexagon boom make it has bigger anti-bending capacity.
- Compact hinge point design take up smaller space
- The work is more safety after fitted over-winds alarm equipment.
- The integer lifting winch improved the work efficiency greatly and prolonged work lift of hydraulic system.
- Float three-point bridge structure design can lower the accessional stress on the chassis when traveling.
- Self-designed & developed slewing machine with greater drive force can meet varied requirements of working situation.
- Anti-slewing impulse equipment that make vehicle running safely
- All Structural made of High Strength Steel
- Optional Crane type: Telescopic boom crane or knuckled boom crane
- Radio Remote Control Available as an Optional Fitment
- Top Seat Control are optional (where the Operator Seat is attached to the Main Boom)
If you're interested in our cargo truck with crane, please send email to truck0011@163.com or talk to Anita by Whatsapp: 0086 13329899995.
Website: www.trucksinchina.com
ISUZU brand FTR 5T cargo truck with crane for sale,
Customized ISUZU brand FTR 5T cargo truck with crane, adopts ISUZU FTR luxurious one row and a half driver cab with air conditioner+ power steering+ electric windows+ central locks, 5800mm wheelbase, ISUZU MLD 6 speed manual gearbox, 4HK1-TC50 ISUZU 205hp Euro Ⅴ diesel engine, 6.3T front axle/13T rear axle, 10.00R20 rail tires, air cut braking, ABS, etc.
The overall dimension(L*W*H) of ISUZU Brand FTR truck with crane is 9000×2500×3470(mm); while the cargo body box dimension(L*W*H) is 5550×2300×600(mm). Clients choose to install CLW Brand 5tons/6.3tons telescopic/knuckle crane boom.
Today, we will introduce customized ISUZU brand FTR 4*2 LHD 205HP 5T cargo truck with crane is as below.
HOT SALE! ISUZU brand 5T cargo truck with crane
The specification of ISUZU brand 5tons telescopic crane boom mounted on truck manufactured by Chengli Special Automobile Co., Ltd. as below.
| Product name |
ISUZU Brand 4*2 LHD 5tons telescopic crane boom mounted on truck for sale |
| Chassis type |
QL5160 |
| Parameters |
Overall dimension length/width/height (mm) |
9000×2500×3470 |
| Cargo body dimension (L*W*H)(mm) |
5550×2300×600 |
| GVW(kg) |
16000 (Kg) |
| Kerb Mass(kg) |
10550(Kg) |
| Rated mass(kg) |
5255(Kg) |
| Approach angle/ Departure angle(mm) |
26/10 (°) |
| Front suspension/rear suspension(mm) |
1335/1865 |
| Fuel Type |
diesel |
| Max Speed |
90 |
| Engine |
Type |
4HK1-TC50 |
| Displacement/Power(kw) |
5193ml/151KW/205hp |
| Manufacturer |
ISUZU |
| Chassis |
Drive Type |
4×2 |
| Wheelbase(mm) |
5800 |
| Tread(front/rear) |
1960/1855 (mm) |
| Transmission |
ISUZU MLD 6 speed gearbox, manual |
| Braking system |
Air braking |
| Cab |
Isuzu FTR one row and a half luxurious driver cab |
| Number of spring axle(front/rear) |
9/7+7 |
| Tire Type |
10.00R20 |
| Upper part(cargo van and crane boom) main parameters |
| Upper body |
Cargo body dimension |
5550×2300×600 |
| Material |
Carbon steel |
| Side sheet thickness |
2mm thickness |
| Bottom sheet thickness |
2mm thickness |
| Painting |
Upon request |
| Crane boom main parameters |
| Crane boom |
Choose to install CLW brand/XCMG 5Ttelescopic/knuckle crane boom |
| The color of the whole truck is upon request. |
