high quality best price China supplier dongfeng water tank for sale, factory sale best price dongfeng portable cistern truck
Chengli Special Automobile Co., Ltd. is one of the famous manufacturers of water trucks and cistern trucks in China since 2004s. With many years’ experience of manufacturing in special vehicles, Chengli Automobile Co., Ltd. could offer 3cbm to 5cbm water truck with spray system, 700 gallon to 1000 gallon water delivery truck, 2000 gallon to 4000 gallon dongfeng cistern truck, 5000 gallon to 9000 gallon water tank, water tanker truck.
dongfeng tianlong double rear bridge 4000 gallon cistern truck
As the leading manufacturer of water trucks and tank trucks in China of many years, Chengli Automobile Co., Ltd will tell you how something of the water truck, such as the features and applications of water truck, how to maintain water truck, etc.?
Features of water truck
1. the water tanker is equipped with front sprinklers, rear sprinklers and side sprinklers. So it can spray water in every direction.
2. the water cannon is installed in rear working platform. When it shoots straight stream, its effective range is above than 28m. when it shoots mist flow, it effective range is above 15m.
3. it has function of water carrying and water draining, and also can eb used as fire pumper.
water sprinkling truck for pesticide
If you're interested in our water sprinkling truck, please feel free to send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995
Website: www.trucksinchina.com.
Application
The water truck is widely usded to spray water pavements, trees, green belts, lawns, guardrails high-rises, and more. It can be used to spray agricultural chemicals.
dongfeng long head 1000 gallon water truck
How to maintain water truck?
a. According to the coating requirements, before using, the water truck should be filled with water and let it been for 5 days, then bleeded. After that water wash the coating surface, then washing again, filled with water for 2 days, let out the water, now it could take in water.
b. We should regularly check the waterway system connectors, switch, and the sealing of the sucking rubber pipes, such as when leaking, we need to replace the seal elements.
c. We should regularly check the stability of the tanker, pump frame, stand. All nuts should be tightened to make sure the connectors securely.
d. We should regularly check the connecting of PTO and water pump, it should connecting stably, normal operating. If find the PTO and water pump leak oil, seal elements should be replaced.
e. Because there is no anti-freezing devices of the water tanker truck, so when it using below 0℃ in cold area, the backwater of the water pump, water tanker and waterway system should be drained off. And please switch the water pump and nut draining, making sure they are sealed, otherwise influence the pump sucking water.
f. The painting of the water truck should not spot diesel and gasoline, otherwise it fastening the painting damage. regularly check the tanker paint’s quality, when it damaged, painting again, avoiding the tanker rust.
g. The using and maintains of the truck chassis and engine part, please see the cargo truck using instruction book.
h. The medium through the ball valve shouldn’t be too dirty, otherwise it will hurt the seal ring, shorten the lifetime of ball valve. Every ball valve couldn’t work at half-open state, then the seal ring will be easily deformed.
i. Regularly take apart the pump filter network., avoiding residues block the filter network., affecting the quality.
j. When the water tanker filed with water, we must tighten the U shape bolt regularly, especially the new water truck.
More pictures of hot sale dongfeng cistern truck as below.
Main technical parameters of hot sale dongfeng brand water cistern truck as below
| Main parameters |
| Dongfeng 4*4 water truck for sale |
| Total mass(Kg) |
16000 |
Tank volume(m3) |
8.3 |
| Rated mass(Kg) |
7905 |
Overall dimension(L*W*H)(mm) |
8500×2470×3040 |
| Curb mass(Kg) |
7900 |
Front/rear suspension(mm) |
1250/2750 |
| Seated person |
3 |
wheelbase(mm) |
4500,4700 |
| Approach/departure angle(°) |
25/23 |
Max speed(Km/h) |
88 |
| Axle nos. |
2 |
Axle load(Kg) |
6000/10000 |
| Remark |
The transported medium: water, density: 1000kgs/cbm
Tank volume: 8300L |
| Chassis main parameters |
| Chassis model |
EQ5162GLJ |
Company |
Dongfeng company |
| Overall dimension(mm) |
8200×2470×2850 |
Tyre nos. |
6 |
| approach/departure angle(°) |
25/28 |
Tyre specification |
9.00R20,10.00R20 |
| Steel spring |
9/11+8 |
Front tread(mm) |
1900,1940 |
| Fuel type |
Diesel |
Rear tread(mm) |
1800,1860 |
| Emission standard |
Euro 3 |
| Engine model |
Manufacturer |
Displacement (ml) |
Power (Kw) |
| B190 33 |
Cummins |
5900 |
140 |
| Superstructure Parameter and main performance |
Tank volume(L) |
8300L |
| Tank material |
4 mm good quality carbon steel ,Square round shape |
Tank material |
| Water pump |
High quality water pump, suction lift>6m |
Water pump |
| Standard configuration |
fire interface, gravity valve, and filter gauze, front(rear, side)sprinkler, Rear working platform with water cannon,two 3m long water pipe |
Standard configuration |
| Main performance |
sprinkling width>14m, water cannon range>28m |
Main performance |
| Main function |
Watering, carrying water, drought, emergency fire fighting |
Main function |
| Optional |
Operation in the cab, long warning light on the top of the cab, LED arrow lights on the rear of the tank, CD |
Optional |
