hot sale best price dongfeng pick-up swill collector truck, high quality dongfeng 4*2 LHD/RHD kitchen wastes food truck for sale
The technical advantages of the waste food garbage truck
a. good looking, the truck cross section just looks like circular cylinder frame, the longitudinal cross-section looks like trapezoidal frame, the tow sides and the top are circular. The whole truck looks like acute and graceful.
b. the waste bins sealed well with the rear door assembly, adopting special strength rubber sealed, good sealing, avoiding the second pollution.
c. high reliability and safety, using electro-hydraulic control, and also having safety protection switch, making sure working accurately and reliably.
d. The engine output realizes fully automatically, when non-work, the engine in idle mode; when working, the engine speed up automatically.
If you're interested in our truck, please feel free to send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
main technical parameterd of hot sale dongfeng 4.2m3 kitchen garbage truck as below
| Dongfeng 4.2cbm kitchen garbage truck for sales |
| Total mass(kg) |
7300 |
Tanker volume(cbm) |
4.2 |
| Rated mass(kg) |
3265,3200 |
Overall dimension |
5995X2000X2900 |
| Curb mass(kg) |
3905 |
Wheelbase(mm) |
3300 |
| Driver cab person |
2,3 |
Front/rear suspension(mm) |
1032/1663 |
| Approach/departure angle |
19/13 |
Max speed(km/h) |
95 |
| Axle nos. |
2 |
Axle load(kg) |
2920/4380 |
| Remark |
The tanker volume: 4.2cbm, adopting Wugang high quality steel, round tanker, the discharging door and the rear door are hydraulic sealed. The effective volume can reach 90 percent.
The loading of the waste food garbage truck is done by lifting system of the side hydraulic waste bins, using the common sizes 120L/240L square shape waste bins. The lifting system can locking the waste bins, loading and discharging safely and reliably. The waste bins join the waste slot tog well, assuring non-overflow, non-missing.
Hydraulic system is made up of pump, hydraulic valve, sequence valve, and multi-purpose hydraulic cylinders, high-low pressure pipeline, etc. The key parts can choose the original imported ones, assuring the truck working safely and reliably. |
| Chassis main parameters |
| Chassis model |
DFA1070SJ35D6 |
Manufacturer |
Dongfeng |
| Approach/departure angle |
19/13 |
Tyre |
6 nos. ×7.00-16 14PR, |
| Steel spring |
8/9+5,6/8+4 |
Front tread(mm) |
1506, |
| Fuel type |
Diesel |
Rear tread(mmm) |
1466, |
| Emission standard |
Euro 4 |
| Engine model |
Manufacturer |
Displacement(ml) |
Power(KW) |
CY4102-CE4F |
Chaochai engine |
3856 |
73 |
The loading of the waste food garbage truck is done by lifting system of the side hydraulic waste bins, using the common sizes 120L/240L square shape waste bins. The lifting system can locking the waste bins, loading and discharging safely and reliably. The waste bins join the waste slot tog well, assuring non-overflow, non-missing.
Hydraulic system is made up of pump, hydraulic valve, sequence valve, and multi-purpose hydraulic cylinders, high-low pressure pipeline, etc. The key parts can choose the original imported ones, assuring the truck working safely and reliably.
The pick-up swill collecting trucks are mainly used to collect and transport the kitchen garbage, leftover, ort, swill,etc from restarant, hotel, factory mess hall, school dining room.
The tanker of the kitchen garbage truck was divided in two parts, one is for liquid food and the other is for solid food. When it works, the garbage bin with kitchen garbage will be transported to the tank top by conveyor belt and topple over the kitchen garbage into the tank. Then the solid waste and liquid waste will be separated and stored in their own tank. The solid waste also will be compressed to increase the storage capacity. When this garbage are transported to destination, you can operation the control valve to lift the tank, then open the rear door, the garbage will discharge automotically.
Dongfeng swill garbage truck for sale
High quality and best price dongfeng kitchen wastes food garbage truck for sale
