Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of septic truck, vacuum truck, sewage suction truck, fecal suction truck, etc. With many years' experience in supplying, Chengli Special Automobile Co., Ltd. could produce and supply ISUZU septic tanker truck, Dongfeng sludge tanker truck, FAW sewage suction truck, Foton vacuum vehicle, Howo sewer sucking vehicle, IVECO sewage suction truck, etc. More information, please feel free to contact with us.
If you're interested in our CLW brand septic tank truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
| Items |
Descriptions |
Specifications and Types |
| General |
Truck Name |
ISUZU Euro4 5-6cbm Sewage suction truck |
| Drive Type |
4*2 |
| Gross Vehicle Weight(kg) |
10000 |
| Curb Weight (kg) |
6205 |
| Rated mass(kg) |
3600 |
| Overall Dimensions L*W*H(mm) |
6700×2180×2950 |
| Engine |
Engine Model |
4HK1-TCG40 |
| Engine Brand |
ISUZU |
| Fuel Type |
Diesel |
| Power |
139kw/190HP |
| Emission Standard |
Euro 4 |
| Displacement(ml) |
5193 |
| Engine Type |
4 cylinders high pressure common rail diesel engine |
| Chassis |
Chassis Brand |
ISUZU |
| Front/Rear Axle Load(KG) |
3350/6650 |
| Tire No. |
6+1 |
| Tire Specification |
825-20 nylon tyre |
| Wheelbase (mm) |
3815 |
| Axle No. |
2 |
| Gear Box |
ISUZU MLD 6 speed manual transmission |
| Steering Wheel |
left hand drive,right hand drive is optional |
| Driver cab |
ISUZU 700P single row driver cab with original air-conditioner, |
| Brake |
Oil brake with vacuum booster pump |
| Bridge |
4ton front bridge, 7ton rear bridge |
| Sucking System |
Tank Volume(L) |
5000l-6000L |
| Tank shape |
Cylindrical |
| Tank Material |
5mm thick carbon steel |
| Vacuum Pump |
CLW brand vacuum pump |
| Suction Depth(m) |
More than 6 meter |
| Tank Tipping angle(°) |
More than 45 |
| Rear door |
Open and closed by hydraulic cylinders |
| Remark |
Sewage suction truck is made up of truck chassis, vacuum pump, PTO, shaft, water separator, oil separator, multi-way valve, sludge tanker,discharging valve, sewer view window, vacuum pressure gauge, pipelines, hydraulic system, etc.
rating rotate speed=1400r/m, min rotate speed>800r/m, max suction lift>6m, vacuum>500mmHg, steering: clockwise, full discharging time <8min |
More pictures of hot sale ISUZU vacuum truck for sale
hot sale ISUZU sewage suction truck
And the special parts of the sewage suction trucks are vacuum pump, PTO, shaft, water separator, oil separator, multi-way valve, tanker, discharging valve, sewer view window, vacuum pressure gauge, pipelines, hydraulic system, etc. The rear door is operated by the hydraulic switch with self-discharging function. The outlet is shut by pneumatic controlling. The truck also equips with one 5m length hose, with hand cleaning small water tanker.
the main advantages and the product description: the sewage suction truck is just suitable for sucking, transport and discharging all kinds liquid or half liquid, such as sewer, septic pool, swill, slops, feces and 8mm stone).
And also we can design and produce multitpurse septic trucks upon request, such as spetic truck with snow shovel, septic truck with water cannon, etc.
