DONGFENG 4*2 Cleaning Suction Sewage truck 6m3
Cleaning Suction Sewage truck , is also called sewage suction and cleaning truck, suction and cleaning trcuk, mainly used in cleaning road, sidewalk, guardrail, silt, stubborn stains, health corner and other kinds of public facilities, meanwhile, it is also used to suck liquid sewage, etc. It has many kinds of features: large flow , high pressure , cleaning conveniently, saving water, multifunctional, etc.
Product Notes:
1.DONGFENG 4*2 light duty chassis, 120hp, euro 2, LHD or RHD
2 Cleaning tank volume: 3.5m3, suction sewage tank volume:2.5m3
3. Equipped with high quality vacuum pump( vertical suction lift ≥ 10m.)and Italy high pressure pump
4 Factory direct sale, high quality low price
If you're interested in our dongfeng 145 cold room truck, please feel free to send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
More pictures of hot sale dongfeng sewer jetting vehicle as below.
More information, please feel free to contact with Ms. Anita Deng.
Whatsapp/wechat/Mob.: +86 13329899995
Skype: truck0011
QQ: 504873236
Main Parameter of DONGFENG 4*2 Cleaning Suction Sewage truck 6m3:
|
Main Technical Parameter
|
|
Product Model
|
DONGFENG Cleaning Suction Sewage truck
|
Overall Dimension(L*W*H)(mm)
|
7250×2470×3500
|
|
Wheelbase(mm)
|
3800
|
Tank volume( m3)
|
Water tank 3.5m3 ,sewage tnak:2.5m3
|
|
Curb weight(kg)
|
6300
|
Number of Axles
|
2
|
|
Approach/ departure angle (° )
|
18/14
|
Max Speed (km/h)
|
90
|
|
Cab capacity
|
2,3
|
Cab Type
|
flat proof, single row, air conditioning
|
|
Chassis Parameter
|
|
Chassis Model
|
EQ1110
|
Chassis manufacturer
|
DONGFENG Automobile Co., Ltd
|
|
Gear Box
|
DONGFENG 5 shift forward and 1 reverse
|
Transmission type
|
manual
|
|
Steering Type
|
LHD or RHD with power steering
|
Traction Type
|
4*2
|
|
Brake System
|
Air brake
|
Number of Tire
|
6 with a spare
|
|
Drive axle load(kg)
|
6000
|
Tire size/type
|
7.50.R16(radial tire)
|
|
Engine Parameter
|
|
Engine Model
|
CY4102-E3C
|
Engine manufacturer
|
DONGFENG CHAOYANG
|
|
Fuel type
|
diesel
|
Displacement(ml)
|
3856
|
|
Emission stand
|
Euro 2
|
Power(kw)
|
91(124hp)
|
|
superstructure parameter
|
1. Cleaning water Tank material:4mm high quality carbon steel
|
|
2. Water tank configuration; Italy imported High pressure Pump, 4mm good quality carbon steel, 16Mpa, 125L/Min, 60 meter Ø 19mm pipe, 10 high pressure sprayers;
|
|
3. Suction tank material: 5 mm good quality carbon steel,round tank
|
|
4. suction tank configuration: 8T vacuum pump( vertical suction lift ≥ 10m.)
,rear gravity mouth , inspect fecal window, Pressure gauge, hand-washing device, 5 meter long suction pipe, oil-water separators, overflow valve, etc
|
|
5. With self-priming, self-discharging and dump function, rear door and sewage outfall
is controlled by hydraulic cylinder
|
|
Warranty
|
12 months, from the date of supply
|
