export model bulk lpg gas cooking propane tanker trailer,factory direct sale CLW brand propane gas tank semitrailer
Chengli Special Automobile Co., Ltd. is the leading manufacturer of LPG pressure vessels, LPG tank trucks, LPG storage truck, LPG gas tank, LPG tank trailer, etc. in China since 2004s. With many years’ experience in manufacturing and selling, Chengli Special Automobile Co., Ltd could offer storage tanks series (10cbm-100cbm propane storage tank, 10cbm-100cbm liquid ammonia pressure vessels), LPG gas trailers (2 axles LPG trailer for propane, 3 axles LPG trailer for propane, 3 axles LPG trailer for methoxymethane, 3 axles LPG semitrailer for liquid ammonia), and LPG tanker trucks for loading propane, propene, liquid ammonia, isobutene, propylene, etc.
All the LPG tank trucks and LPG pressure vessels manufactured by Chengli Special Automobile Co., Ltd. are line with the GB150-1998.
More information, please feel free to send email to truck0011@163.com or talk to Anita directly by whatsapp/wechat: +86 13329899995.
Website: www.trucksinchina.com
The main parameters of hot sale lpg gas trailers manufactured by Chengli Special Automobile Co., Ltd. as below
| list |
product model |
main parameters |
|
Pri
ce
|
| chassis model |
overall
dimension
(L*W*H)
(mm)
|
tank dimension
(inner diameter*
tank thickness*
length)
(mm)
|
end head type and thickness |
tank volume(m3) |
medium |
filling ratio |
designed pressure |
rated weight
(kg) |
curb weight
(kg) |
total weight
(kg) |
material |
| 1 |
CLW5250GYQD4 |
DFL1250A11
(dongfeng 6×4 LPG truck) |
10200*2500
*3450 |
2100*12*
7534
|
double oval shape δ12 |
24 |
LPG |
0.42 |
1.61MPa |
10420 |
14385 |
25000 |
Q345R |
|
| 2 |
CLW5311GYQD4 |
DFL1311A10
(dongfeng 8×4 Lpg truck) |
11700*2500
*3690 |
2350*11*
8960
|
double ball shape δ8 |
35.5 |
LPG |
0.42 |
1.61MPa |
14910 |
15895 |
31000 |
Q370R |
|
| 3 |
CLW5310GYQC4 |
CA5310GYYP63K1L6T4E4
(FAW 8×4 LPG truck) |
11700*2495
*3690 |
2350*11*
8960
|
double ball shape δ8 |
35.5 |
LPG |
0.42 |
1.61MPa |
14910 |
15895 |
31000 |
Q370R |
|
| 4 |
CLW5240GYQ |
CA5250P7K2L3T1E4
(FAW 6×4 LPG truck) |
10200*2500*3450 |
2100*12*
7534
|
double oval shape δ12 |
24 |
LPG |
0.42 |
1.61MPa |
10420 |
14385 |
25000 |
Q345R |
|
| 5 |
CLW9409GYQ |
3 axles LPG semitrailer |
13000*2500*3977 |
2474*11*
12615
|
double oval shape δ13 |
58.5 |
LPG |
0.42 |
1.61MPa |
24570 |
15430 |
40000 |
Q370R |
|
| 6 |
2470*12*
12840
|
one ball and one oval shape end headδ8mm for ovalδ12 for ball |
24570 |
15430 |
40000 |
Q345R |
|
| 7 |
CLW9400GYQA |
3 axles LPG semitrailer |
13000*2500*3990 |
2475*11.5*
12837
|
double oval δ11.5 |
59.52 |
LPG |
0.42 |
1.61MPa |
25000 |
15000 |
40000 |
Q370R |
|
| 8 |
CLW9390GYQ |
3 axles LPG semitrailer |
12700*2500*3975 |
2450×11.5*12340 |
double ovalδ11.5 |
56 |
LPG |
0.42 |
1.61MPa |
23520 |
15480 |
39000 |
Q370R |
|
| 9 |
CLW9406GYQ |
3 axles LPG semitrailer |
12640*2490*3980 |
2450*8*12311 |
double ovalδ8 |
56 |
LPG |
0.49 |
0.70MPa |
27440 |
12560 |
40000 |
Q345R |
|
| 10 |
CLW9402GYQA |
3 axles LPG semitrailer |
13000*2500*3990 |
2450*13*12756 |
double ball δ8 |
57.1 |
LPG |
0.43 |
1.95MPa |
24550 |
15450 |
40000 |
Q370R |
|
| 11 |
CLW9310GYQ |
2 axles LPG semitrailer |
11324*2500*3730 |
2200*12*11044 |
double oval shape δ12 |
40.5 |
LPG |
0.42 |
1.61MPa |
17010 |
13415 |
30425 |
Q345R |
|
| 12 |
hot sale |
3 axlesLPG semitrailer |
12740*2480*3800 |
2300×12×12372 |
double oval δ12 |
49.6 |
LPG |
0.42 |
1.61MPa |
20832 |
15300 |
36132 |
Q345R |
t |
| hot sale |
EQ1141KJ(dongfeng 4×2 LPG truck ) |
7600*2462*3250 |
2000×10×5140 |
double oval shape δ10 |
15 |
LPG |
0.42 |
1.61MPa |
6300 |
8700 |
15000 |
Q345R |
|
| hot sale |
CA1313P7K1L11T4E
FAW 8×4 LPG truck |
10625*2490*3740 |
2450×12×7769 |
double oval shape δ12 |
34.5 |
LPG |
0.42 |
1.61MPa |
14490 |
16510 |
31000 |
Q345R |
|
| hot sale |
EQ1110GLJ(dongfeng 4×2 LPG truck |
7100*2230*2810 |
1600×8×4266 |
double oval shapeδ8 |
8 |
LPG |
0.42 |
1.61MPa |
3360 |
7100 |
10460 |
Q345R |
|
| The standard devices of the LPG tank semitrailer are single outlet, double side loading and unloading, double valves boxes, double toolboxes, safety valve, temperature gauge, pressure gauge, cut off valves, 3 axles 13ton BPW bridges (FUHUA bridge), 12 sets12.00 vacuum tyres and 1 set spare tyre, JOST outriggers, JOST traction pin, one extinguisher bottle, steel flippers, with ABS, etc. |
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
More pictures of hot sale lpg gas trailers manufactured by Chengli Special Automobile Co., Ltd. as below
17tons double axles lpg gas trailer for sale
best price lpg gas trailer for sale
