| Product No.: |
Overall dimension
(mm)
|
Capacity
(cbm)
|
Medium |
Design pressure |
Material |
| CLW9310GYQ |
11324*2500*3730 |
40.5 |
Propane |
1.61mpa |
Q345R |
| CLW9390GYQ |
12700*2500*3975 |
56 |
propane |
1.61mpa |
Q370R |
| CLW9400GYQA |
13000*2500*3990 |
59.52 |
propane |
1.61mpa |
Q370R |
| CLW9402GYQA |
12050*2490*3880 |
57.1 |
Propene |
1.95mpa |
Q370R |
| CLW9403GYQ |
12500*2500*3990 |
47.58 |
Dimethyl |
1.15mpa |
Q345R |
| CLW9405GYQA |
12500*2500*3990 |
49 |
Liquid ammonia |
1.91mpa |
Q370R |
| CLW9406GYQ |
12640*2490*3980 |
56 |
isobutane |
0.70mpa |
Q345R |
| CLW9409GYQ |
12900*2500*3977 |
58.5 |
Propane |
1.61mpa |
Q345R |
| |
10945*2480*3670 |
23.97 |
Silfur dioxide |
0.73mpa |
Q345R |
| |
12000*2500*3970 |
52.6 |
butadiene |
0.7mpa |
Q345R |
Lpg trailer kinpin:90# or 50#
LPG gas trailer landing gear :TFOC ,FUWA,JOST brand ,etc
Propane gas trailer axles :FUWA,BPW brand etc
Tri-axles propane trailer equipment :Equipped with safety valve ,liquid gauge ,pressure gauge ,temperature gauge ,urgent cut off valve ,valve box ,fire extinguish,anti static belt ,well-secured fenders and mudguards,tire well-secured ,fenders and mudguards,tool box for two side .
Function characteristic of liquefied gas truck of chengli factory
The anti corrosion coating of liquefied gas semi-trailer adopt the following process:sandblast,spray painting,purging and so on
There are domestic or imported safety accessories with high quality ,its matching is complete
We adopt scientific advanced construction process strictly,ensure that the products are with the lowest shrinkage and the highest dimensional stability at low temperature
We inspect the quality of product strictly,ensure that A and Btype of welding seam pass the examination of level two radiographic test C and D type of welding seam pass the examination of
Level one radiographic test .
