Jmc 4*2 LHD mobile digital billboard LED advertising vehicle for sale, hot sale high quality and best price JMC LED truck with stage
3 sides LED billboard truck,
PIXELS: 10mm/8mm/6mm(P10/P8/P6)
One side: 6.88
Sides(left + right): 6.88m2*2=13.76m2
Rear: 1.84m2
Stage: 10m2
JMC mobile LED billboard advertising vehicle, adopts JMC Brand 4*2 LHD truck chassis, 3360mm wheelbase, JMC 108hp diesel engine(Euro 4), JMC single row driver cab, 7.00R16LT 8PR tires*6+1, 5 speed gearbox, 1.5tons front axle/3tons rear axle, exhausting brake, etc.
The overall dimension(L*W*H) of JAC Mobile LED truck:5995*1880*2900(mm), truck model: CLW5040XXCJ.
1, the right side of the driver cab is with high quality P10/P8/P6 HD waterproof and shake-proof full color outdoor screen (screen area: 3840*1792=6.88m2),choose to install the side screen is with hydraulic lifting stage(stage area: 10m2, lifting height: 1.5m) and 4 sets manual/hydraulic outriggers.
2, the left side of the driver cab is with word roller light-box with automatically switching format advertisings; and the exterior with tempered glass or left and right sides with P10/P8/P6 screens
3, the rear part screen is with single color word screen (screen area: 1280*1440=1.84m2)
4, truck mounted diesel generator adopts high quality OUMA 8KW/15KW diesel generator.
5, truck trim: 5cm thickness composited steel box body frame, FRP material body, wooden floor, 4 sets of waterproof Audio, one set amplifier, intelligent Mechatronics controlling system, Circulating ventilation cooling system, safety intelligent Automatic switching system for inside and outside of the network, high ability Mute generator set, Gigabit flow Media control system.
Remark: the computer is with English words, English operation system and Software playback system.
If you're interested in our JMC brand mobile LED billboard advertising truck, please feel free to send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995
Website: www.trucksinchina.com.
main technical parameters of JMC brand mobile LED billboard advertising truck as below
| Main technical parameters |
| Product name |
JMC MOBILE LED billboard truck for sale |
| Total mass(Kg) |
4495 |
Diesel generator |
OUMA 8KW/15KW diesel generator |
| Curb mass(Kg) |
4365 |
Overall dimension(L*W*H)(mm) |
5995*2030*3050 |
| Side screen area |
3840*1792=6.88m2 |
Rear screen area |
1280*1440=1.84m2 |
| Seated person |
2 |
Truck mounted computer |
Full ENGLISH word Computer |
| Approach/departure angle(°) |
27/15 |
Front/rear suspension(mm) |
1065/1570 |
| Axle nos. |
2 |
Wheelbase(mm) |
3360 |
| Axle load(Kg) |
1860/2635 |
Max speed(Km/h) |
100 |
| Truck chassis |
| Truck chassis model |
Jx1041tg24 |
Manufacturer |
JMC COMPANY |
| Tire specification |
7.00R16LT* 6+1 |
Front tread(mm) |
1385 |
| Steel spring |
7/4+5 |
Rear tread(mm) |
1425 |
| Driver cab |
2 |
Gearbox |
5 speed gearbox |
| Emission standard |
Euro 3/4 |
| Engine model |
Manufacturer |
Displacement (ml) |
Power (Kw) |
| JX493ZLQ4 |
Jmc |
2771 |
80KW/108hp |
More pictures of hot sale JMC brand 4*2 mobile LED truck as below
HOT SALE! JMC brand 4*2 mobile LED billboard truck
high quality and best price JMC mobile outdoor LED billboard advertising truck for sale
