hot sale cheapest price dongfeng tianjin 4*2 LHD/RHD stainless steel refrigerated truck, factory sale best price stainless steel cold room truck
Dongfeng Tianjing refrigerated truck, chassis model: DFL1160BX, adopting Dongfeng Tianjing Original chassis, Chinese Ⅲ Emission standard Cummins 190hp engine, dongfeng 6 speed transmission, 5ton front bridge, 10ton rear bridge, 10.00-20 nylon tyre, with air-conditioner, wheelbase: 4700mm, the cargo dimension (L*W*H):6200*2200*2200(mm), the cargo volume: 30cbm.And the cargo van uses inner and outer glass steel. The cargo van is choosen to install fasten with 150 sets double side meat hooks, installing American Thermo King/CARRIER independent cooling unit, the cooling temperature can reach to 20 degree below zero.
If you'rei nterested in our truck, please feel free to send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
Main technical parameters of hot sale dongfeng tianjin stainless steel cold room truck as below
| Items |
Descriptions |
Specifications and Types |
| General |
Truck Name |
dongfeng Tianjin LHD cold room truck(CLW5160XLD3) |
| Drive Type |
4*2 LHD |
| Payload (kg) |
8210 |
| Seating person |
3 |
| GVW (kg) |
16,000 |
| Curb Weight (kg) |
7,790 |
| Overall Dimensions (mm) |
8720*2,370*3,630 |
| Driver cab |
Dongfeng Tianjin luxurious driver cab |
| Engine |
Engine Model |
B190 33 |
| Engine Brand |
Dongfeng Cummins |
| Fuel Type |
Diesel |
| Max output (hp/rpm) |
190hp/2500 |
| Max torque (rpm) |
1500 |
| Emission Standard |
Euro Ⅲ |
| Capacity (cc) |
5900 |
| Engine type |
6 cylinders, inter-cooling diesel engine |
| Chassis |
Chassis Brand |
Dongfeng |
| Tire Specification |
10.00R20 RIB (RADIAL) |
| Wheelbase (mm) |
4700/4500 |
| Axle No. |
2 |
| Front/Rear axle |
5ton front axle/10ton rear axle |
| Steering Wheel |
Left hand drive |
| Gear Box |
6 speed gearbox, manual |
| Brake |
Air brake |
| Air-conditioner |
Yes, with original air conditioner |
| Cold Room |
Box inner dimension(mm) |
6200*2200*2200 |
| Box Side |
Exterior and interior with stainless steel , and the middle with 80mm PU slices with vacuum negative pressure one-formed casting as the insulation layer, approved the related Ministry of Health of food grade requirements, etc. just like sandwich structure. |
| Box Floor |
Baseboard adopts aluminum alloy anti-skipping diamond board, which assuring the insulation ability and the compact resistance of the baseboard. |
| Doors |
Frame of standard rear double doors adopts the stainless steel structure frame with light mass and perfect corrosive resistance, etc.
The door edgings frames are sealed with the imported high quality epdm rubber, making sure the van insulation stability.
Door edgings, door locks and accessories use stainless steel materials.
|
| Refrigerator Unit |
Refrigeration unit |
Choose high quality made in China brand or USA brand cooling unit upon request. And the teperature can be adjusted from -18 degree to zero at the driver cab. |
| Heating system |
Can be installed upon request. |
| Others |
The refrigerated trucks can choose to install meat hangers (double sides meat hangers), and also choose to fix vent slots if needed. |
More pictures of hot sale dongfeng 10tons stainless steel reefer van truck as below
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of refrigerator truck in China. With many years' development, we Chengli Special Automobile Co., Ltd. could supply 4*2 cold room truck, 4*4 refrigerated truck, 6*4 heavy duty refrigerator truck, 6*6 reefer van truck, 8*4 heavy duty refriegrated truck, refrigerator van trailer, RHD cold box van truck, etc. More information, please feel free to contact with Ms. Anita.
