HOT SALE! 2019s new design CLW Brand 59.53m3 propane gas tank semitrailer for sale, factory sale bottom price 59,530Liters road transported lpg gas tank trailer
main technical parameters of hot sale 59.53M3 LPG GAS TANK TRAILER as below
| Main parameters |
| Product name |
Lpg gas trailer for propane |
Product model |
CLW9408GYQB Lpg gas tank semitrailer |
| Total mass(Kg) |
40000 |
Tank volume(m3) |
59.53 |
| Rated mass(Kg) |
25003 |
Overall dimension(mm) |
13000×2500×3990 |
| Curb mass(Kg) |
14997 |
Cargo body dimension(mm) |
×× |
| Approach/departure angle(°) |
-/22 |
Front/rear suspension (mm) |
-/1540 |
| Axle nos. |
3 |
Wheelbase(mm) |
7230+1310+1310 |
| Axle load(Kg) |
-/24000(triple axles) |
Max speed(Km/h) |
|
| Remark |
The transporting medium: propane, and the density: 0.42tons/cbm-0.52tons/cbm;
The lpg gas tank volume: 59.53cubic meters.
Tank overall dimension(Length*diameter): 12,791*2500(mm), |
| Chassis main parameters |
| Overall dimension (mm) |
13000×2500×3990 |
Tyre nos. |
12 |
| Approach/departure angle(°) |
-/19 |
Tyre specification |
11.00R20 12PR,12R22.5 12PR |
| Steel spring |
-/4/4/4,-/7/7/7 |
Front tread(mm) |
|
| Fuel type |
|
Rear tread(mm) |
1840/1840/1840 |
59.52cbm LPG tanker semitrailer for LPG GAS adopts 13ton FUWA triple axles, 12 sets 12.00-20 vacuum tyre, and another spare tyre, JOST 28ton outrigger, JOST 50# traction pin, fire extinguisher bottle, anti-static tape.
The standard devices are single outlet, double side loading and unloading, double valves boxes, double toolboxes, safety valve, temperature gauge, pressure gauge, cut off valves, 3 axles 13ton FUWA bridges, 12+1sets12.00 vacuum tyres and 1 set spare tyre, JOST outriggers, JOST traction pin, one extinguisher bottle, steel flippers, ABS etc.
If you're interested in our CLW brand lpg gas pressure vessels, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of hot sale CLW Brand 2017s new design 59.53m3 lpg gas tank semitrailer manufactured by Chengli Special Automobile Co., Ltd. as below.
CLW brand 59.53m3 lpg gas tank semitrailer for sale
High quality and competitive price CLW brand 50.53m3 lpg gas tank semitrailer for sale
Cheng Li produced a liquefied gas storage tanks in series, can be used to store the different nature of the liquefied petroleum gas (propane), propylene, ammonia, dimethyl , methanol, butadiene, butane, ethylene oxide, etc.in low pressure liquefied gases at room temperature; volume from 10 cubic meters --- 120 cubic optional. Besides, the lpg gas tank, Chengli Special Automobile Co., Ltd. could offer lpg gas trailer, lpg gas tank, lpg gas delivery truck, lpg gas dispenser vehicle, skid lpg gas filling plant, etc. More information, please feel free to contact with Ms. Anita Deng.
