Professional export Chengli 3 axle 50000l lpg tanker trailers for sale,Factory sale best price CLW lpg gas tank semitrailer
Specifications of Chengli 3 axle 50000l lpg tanker trailers for sale:
Chengli 3 axle 50000l lpg tanker trailers for sale is also called LPG trailer , LPG tank semitrailer , is widely used in transporting kinds of Liquefied petroleum gas, such as propane, isobutane, propylene, dimethyl , ammonia, etc. Adopt China newest or USA ASME pressure vessel Standard, it is high quality and reliable safety.
Product Notes:
1. We can make lpg trailer, lpg tank, lpg truck, lpg skid station, lpg tank container.
2. Special design for South America market: long wheelbase,one trailer axle with lifting device.
3. You can choose ASME standard products.
4. More than 10 years professional technology, Strictly whole process quality control.
More pictures of hot sale 3 axles 50,000Liters lpg gas tank trailer manufactured by Chengli Special Automobile Co., Ltd. as below.
High quality and competitive price CLW Brand lpg gas tank trailer for sale
Customized 50m3 lpg gas tank trailer for sale
Main Parameters of Chengli 3 axle 50000l lpg tanker trailers for sale:
| Product name |
Chengli 3 axle 50000l lpg tanker trailers for sale |
| Tank parameter |
Overall dimension(L*W*H)(mm) |
12740*2480*3800mm |
| Storage medium |
Propane |
| Volume(m3) |
50m3/50000L |
| Curb weight (kg) |
15300 |
| Tank material |
Q345R |
| Tank thickness(mm) |
body 12mm/ Head 12mm |
| Head type |
two oval-shaped head |
| Design pressure(Mpa) |
1.61mpa |
| Test pressure(Mpa) |
2.1Mpa |
| Design temperature(℃) |
-19 ℃to 50 ℃ |
| Paint process |
First step: Blowing sand; second step:Spray Antirust primer; third step: Spray topcoats |
| Accessories |
With China top brand safety valve, thermometer, pressure gauge, emergency shut-off valve, magnetic ball float type level gauge, fire extinguisher, anti-static ground tape, two valve boxes, tool box, |
| Manufacturing standards |
China Newest Pressure Vessel Standard: GB150-2011 or ASME |
| Optional |
Sun shield( Surface aluminum plate, inside polyurethane foam) |
| Chassis parameter |
Axle number |
3 |
| Payload |
20832kg |
| Suspension type |
BPW Leaf spring suspension |
| Brakes |
4-channel air brake compressed air brake with ABS |
| electrical |
24V, with pneumatic fittings and seven pole socket |
| Tire number |
12 with a spare tire |
| Tire type |
AEOLUS tires 12R22.5 |
| King pin |
JOST 90# |
| Outrigger |
25 ton JOST outrigger manually operated with two speed |
