Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of street sweeper, road sweeper truck, vacuum sweeper, sweeper washer vehicle, etc. With many years’ experience in manufacturing, we Chengli Special Automobile Co., Ltd. could supply Dongfeng street sweeper, ISUZU road sweeper truck, JMC sweeper cleaning truck, JAC sweeper truck, HOWO sweeper truck, etc. More information, please feel free to contact with Ms. Anita Deng.
The simple operation procures of road sweeper truck as below.
2020s PROMOTION! Factory sale good price JAC brand new street sweeping vehicle for sale, good price road sweeper truck
1, the sweeper truck reached the working streets, start the rear arrow light
2, park the street sweeper truck
3, open the power supply control box,
4, let the clutch of the auxiliary engine at the “separate” position.
5, start the auxiliary engine, working slowly.
6, let the rotation switch of the sweeping disk at the position of “positive turn reverse turn”.
7, start the main truck, driving, speed-up the auxiliary engine, beginning to sweeping the road.
8, after working, the auxiliary engine is at idling speed, stop the main truck.
9, the sweeping disks stop in circle, lifting the sweeping disk, and lifting the sucking dust van.
10, open the rear door the road sweeper,
11, press the “up” button of the sweeper van, and the sweeper van tipping.
12, dumping the wastes,
13, press the “down” button, then the sweeper van return.
14, close the rear door of the sweeper van
15, close the power supply at the operation box.
16, finishing the sweeping working.
If you're interested in our CLW brand road sweeping vehicle, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995
Website: www.trucksinchina.com
More pictures of JAC brand road sweeper truck manufactured by Chengli Special Automobile Co., Ltd. as below.
main technical parameters of JAC brand 4*2 LHD road sweeper truck manufactured by Chengli Special Automobile Co., Ltd. as below.
| ROAD SWEEPER TRUCK |
| # |
Descriptions |
Specifications and types |
| General |
Truck Brand |
Chengliwei (our brand) |
| Chassis Brand |
JAC |
| Approx. Dimension |
5900*1980*2450 mm |
| GVW./Kerb Wt. |
6995 / 4965kg |
| Cab |
Cab Capacity |
2 persons' seat |
| Air Conditioner |
Air Conditioner is optional |
| Chassis |
Drive Type |
4X2,left hand drive or right hand drive |
| Fuel Type |
Diesel |
| Engine Make & Model |
JAC ENGINE |
| Power |
120 Ps / 88 KW |
| Displacement |
2771 ml |
| Emission Standard |
EURO II or EURO III or EURO IV |
| Wheelbase/No.of axle |
3360 mm / 2 |
| Tyre Specfication |
7.00R16 14PR,7.00-16 14PR |
| Tyre Number |
6 tyres and 1 spare tyre |
| Max Speed |
98 km/h |
| Paint |
Automative metallic paint |
| Debris bin capacity |
3.5CBM |
| |
Clean water bin capacity |
0.8CBM |
| |
Air blower |
Manganese or stainless steel,drive by auxiliary engine |
| |
Auxiliary engine |
77hp @ 3600rpm |
| Equipments |
Debris bin and water bin are made of stainless steel ,corrosion-resistant
Four booms sweeping system and suction system combine working ,high efficient.
Water sprinklers equipped on brooms,suction nozzle.
Suction nozzle is floating type,self adjustable for different road condition.
Air blower is special for road sweeper,high efficient,low noise
|
More pictures of JAC brand road sweeper truck as below.
The standard devices of high quality CLW street sweeper trucks manufactured by Chengli Special Automobile Co., Ltd.
1, the street sweeper trucks manufactured by Chengli Special Automobile Co., Ltd. are with 4 sets of sweeping brushes, JMC 88hp auxiliary engine(dongfeng 145/dongfeng 153/ dongfeng Tianjin with Cummins 140hp auxiliary engine), Italian motor, France switches, high quality solenoid valve units, maintenance-free automatic disconnect-type clutch, maintenance-free fan, stainless steel water tank and garbage van, rear part with LED arrow lamps, portable pump emergency system, etc.
2, the max sweeping width of CLW sweeper truck is 3.2m, and the max suction diameter of the particles is 120mm.
3, And the clients can choose to install camera, front-washing and rear sprinkling, etc.
