best seller 50m3 bulk lpg gas road transported tanker in 2019s, new manufactured cheaper 20tons propane gas tanker semitrailer body for sale
The LPG tanker semi-trailer manufactured by Chengli Special Automobile Co., Ltd. is line with the GB150-1998, <<Supervision Regulation On Safety Technology for Pressure Vessel>>, <<Regulation of Safety Supervision for Liquefied Gas Tank Car>>. We can also manufacture ASME standard lpg gas trailer, lpg gas tank, lpg gas truck, skid lpg gas filling plant, etc. And we can design and produce lpg gas pressure vessels customized.
Cheng Li produced a liquefied gas storage tanks in series, can be used to store the different nature of the liquefied petroleum gas (propane), propylene, ammonia, dimethyl , methanol, butadiene, butane, ethylene oxide, etc.in low pressure liquefied gases at room temperature; volume from 10 cubic meters --- 120 cubic optional. Besides, the lpg gas tank, Chengli Special Automobile Co., Ltd. could offer lpg gas trailer, lpg gas delivery truck, lpg gas dispenser vehicle, skid lpg gas filling plant, etc. More information, please feel free to contact with Ms. Anita Deng.
If you're interested in our lpg gas tank semitrailer, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of 2019s best seller- 50m3 bulk lpgh gas road transported tanker manufactured by Chengli Special Automobile Co., Ltd. as below.
main technical parameters of 2019s best seller-50m3 lpg gas tank trailer manufactured by Chengli Special Automobile Co., Ltd. as below.
| Loading medium |
LPG gas |
Medium characteristic |
flammable and combustible |
Safety valve |
2*DN100 |
| Curb mass (kg) |
15300 |
Tanker |
Designed pressure(Mpa) |
1.61MPa |
Designed standard
GB150-2011<<pressure vessels>>
GB/T19905-2005 <<Liquefied Gas Tank Car>>
|
| Loading mass(kg) |
20832 |
Filling ratio(kg/cbm) |
420 |
| Max total mass (kg) |
36132 |
Tanker material |
Q345R |
| Wheelbase(mm) |
6800+1310+1310 |
Tanker designed thickness(mm) |
11.05 |
| Front/rear suspension(mm) |
-/1650 |
Head designed thickness(mm) |
11.03 |
| Overall dimension(L*W*H)(mm) |
12740×2480×3800 |
Tanker body dimension(L*W*H)(mm) |
2300*12*12372 |
Chengli Special Automobile Co., Ltd. |
The standard devices of CLW Brand 49.6m3 lpg gas tank semitrailer customized for client from Nigeria: 13ton FUWA triple axles, 12+1 sets 12.00-20 tubeless tyres, JOST 28ton outrigger, JOST 50# traction pin, fire extinguisher bottles, anti-static tape. The standard devices are single outlet, double side loading and unloading, double valves boxes, double toolboxes, safety valve, temperature gauge, pressure gauge, cut off valves, 3 axles 13ton FUWA bridges, 8 sets12.00 tubeless tyres and 1 set spare tyre, JOST outriggers, JOST traction pin, one extinguisher bottles, steel flippers, with ABS, etc.
