new dongfeng dry-type street sweeping vehicle for sale, best price new designed road sweeping truck for sale
|
Main technical parameters
|
|
Truck chassis
|
DONGFENG TIANJIN dry-wet road sweeping truck for sale
|
Remark
|
|
Chassis model
|
DFL
DFH1180BX1V
|
|
|
Wheelbase
|
4500 mm
|
|
|
4700mm
|
|
Front/rear suspension
|
1430/1920 mm
|
|
|
|
|
Engine model
|
Chassis engine
|
B190 33
|
|
|
|
|
Auxiliary engine
|
B170
|
|
|
Engine rated power
|
Chassis engine
|
140KW
|
|
|
|
|
Auxiliary engine
|
125 kW
|
|
|
Max grade
|
30%
|
|
|
Emission standard
|
Euro V/Euro Ⅲ
|
|
|
Max speed
|
98 km/h
|
|
|
Approach angle
|
20°
|
|
|
Departure angle
|
12°
|
|
|
Mass
|
Curb mass
|
10670 kg
|
|
|
Total max mass
|
15800 kg
|
|
|
Dimension
|
Overall dimension(L*W*H)
|
8050×2500×3060 mm
|
|
|
7850×2500×3060 mm
|
|
Mini ground clearance
|
240 mm
|
|
|
Sucking and sweeping
|
Sweeping effectiveness
|
≥95%
|
|
|
Maximum inhalation particle size
|
110 mm
|
|
|
Sucking and sweeping width
|
3.0-3.2 m
|
|
|
Max sweeping ability
|
51000 m2/h
|
|
|
Disc-shaped brush overhang size
|
≥400 mm
|
|
|
|
Driving speed when sweeping
|
3-15 km/h
|
|
|
Dust tank
|
Rated volume
|
8.0 m³
|
|
|
Discharge door opening angle
|
≥85°
|
|
|
Hydraulic system
|
Type
|
Open-type, electrical controlling
|
|
|
Main units
|
Gear pump, hydraulic motor, hydraulic cylinder, electromagnetic valve
|
|
|
System pressure
|
16MPa
|
|
|
Hydraulic oil tank volume
|
60 L
|
|
|
Oil temperature
|
60 ˚C
|
|
|
Electrical system
|
Type
|
DC24 V
|
|
|
Voltage
|
24 V
|
|
|
Storage batteries
|
24 V(2*12 V series)
|
|
|
Sweeping disk
|
Type
|
Middle-installed two sweeping disks, hydraulic motor drive, adjustable rotated speed, separated controlled, Automatic avoidance function
|
|
|
Disk diameter
|
850 mm；950 mm
|
|
|
Disk angle
|
Forward leaning:4-6°; Extravert:4-7°
|
|
|
Dust suction pipe diameter
|
140 mm
|
|
|
Sucking disk
|
Type
|
Double suction, hydraulic control, spring suspension
|
|
|
sucker diameter
|
200 mm
|
|
|
Filter cartridge
|
|
14 units
|
|
| |
|
|
|
|
Vehicle tools
| List |
Name |
No. |
Remark |
| 1 |
manual hydraulic pump joystick |
1 |
Used for start manual hydraulic pump |
| 2 |
Spare tire |
1 |
|
Spare parts
| List |
Name |
No. |
|
| 1 |
Brushing |
1 |
|
| 2 |
Fan seal |
1 |
|
| 3 |
Rear door seal |
1 |
|
More pictures of CLW brand dry-type road sweeper truck manufactured by Chengli Special Automobile Co., Ltd. as below.
HOT SALE! Dongfeng brand 190hp diesel dry-type road sweeping vehicle for sale
If you're interested in our road sweeper, please feel free to send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995
Website: www.trucksinchina.com
Cleaning: The auxiliary engine drives the hydraulic oil pump and fan to work. The hydraulic oil pump drives the left and right sweep discs to expand, lift and rotate. The left and right sweeping pan sweeps the garbage on both sides to the bottom of the road sweeper and in front of the suction nozzle. The fan works to make the air duct composed of the dustbin, the suction pipe and the suction nozzle produce high-speed airflow. Under the action of the airflow, the garbage is sucked into the suction nozzle and into the dustbin; the vacuum hood on the sweeping pan sucks the dust in by the working principle of cyclone Inside the trash can. The chassis engine drives the road sweeper to move forward, and the garbage that is swept in front of the suction nozzle continuously enters the suction nozzle and is continuously sucked into the garbage bin to realize road cleaning.
Dust reduction: the layered design in the garbage bin, the dust is filtered by the filter cartridge and the clean air is discharged, and the granular garbage directly enters the garbage bin; in rainy or wet roads, by switching the air duct, all garbage directly enters the garbage by gravity sedimentation In the box. The garbage and dust sucked into the compartment are separated by inertial separation, impact separation, and filtration separation. The first dry dust removal mechanism is adopted to realize the automatic dust removal of the filter system.
The introduction of fuctions of road sweeper truck manufactured by Chengli Special Automobile Co., Ltd. as below.
1) The vehicle integrates the functions of a road sweeper and a dust collector. It can switch the air duct to change the dust reduction mode. There is no need to use water to reduce dust, and it is not limited by the distance of the water source. It is an all-terrain, all-weather road sweeper, especially suitable In cold and dusty areas.
2) The vehicle adopts the control mode of "display screen + controller + CAN bus operation panel". You can choose the sunny or rainy working mode. When the job is started and stopped, the auxiliary engine speed control, nozzle lifting, sweeping and retracting devices are all controlled by one button, which is easy to operate.
3) The arrangement of "two vertical sweeps in the middle + vacuum hood + wide suction nozzle in the middle + four suction pipes on the left and right". The large sweeping brush design can remove the dead-angle garbage on the road steps. The suction nozzle can automatically level with the ground conditions, with large cleaning capacity and fast cleaning speed.
4) The left and right sweeps are designed for independent or linked work, which can both independently sweep right and sweep left and right at the same time. The scanner has an obstacle avoidance protection function and a reset function. It retracts after encountering an obstacle, and resets after crossing the obstacle.
5) The auxiliary engine is specially used to drive the fan and hydraulic system to ensure that it can continue to work during driving and ensure the continuity of the cleaning process.
6) The transmission setting between the auxiliary engine and the fan is equipped with an automatic clutch, which can ensure the automatic separation of the auxiliary engine from the fan when the auxiliary engine starts and stops without load, reduces the impact on the auxiliary engine, and improves the working reliability and service life of the auxiliary engine . 7) The imported hydraulic valve group can ensure the stability and smoothness of the hydraulic action of the whole vehicle.
8) The high-quality hydraulic motor can ensure the working stability of the sweeper and long service life.
9) Precision seamless cold-formed hydraulic tubing, with no oxidizing impurities on the inner wall, to ensure that the hydraulic circuit is clean and free of valve blockage.
9) Set up high-definition surveillance probes on the right and rear, and set up high-definition LCD monitors in the cab to monitor the work effect;
11) Equipped with reversing protection device. In case of emergency reversing during operation, the intelligent control system will automatically stop the operation and retract the sweeping disc, suction cup and side spray rod; it has protection against lifting the trash can from overturning; it has safety protection for maintenance.
12) Equipped with a dustbin lifting safety protection device to ensure that the dustbin cannot be lifted when the rear door is not opened.
13) When the safety bar is not put down, the intelligent system will prohibit the trash can from returning, which can effectively prevent accidents during maintenance.
14) The high-performance engineering plastic spacer is used in the sweeping brush arm, which has good abrasion resistance, no grease and no maintenance, saving manpower and material resources.
15) Stainless steel dustbin has high strength, can resist general corrosion and increase the service life of the box.
16) The ultra-wide rear door and the opening angle greater than 90 degrees make it easy to dump garbage and clear the garbage bin.
17) The tipping angle of the garbage bin is greater than 48 degrees, which makes it easy to dump garbage.
