Hot sale! Dongfeng D9 180hp diesel Euro 4 10cbm asphalt spreading tanker truck for sale, 8tons bitumen distributing vehicle for sale
Dongfeng D9 180hp diesel Euro 4 10cbm bitumen distributing tanker truck, adopts dongfeng D9 one row and a half luxurious driver cab, 4500mm wheelbase, ISD180-43 Cummins 180hp Euro Ⅳ diesel engine, 9,00R20 rail tires, 4.5t front axle/10t rear axle, 8 speed manual gearbox, etc.
The devices of dongfeng D9 10cbm asphalt tanker truck manufactured by Chengli Special Automobile Co., Ltd. is as below.
1, the asphalt pump adopts high quality QGB950 (high viscosity asphalt pump, 950L/min).
2, hydraulic system: Proportional valve (Taiwan EFBG-03-160-HF); Automatic reversing valve and overflow valve; radiator adopts Risheng brand; the model of hydraulic motor for asphalt pump: 05-110-BD31; hydraulic pump model: CBQ550-L or Power take off after engine GPC4-50R.
3, control way: Intelligent touch screen computer control at the driver cab; control system: (Siemens, Germany), 36 sets intelligent asphalt spraying nozzles (one controls one).
4, Heating method: Burner (Italy imported Riello brand burner model G20) + Automatic heating of heat transfer oil
5, gasoline generator unit: 6KW
6, spreading amount: 0.25-3.5L/㎡;
7, asphalt distributing width: 4.5m, 48 sets spraying nozzles for 6m spreading width is selective (10000RMB additional).
8, Distributing medium: emulsified asphalt, hot asphalt, SBS hot asphalt, etc.
More pictures of dongfeng D9 10cbm asphalt tanker truck manufactured by Chengli Special Automobile Co., Ltd. as below.
If you're interested in our asphal tanker truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995
Website: www.trucksinchina.com
Main technical parameters of dongfeng D9 10cbm asphalt tanker spreading vehicle manufactured by Chengli Special Automobile Co., Ltd. is as below.
| Main technical parameters |
| Product name |
CLW5180GLQ6 asphalt spreading vehicle for sale |
| Total mass(Kg) |
18000 |
Tanker volume(m3) |
10.0 |
| Rated mass(Kg) |
8690,8625 |
Overall dimension(L*W*H)(mm) |
8160×2500×3060 |
| Curb mass(Kg) |
9180 |
Driver cab seated person |
2,3 |
| Approach/departure angle(°) |
19/15 |
Front/rear suspension(mm) |
1260/2400 |
| Axle no. |
2 |
wheelbase(mm) |
4500 |
| Axle load(Kg) |
6500/11500 |
Max speed(Km/h) |
105 |
| Chassis main technical parameters |
| Chassis model |
EQ1185LJ9CDE |
Manufacturer |
Dongfeng company |
| Approach/departure angle(°) |
19/13,19/17 |
Tire specification |
10.00R20 18PR, |
| Steel spring |
8/10+7, |
Front tread(mm) |
1933, |
| Fuel type |
Diesel |
Rear tread(mm) |
1865 |
| Emission standard |
Euro Ⅲ |
| Engine model |
Manufacturer |
Displacement (ml) |
Power(Kw) |
| ISD180-43 |
Cummins |
4500 |
132 |
The asphalt tank distributing vehicle is a kind intelligent automated high-tech special vehicle for distributing different kinds of asphalts such as emulsified asphalt, diluted asphalt, hot asphalt, High viscosity modified asphalt, etc. It is used for distributing the permeable oil waterproof layer on the bottom of asphalt pavement of high grade highways. The asphalt distributing vehicle is made up of truck chassis, asphalt tank body, asphalt pump delivering and spraying system, thermal oil heating system, hydraulic system, combustion system, control system, Pneumatic system, operation platform, etc.
The bitumen distribution truck for sale are consisted with truck chassis, insulated asphalt tank, heater, hydraulic system, conducting oil pipeline, asphalt pump, spray nozzle, etc. The tank volume is from 3m3 to 18m3. The spray nozzle quantity is from 30 to 48 nos.
The liquid bitumen sprayer truck is mainly used to transport asphalt and distribut it for sealing the road.
Our asphalt distributor dopt advanced technology and foreign imported parts. It has more advantages than other asphalt suppliers.
Our asphalt sparyer truck for sale adopt special chassis and Italy imported burner. It has many advantages.
