New manufactured common type bitumen tanker spreading vehicle for sale, HOT SALE! 3tons asphalt distributing truck
The asphalt tank distributing vehicle is a kind intelligent automated high-tech special vehicle for distributing different kinds of asphalts such as emulsified asphalt, diluted asphalt, hot asphalt, High viscosity modified asphalt, etc. It is used for distributing the permeable oil waterproof layer on the bottom of asphalt pavement of high grade highways. The asphalt distributing vehicle is made up of truck chassis, asphalt tank body, asphalt pump delivering and spraying system, thermal oil heating system, hydraulic system, combustion system, control system, Pneumatic system, operation platform, etc.
The bitumen distribution truck for sale are consisted with truck chassis, insulated asphalt tank, heater, hydraulic system, conducting oil pipeline, asphalt pump, spray nozzle, etc. The tank volume is from 3m3 to 18m3. The spray nozzle quantity is from 30 to 48 nos.
The liquid bitumen sprayer truck is mainly used to transport asphalt and distribut it for sealing the road.
Our asphalt distributor adopt advanced technology and foreign imported parts. It has more advantages than other asphalt suppliers.
Our asphalt sparyer truck for sale adopt special chassis and Italy imported burner. It has many advantages.
If you're interested in our asphalt tanker truck, please send email to truck0011@163.com or talk to Anita by Wechat/Mob/Whatsapp: 0086 13329899995
Website: www.trucksinchina.com
Customized common type asphalt tanker vehicle adopts dongfeng 4*2 LHD single row driver cab, chaochai 90hp diesel engine, 5 speed gearbox, 7.00R16 tires*6, 3300mm wheelbase, etc.
The devices of Common type dongfeng brand 4cbm 3tons asphalt distributing vehicle manufactured by Chengli Special Automobile Co., Ltd. as below.
1, the asphalt pump adopts high quality QGB270 (high viscosity asphalt pump, 270L/min).
2, driving by hydraulic system, hydraulic pump model: CBQ540-L; the model of hydraulic motor for asphalt pump: HZH05-90; Manual reversing valve.
3, asphalt distributing width: 4m; 15 sets asphalt sprayers
4, Heating method: Riello burner (G10) imported from Italy.
More pictures of dongfeng 4cbm 3tons asphalt tanker vehicle manufactured by Chengli Special Automobile Co., Ltd. as below.
Main technical parameters of dongfeng 4cbm bitumen tanker truck manufactured by Chengli Special Automobile Co., Ltd. as below
| Main technical parameters |
| Product name |
CLW5072GLQ4 asphalt tanker vehicle |
| Total mass(Kg) |
7300 |
Tanker volume(m3) |
4cbm |
| Rated mass(Kg) |
2690,2625 |
Overall dimension(L*W*H)(mm) |
6300×2080×2400 |
| Curb mass(Kg) |
4480 |
Driver cab seated person |
2,3 |
| Approach/departure angle(°) |
19/12 |
Front/rear suspension(mm) |
1032/1968 |
| Axle nos. |
2 |
Wheelbase(mm) |
3300 |
| Axle load(Kg) |
2920/4380 |
Max speed(Km/h) |
95 |
| Main technical parameters of truck chassis |
| Truck chassis |
EQ1060 |
Manufacturer |
Dongfeng company |
| Overall dimension(L*W*H)(mm) |
5845×1900×2220 |
Tire specification |
6 |
| Approach/departure angle |
19/16 |
Tire specification |
7.00R16 14PR |
| Steel spring |
8/9+5, |
Front tread(mm) |
1506 |
| Fuel type |
Diesel |
Rear tread(mm) |
1466 |
| Emission standard |
Euro 3 |
| Engine model |
Manufacturer |
displacement(ml) |
power(Kw) |
| CY4100Q |
CHAOCHAI |
3786 |
70 |
