HOT SALE! Dongfeng 10m3 stainless steel material Potable Water Truck, foodgrade drinking water tanker vehicle for sale
- CLW drinking water truck, made of stainless steel, is very famous in China for its high quality, good performance and cheap price
- Dongfeng KingRun chassis, Cumins 170HP Turbo-intercooler,5900cc diesel engine
- Main parts: water tank body, pipe system, front spraying, rear spraying, side water discharge valve, watering shooting nozzle, rear work platform, etc
- Capacity: water tank volume from 2000liters to 30000liters, and 30000~50000liters water tank semi trailer
- Function: used to spray water, used to transport water, emergency fire fighting, mobile water pump, cleaning road, spraying green trees grass, etc
- All watering valves or discharge valves can be automatically controlled in driving cabin
- Chasiss brand optional: HOWO, Hongyan, DONGFENG, JMC, FOTON, SHACMAN, JAC, JAPAN BRAND, LIUQI CHENGLONG, etc.
The water truck is mainly used for water transportation, road sprinkling, plant watering, etc. The water carrier truck is consisted of chassis, Q235 water tank, front, side and rear sprinkler nozzle. Also , the rear of the water truck is equipped antiskid platform with water cannon. The water cannon can rotate 360 degree and the water flow can be adjusted to mist, light rain, moderate rain, heavy rain, etc. The spraying width of clw water truck is more than 15m and the cannon range is more than 25m.
1.Tank material of water tanker:
Carbon steel or stainless steel,4mm/5mm/6mm thick for choose.
2. Water pump:
The water truck is installed CLW Famous Brand water pump(suction lift range bigger than 6m).
3. Kind of the sprayer:
Including Front flush, Rear Sprinklers, Side Spray, water monitor install rear working platform.
(water monitor can be adjust to Heavy rain, moderate rain, light rain, mist)
4. Options: Fog connon to spray pesticides and disinfectants.
If you're interested in our water tanker truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: 0086 13329899995.
Website: www.trucksinchina.com
More pictures of Dongfeng stainless steel material water tanker truck is as below.
main technical parameters of dongfeng stainless steel material water tanker truck is as below.
| Main specification |
| Product model and name |
Dongfeng Kingrun 12000Liters water truck |
| Gross weight(Kg) |
16000 |
Drive type |
4*2 |
| Payload(Kg) |
9200 |
Overall dimension(mm) |
8600*2490*3100 |
| Curb weight(Kg) |
6605 |
Cab seats |
3 |
| Approach/departure angle(°) |
18/13,18/16 |
Front/rear hang(mm) |
1430/2470 |
| Axle No. |
2 |
Wheelbase(mm) |
4500 |
| Axle load(Kg) |
6000/10000 |
Max speed(Km/h) |
90 |
| Chassis specification |
| Chassis model |
DFL1160 |
Manufacturer |
Dongfeng Motor Co.,Ltd |
| Brand name |
Dongfeng |
Dimension(mm) |
8790*2370*2760 |
| Tyre specification |
10.00R20 |
Tyre No. |
6 |
| Steel spring number |
7/9+6,8/10+8 |
Front track base(mm) |
1880,1920,1940 |
| Fuel type |
Diesel |
Rear track base(mm) |
1800,1860 |
| Emission standard |
Euro 3 |
Transmission |
6 forward gear,1 reverse gear |
| Cab |
D530 flat.One and half row flat cab, electric window regulator,
central control door lock and PXD-B dashboard with air condition.
|
| Engine model |
Engine manufacturer |
Displacement(ml) |
Power(Kw) |
| B190 33 |
Dongfeng Cummins Engine Co.,Ltd |
5900 |
140(190HP) |
| Performance |
| Tank volume(m³) |
12 |
Tank material |
Carbon steel Q235/Stainless steel |
| Water pump model |
80QZF-60/90N |
Water pump flow(m³/h) |
60 |
| Watering width(M) |
≥14 |
Water cannon range (M) |
≥28 |
| Feature and Application |
|
1).Equipped with high power self-suction water pump that characterized by high-pressure and fast speed suction. 2).Equipped with front, rear and side sprinklers and high position sprinkler, and rear working platform.
3).The water cannon which is installed on the working platform can rotate by 360 degree and the water flow can be adjusted into various rain shape. There are straight shape, heavy rain, moderate rain and drizzle etc. The max range can reach 30M.
4).Equipped with fire coupling, flow valves, filter screen and water level gauge.
5).According to customers’ request, the crane, high working platform and spraying machine also can be equipped.
6).Mainly used for washing on urban roads, watering and greening on trees, green belts and lawn and dust full of construction sites. And also used for drinking water delivery and fire fighting function etc.
|
