Description of road sweeper trucks manufactured by Chengli Special Automobile Co., Ltd. is as below.
1. road sweeper truck Cleaning device type:Center four sweep and rear nozzle scan disk can automatically avoid obstacles;sweep plate has three modes of operation; full sweep left front , right front sweep , to achieve road sweeping and vacuuming .
2.street sweeper Nozzle:The roll-broom enhanced nozzle, built-in roll sweep elimimate waste omission; rolling tire three o'clock floating support,road profiling powerful;(national initiative) pneumatic tybe with a net antifreeze device,can effectively ensure sprinkler parts are not due to structral damage caused by freezing;(national patent technology)
With a leak proof drainage device, effectively prevent dirt build-up,to prevent fouling and clogging junk falls back to the groud straw causing secondary pollution;(national patent technology)
3,road cleaning truck All fasteners are made of galvanized, scan disk,nozzles and other structural parts are made of acid phosphate electrostatic spraying , strong adhesion, coating corrosion resistance,weather resistance
4,Trach the whole entire layer of SUS304 stainless steel, structural strength,does not rust.
Trash shape with side large surface modeling ,arc transition, in proportion to the whole car ,nice .
5.In the state of emergency, it can be manipulated by setting the manual pump trash ,and sweep the nozzle plate movements and other movements , special circumstances can work directly into the engine compartment to detect vice and maintenance
6,Functional device with enhanced pressure dust,the dust can be adapted to the cleaning surface thicker
7.With a varity of security alarm devices; water tank low water level, job tips , deputy engine temperature,oil pressure , parking tips,hydraulic oil leak alarm,trash tipping , reset , and the back door open and close securith alarm devices .
The technical advantages of CLW brand road sweeping vehicle is as below.
1. Assembling on secondary-class chassis, this road sweeper truck is equipped with air conditioning,heater, power steering system, and high-quality CD player, making driving easy.
2. This equipment is an environment-friendly special purpose sweeper, which integrates sweeping, sprinkling, and garbage transportation.
3. The cleaning system is driven by imported advanced hydraulic motor to guarantee the power and reliability during work.
4. When cleaning, the sweeping brushes softly contact the ground, largely reducing their wear and extending their working life.
5. The suction unit features elastic collision and ensures the safety during the cleaning process.
6. Equipped with oversized three layers of filter system, dust filtering ratio up to 99.99%, extending engine's life.
7. The hydraulic motor is imported from Bulgaria, stable operation.
8. Equipped with a backup hydraulic unit, which is used to lift the garbage bin and other actions, in case the truck can not start.
9. The chissis and auxiliary engines are from the same brand, so it is relatively easy to maintain.
10. Stainless steel water tank and garbage bin which make the using life longer.
11. Customized suction fan provides ample wind force; ensure a smooth and efficient completion of work.
12. Equipped with warning light that ensures a safe working enviroment during the operation.
If you're interested in our road sweeper truck, please send email to truck0011@163.com or talk to Anita by Whatsapp: 0086 13329899995.
Website: www.trucksinchina.com
More pictures of dongfeng tianjin road sweeper truck is as below.
HOT SALE! Dongfeng tianjin road sweeper for sale
main technical parameters of dongfeng tianjin road sweeper truck is as below.
|
1,.the standard device
The road sweeper trucks manufactured are with 4 sets of sweeping brushes, Cummins auxiliary engine, Italian imported motor, Schneider Electric switches, Taiwan Solenoid valves, maintenance-free and self-disconnect type clutch, maintenance-free fan, stainless steel water tank, stainless steel wastes van, rear part LED arrow lamp, manual portable pump Emergency system, seamless cold-rolled steel hydraulic oil tubes for precision applications, etc.
The rotation mechanism of the front sweeper arm adopts high-tech rear-resistant work spacer sleeve, without buttering, precise cold-bending seamless hydraulic oil pipes, etc.
|
|
Truck model
|
CLW5160TSLD3 road sweeper truck
|
Remark
|
|
Truck model
|
DFL1160BX2
|
|
|
Wheelbase
|
4500 mm/4200mm
|
|
|
Front/rear suspension(mm)
|
Front: 1430;rear: 1950/2250mm
|
|
|
Engine model
|
Truck chassis model
|
B170 33/ B190 33
|
|
|
Auxiliary engine
|
B140
|
|
|
Engine rated power
|
Truck chassis engine power
|
125KW/140KW
|
|
|
Auxiliary engine
|
103 kW
|
|
|
Maximum climbing angle
|
30%
|
|
|
Displacement Emission standard
|
Euro Ⅲ
|
|
|
Outside-automobile noisy in the accelerating
|
≤84dB(A), meeting the noisy of Second stage requirements
|
|
|
Max speed
|
90 km/h
|
|
|
Approach angle
|
20°
|
|
|
Departure angle
|
10°/9°
|
|
|
Weight
|
Curb weight
|
10205kgs
|
|
|
Max total weight
|
16000 kg
|
|
|
Rated weight
|
5600kg
|
|
|
Dimension
|
Overall dimension(L*W*H)
|
7880*2470*3150(mm)
|
|
|
Sweeping and sucking working
|
Sweeping efficiency
|
≥95%
|
|
|
Max sucking granularity
|
120 mm
|
|
|
Sucking-sweeping width
|
3.2-3.5 m
|
|
|
Max sweeping ability
|
70000 m2/h
|
|
|
Extension dimension of dish brush
|
≥400 mm
|
|
|
Working driving speed
|
3-20 km/h
|
|
|
Tank
|
Water tank volume
|
3.0 m³
|
|
|
垃圾箱
|
Wastes van volume
|
7.2 m³
|
|
|
The opening angle of unloading door
|
≥45°
|
|
|
Hydraulic system
|
Type
|
Open-type, electronic-control
|
|
|
Main untis
|
Gear pump, hydraulic motor, hydraulic cylinders, solenoid valve,
|
|
|
System pressure
|
16MPa
|
|
|
hydraulic oil tank volume
|
60L
|
|
|
Hydraulic oil temperature
|
60 ˚C
|
|
|
Electronic system
|
Type
|
DC24V
|
|
|
voltage
|
24V
|
|
|
Storage battery
|
24V
|
|
|
Water-sprinkling system
|
Main units
|
Electronic diaphragm pump, water filter, nozzles,
|
|
|
Sweeping disks device
|
Type
|
4 sets of sweeping disks middle-installed driving by hydraulic motor;
The right-front one can work separately, with the function of dodge and repeat working
|
|
|
Diameter
|
850mm；950mm
|
|
|
Angle
|
ante version:4-6 °; extroversion: 4-7°
|
|
|
Sucking disk
|
Type
|
Single sucking, hydraulic-control, springs
|
|
|
Sucker mouth diameter
|
200mm
|
|
