HOT SALE! GOOD PRICE DONGFENG 4*2 RHD 3T flatbed wrecker towing truck, Street repair recovery removal vehicle for sale
Customized mini dongfeng 4*2 RHD 3tons recovery wrecker tow truck adopts dongfeng 4*2 RHD truck chassis, chaochai 90hp diesel engine, 5 speed gearbox, 7.00R16 rail tires, 3300mm wheelbase, power steering+ air cut braking, etc.
The loading capacity of the flatbed type wrecker tow truck is 3tons, 4tons loading capacity hydraulic winch, and the length of the flatbed is 4.2m; the width of the flatbed is 2.3m; while the length of the tail plate is 1m, which can be designed and manufactured as hydraulic folded flipping plate. So the length of the flatbed of dongfeng wrecker tow truck is 5.2m (4.2m+1m), 20m length wire rope, Bilateral Linkage, Retractable Rear Lift Arm is selective, yellow color alarm light, 4 sets binding belts, Auxiliary wheels *1, etc.
The standard devices of dongfeng 4*2 RHD road wrecker tow truck as below
1, 3 tons loading capacity for the upper part/flatbed
2, 4T hydraulic winch and 20m length wire rope
3, Retractable Rear Lift Arm (choose to install)
4, auxiliary wheels*1 set
5, bilateral linkage control valve
6, fully hydraulic flipping plates
7, yellow color alarm light
8, 4* special binding belts
If you're interested in our flatbed wrecker towing truck, please send email to truck0011@163.com or talk to Anita by Whatsapp: 0086 13329899995.
Website: www.trucksinchina.com
More pictures of Dongfeng 4*2 RHD 3tons flatbed type road repair removal vehicle is as below.
main technical parameters of dongfeng 4*2 RHD road towing truck as below
| Overall parameters |
Product name |
Dongfeng 4*2 RHD 3T flatbed wrecker tow truck |
| Manufacturer |
Chengli Special Automobile Co., Ltd. |
| Product model |
CLW5041TQZ3 |
| Total mass(kgs) |
4495 |
| Rated mass(kgs) |
|
| Curb mass(kgs) |
3600 |
| Overall dimension (L*W*H)(mm) |
5997×2300×2220 |
| Chassis parameters |
Driver cab |
dongfeng 4*2 LHD single row driver cab with 2 seats and original air conditioner |
| Approach/departure angle(°) |
20/13 |
| Front/rear suspension(mm) |
1040/1649 |
| Axles nos. |
2 |
| Wheelbase(mm) |
3300 |
| Axle load(kgs) |
1800/2695 |
| Max speed(km/h) |
99 |
| Tire specification |
7.00-16 8PR*6 |
| Steel spring |
6/6+5 |
| Front/rear tread(mm) |
1505/1493 |
| Engine model |
CY4100Q |
| Fuel type |
Diesel |
| Emission standard |
Euro Ⅲ/Ⅳ/Ⅴ |
| Gearbox |
5 speed gearbox, manual |
| Upper part parameters |
Flatbed dimension(L*W)(mm) |
4200*2300 |
| Rear hydraulic flapping plate Length (mm) |
1000 |
| Total flatbed length (mm) |
4200+1000 |
| Hydraulic winch |
4tons |
| Operation way |
Bilateral linkage operation |
| Retractable Rear Lift Arm |
Choose to install |
| |
Loading capacity of the flatbed |
3tons |
| |
Wire rope |
20m length |
| |
Auxiliary wheels |
1 sets |
| |
Special binding belts |
4 sets |
| |
Yellow color alarm light |
Yes |
1, Bilateral Linkage
Winch, rear lift arm and flat plate can all be operated in one-key. Both sides of the body can be operated conveniently and quickly, saving time and effort.
2,Retractable Rear Lift Arm
Accord to the chassis to choose different tonnage rear arm, can be optional to telescopic type arm, can pull different size of the fault vehicle.
3,Hydraulic Winch
Accord to the chassis to choose 4-6 tons winch, optional 21m and 25m steel wire rope. Hydraulic transmission, with overload protection, impact protection and explosion protection properties.
4, Auxiliary Wheel
The vehicle is equipped with two auxiliary wheels, which can assist in pulling the broken vehicle onto the wrecker when the wheels of the vehicle cannot move
5,
5, Anti-stripping Hook
The end of the wire rope is equipped with anti-stripping hook, which is more safe and reliable when using, and the wrecker is equipped with four binders.
6, Front Baffle
A baffle is set on both sides of the front end of the flatbed to effectively prevent the vehicle from moving forward, which is more stable and safer.
