HOT SALE! SINO TRUK HOWO 4*2 LHD 4T-5T wrecker towing truck with crane boom for sale,Small Car Towing Emergency Rescue wheel lift Wrecker Tow Truck
Wrecker towing truck is used for pulling the broken car,truck, bus or trailer, etc on highway and city road, suburb way ,airport, etc. It is made of chassis, hoisting equipment, lifting and towing equipment, hydraulic system, electric control system, truck body and the tool boxes. It combine the hoisting, lifting, towing functionm, etc. More information, please feel free to contact with Ms. Anita.
CLW brand wrekcer towing truck consists of the truck chassis, hoisting equipment, truck tow hook, tow truck winch, tow truck wheel lift, hydraulic system, electric control system, truck body and the tool boxes. The tow truck can hoist, lift, draw, and be with other special functions, mainly used in highway, garage and city road obstacle cleaning.
As a professional road rescue truck supplier in China, we Chengli tow trucks can meet all your demand. Right hand wrecker tow trucks, left hand drive wrecker tow trucks, 4x2 wreckers, 4x4 wrecker truck, 6x4 wreckers, 8x4 tow wrecker trucks,etc. In wrecker truck types, we produce flatbed tow truck, under lift wrecker truck, rotator tow truck, full landing wrecker tow truck, etc. More information, please call +86 13329899995.
SINO TRUK HOWO 4*2 LHD 4T-5T wrecker towing truck adopts SINO TRUK HOWO 2080mm width one row and a half driver cab, 4500mm wheelbase, YC4E160-33 160hp diesel Euro 3 engine, 6 speed manual gearbox, 3.2tons front axle/8tons rear axle, 8.25R20 rail tires, power steering+ air cut braking, etc.
The length of the flatbed for the SINO TRUK HOWO wrecker tow truck is 5400mm; while the width of the flatbed is 2300m. Choose to install 4T telescopic/knuckle crane boom.
The standard devices of SINO TURK HOWO 4T-5T road wrecker tow truck with crane boom is as below
1,4T-5T tons loading capacity for the upper part/flatbed
2, 4T hydraulic winch and 20m length wire rope
3, 2.5tons loading capacity of Retractable Rear Lift Arm (choose to install)
4, auxiliary wheels*1 sets
5, yellow color alarm light
6, special binding belts*4sets
7, 4T telescopic/knuckle crane boom
8, Bilateral linkage operation
If you're interested in our wrecker truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
More picures of HOWO 5T wrecker towing truck with knuckle crane boom is as below.
HOT SALE!SINO TRUK HOWO 4*2 LHD 4T-5T wrecker towing truck with knuckle crane boom
Main technical parameters of SINO TRUK HOWO 4*2 LHD 4T-5T wrecker towing truck is as below.
| Overall parameters |
Product name |
SINO TRUK HOWO 4T-5T flatbed wrecker tow truck with crane for sale |
| Manufacturer |
Chengli Special Automobile Co., Ltd. |
| Product model |
CL5123TQZ3YJ |
| Total mass(kgs) |
11995 |
| Rated mass(kgs) |
|
| Curb mass(kgs) |
8900 |
| Overall dimension (L*W*H)(mm) |
8590×2550×3230 |
| Chassis parameters |
Driver cab |
SINO TRUK HOWO 2080mm width one row and a half driver cab |
| Approach/departure angle(°) |
18/11 |
| Front/rear suspension(mm) |
1180/2670 |
| Axles nos. |
2 |
| Wheelbase(mm) |
4500 |
| Axle load(kgs) |
4285/7710 |
| Max speed(km/h) |
95 |
| Tire specification |
8.25R20*6 |
| Steel spring |
8/9+6 |
| Front/rear tread(mm) |
1776/1555 |
| Engine model |
YC4E160-33 |
| Fuel type |
Diesel |
| Emission standard |
Euro Ⅲ |
| Gearbox |
6 speed gearbox, manual |
|
Upper part parameters
|
Flatbed dimension(L*W)(mm) |
5400*2300 |
| Hydraulic winch |
4tons |
| Operation way |
Bilateral linkage operation |
| Loading capacity of the flatbed |
4T-5tons |
| Wire rope |
20m length |
| Special binding belts |
4 sets |
| Yellow color alarm light |
Yes |
| auxiliary wheels |
1set |
| Retractable Rear Lift Arm |
2.5T loading capacity(choose to install) |
| Crane boom |
Choose to install 4tons telescopic/knucle crane boom |
1, Bilateral Linkage
Winch, rear lift arm and flat plate can all be operated in one-key. Both sides of the body can be operated conveniently and quickly, saving time and effort.
2,Retractable Rear Lift Arm
Accord to the chassis to choose different tonnage rear arm, can be optional to telescopic type arm, can pull different size of the fault vehicle.
3,Hydraulic Winch
Accord to the chassis to choose 4-6 tons winch, optional 21m and 25m steel wire rope. Hydraulic transmission, with overload protection, impact protection and explosion protection properties.
4, Auxiliary Wheel
The vehicle is equipped with two auxiliary wheels, which can assist in pulling the broken vehicle onto the wrecker when the wheels of the vehicle cannot move
5,
5, Anti-stripping Hook
The end of the wire rope is equipped with anti-stripping hook, which is more safe and reliable when using, and the wrecker is equipped with four binders.
6, Front Baffle
A baffle is set on both sides of the front end of the flatbed to effectively prevent the vehicle from moving forward, which is more stable and safer.
