IVECO YUEJIN truck mounted road sweeper for sale, CHINESE IVECO 1500 liters water tank and 4000 liters garbage tank street sweeper truck
Compared with common road sweeper, this model has more functions:Road sweeping, road flushing, multi-angle slush flushing, separation zone cleaning, freeway guard rail flushing,spraying, moistening and dust containing, high pressure water gun for car cleaning/low flat flushing with strong water flow, road sprinkling and flower watering from both sides and so on.
1.The Vice-engine sweepers no. Fans and other work devices to take power through the chassis engine to drive.
2. Cleaning device with Automatic Collision Avoidance Obstacle protection and automatic reset function (by national patent)
3. “Mid four brush - rear nozzle” structure layout with sweeping wide, clean and efficient features, and facilitate the cleaning device and nozzle adjustment and maintenance.
4.Pneumatic conveying system with digestion and absorption of foreign advanced technology and efficient sweepers dedicated fans and can auto-leveling with the road the whole floating nozzle.
5.Sweeper combined with trochar disc, it can work excellently and can automotically choose work type according to waste condition on the ground and speed of the truck. ;
6.Trash and water tank large, continuous cleaning operation a long time.
7. Left, right front linkage scan can work independently or can choose to use the right front or left front sweep sweep to work independently.
8.Hydraulic system with superimposed solenoid hydraulic valve, highly integrated, reliable, easy maintenance;
9. Control switch installed in the driver focused interior, all electronic control can be found in cab ,Beautiful appearance designed via computer.
If you're interested in our sweeper truck, please feel free to send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995
Website: www.trucksinchina.com
More pictures of hot sale IVECO YUEJIN road sweeper truck as below.
More information, please feel free to contact with Ms. Anita Deng.
Whatsapp/wechat: +86 13329899995
Skype: truck0011
QQ: 504873236
1,SPECIFICATION of IVECO Yuejin brand street sweeper trucks manufactured by Chengli Special Automobile Co., Ltd. as below
|
Upper-Body specification
|
|
Vice generator
|
|
Model
|
JX493-G3
|
|
Rated power (kw)
|
57
|
|
Suction sweep operation
|
|
Cleaning efficiency
|
≥95%
|
|
The maximum diameter of the suction body(mm)
|
120
|
|
Suction sweep width(mm)
|
2.8-3.2
|
|
Maximum cleaning power (m2/h)
|
60000
|
|
Butterfly dish brush overhang dimension(mm)
|
≥400
|
|
Working speed (km/h)
|
3-20
|
|
Water tank body
|
|
Rated capacity (m3)
|
1.0-1.5
|
|
Garbage tank body
|
|
|
Rated capacity(m3)
|
3.5-4
|
|
Discharge door opening angle
|
≥45º
|
|
Hydraulic system
|
|
Model
|
Open, electrical control
|
|
The main element
|
Gear pumps, hydraulic motors, hydraulic cylinders, solenoid valve
|
|
Pressure (mpa)
|
16
|
|
Hydraulic oil tank capacity (l)
|
60
|
|
Hydraulic oil temperature (ºC)
|
60
|
|
Electrical system
|
|
Model
|
DC24V
|
|
voltage
|
24V
|
|
Battery
|
24V(2 set 12 v battery series connection )
|
|
Sprinkle system
|
|
The main elements
|
Electric diaphragm pump, water filters, nozzles, etc.
|
|
Sweeper disk device
|
|
Model
|
Center four sweeper disk, controlled by a hydraulic motor, front right can be independently controlled with avoidance and reset function
|
|
Diameter (mm)
|
850
|
|
Angel
|
Forward 4-6º roll 4-7º
|
|
Sucker device
|
|
Model
|
Single suction port, hydraulically controlled, spring suspension.
|
|
Diameter (mm)
|
200
|
