high quality and best price JAC brand Vacuum sweeper truck with snow removal for sale, factory sale JAC Small diesel sweeping suction truck
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of sweeper truck in China. With many years' development, Chengli Special Automobile Co., Ltd could supply dongfeng sweeper truck, ISUZU sweeper truck, Forland road cleaning truck, JMC road sweeper truck, FAW street sweeper, etc. More information, please feel free to contact with Ms. Anita Deng.
If you're interested in our sweeper truck, please feel free to send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mo.b: +86 13329899995
Website: www.trucksinchina.com
More pictures of hot sale JAC vacuum sweeping truck with snow removal manufactured by Chengli Special Automobile Co., Ltd. as below.
JAC Brand road sweeping vacuum truck with snow removal for sale
best price JAC brand vacuum sweeper truck with snowplow for sale
More information, please feel free to contact with Ms. Anita.
Whatsapp/wechat: +86 13329899995
Skype: truck0011
QQ: 504873236
Compared with common road sweeper, this model has more functions:Road sweeping, road flushing, multi-angle slush flushing, separation zone cleaning, freeway guard rail flushing,spraying, moistening and dust containing, high pressure water gun for car cleaning/low flat flushing with strong water flow, road sprinkling and flower watering from both sides and so on.
1.The Vice-engine sweepers no. Fans and other work devices to take power through the chassis engine to drive.
2. Cleaning device with Automatic Collision Avoidance Obstacle protection and automatic reset function (by national patent)
3. “Mid four brush - rear nozzle” structure layout with sweeping wide, clean and efficient features, and facilitate the cleaning device and nozzle adjustment and maintenance.
4.Pneumatic conveying system with digestion and absorption of foreign advanced technology and efficient sweepers dedicated fans and can auto-leveling with the road the whole floating nozzle.
5.Sweeper combined with trochar disc, it can work excellently and can automotically choose work type according to waste condition on the ground and speed of the truck. ;
6.Trash and water tank large, continuous cleaning operation a long time.
7. Left, right front linkage scan can work independently or can choose to use the right front or left front sweep sweep to work independently.
8.Hydraulic system with superimposed solenoid hydraulic valve, highly integrated, reliable, easy maintenance;
9. Control switch installed in the driver focused interior, all electronic control can be found in cab ,Beautiful appearance designed via computer
main parameters of hot sale JAC vacuum sweeping truck with snowplow manufactured by Chengli Special Automobile Co., Ltd. as below.
| Vehicle Description |
| Vehicle model |
Vacuum Sweeper truck for sale |
Overall dimensions (mm) |
5900*2270*2250 |
| GVW (kg) |
Appro×7000 |
Fact Loading Capacity(kg) |
4000 |
| Mass in working order (kg) |
Appro×5150 |
Max. Speed (km/h) |
100 |
| Chassis Description |
| Chassis Model |
HFC1073P83K1C3 |
| Cab |
Standard cabin with Left hand drive |
| Color |
Optional |
| Allowable person in cab |
2/3 |
| Wheel base (mm) |
3360 |
| Front/Rear track base (mm) |
1850/1806 |
| Front/Rear overhang (mm) |
1230/2150 |
| Number of axles |
2 |
| Axle |
Front axle |
3000 |
| Rear axle |
5000 |
| Traction system |
4*2 |
| Operation control system |
Power steering |
| Braking system |
Full air |
| Electric system |
24V |
| Transmission |
5speed |
| Spring plate |
8/13 |
| Tire specification |
7.00R16 14PR |
| Tire quantity |
6+1 |
| Engine Description |
| Engine model |
HFC4DA1-2C |
| Emission standard |
Euro 2 |
| Exhaust/output |
2771ml/88kw |
| Horse power |
130hp |
| Up-parts Description |
| Sweeping Width (mm) |
2400-3000 |
| Garbage Tank Volume(L) |
6000 |
| Working Speed(km/h) |
10~40 |
| Maximum Working Area(m2/h) |
40000 |
| Maxiumu Suction Size(mm) |
≥40 |
| Sweeping Efficiency |
≥95% |
| Working Condition: |
1,Altitude: 0-4500m
2,Temperature: -350C~+450C
3,Relative humidity: 80%
4,Wind force: ≤8 degree
5, choose to install snowplow to remove snow
|
