Japan brand ISUZU 190hp diesel street sweeper truck for sale, high quality and best price ISUZU brand road sweeping vehicle for export
1,garbage sump size is high , In order to facilitate the rubbish easy, the water tank is arranged in the garbage box bottom, such that the maximum discharge angles up to 54degrees above, makes the garbage dumping more thoroughly.
2, The hydraulic valve group with well-known domestic brand leader, test pressure can reach35MPa,flow rate up to 300L/Min, can be of various industrial valves and hydraulic walking hydraulic valve dynamic, static and fatigue life of precision testing.
3, The auxiliary machine air filter intake system design , which can greatly improve the service life of the engine:Engine air intake quality will directly affect the service life of the engine, the engine inlet air filtration is not good,light can make the power of the engine is reduced, burning oil, heavy can make the engine cylinder liner and pistonscrapped, so my company in order to maximize the engine's intake quality, not only will the engine air intake to thetop of the box, is still the original air filter front-end increase an oil bath type filtering device, used to bond the gas flow in the fine dust, so that the engine air cleaner.
If you're interested our road sweeper truck, please feel free to send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995
Website: www.trucksinchina.com
4, Hydraulic system filter using well-known products, so that the hydraulic system to keep high cleanliness, uses the original hydraulic oil cooling technology, compared with similar products, the temperature dropped 10 degrees, prolongs the service life of hydraulic oil, hydraulic system with automatic overload protection device, fully guarantee the safe use of hydraulic system.
5,Cleaning brush made by quality hydraulic motor ,high working effect ,and long life.
6,Cleaning device with automatic obstacle avoidance, protection or automatic reset function, brush adopts a spring suspension obstacle avoidance structure, prevent brush obstacle was damaged in may.
7,The truck's pumping sucker adopts a fully floating connecting structure, can fully guarantee the cleaning operation,chuck can be based on road conditions, follow-up, to ensure that the sucker and the road clearance remains constant. Posterior sucker walking mechanism is advanced, encountering small deceleration strip easily cross.
8, The left and right front brush disc can be independent or linked, so that the vehicle in work can selectively use rightor left anterior sweep sweep before working on the side of the highway, make the working mechanism in the choice of the left and the condition of out body not only reduces the width of Zhandao, improve the operating and traffic safety, and reduce the brush wear, reduce running cost.
9,the original hand pump emergency lifting system, in the side of engine trouble, unable to start the engine, the garbage box rises, in order to facilitate the repair personnel to repair.
10, a variety of configuration, multiple choice: to make the vehicle truly make a multi-purpose vehicle, the vehicle can also be based on user needs, choose the snow shovel device assembly.
The main tehnical parameters of ISUZU road sweeper truck as below
| Product name |
ISUZU road sweeper truck for sale |
| Overall dimension(mm) |
5750×1980×2500(Euro Ⅳ)
6190×1990×2590(Euro Ⅴ) |
Total mass(Kg) |
6435
7300 |
| Cargo body dimension (mm) |
×× |
Rated mass(Kg) |
1675
2240 |
| Approach/departure angle |
24/13 |
Curb mass(Kg) |
4630
4930 |
| Front/rear suspension (mm) |
1015/1325 |
Max speed (km/h) |
105/110 |
| Truck chassis |
QL1060A1HAY QL1070A5HAY |
| Engine model |
Manufacturer |
Displacement |
Power |
| 4KH1-TC |
ISUZU company |
2999 ml |
88kw 120hp/96kw 130hp |
| Fuel type |
Diesel |
Emission standard |
Euro Ⅳ/ Ⅴ emission standard |
| Axle nos. |
2 |
Tyre nos. |
6+1 |
| Wheelbase |
3360 |
Tyre specification |
7.00-16 14PR,7.00R16 14PR |
| Axle load |
2580/4720 |
Front tread |
1504 |
| Steel spring |
8/6+5 |
Rear tread |
1425 |
More pictures of hot sale ISUZU 700P 190hp Euro 4 road sweeper truck as below
best price ISUZU 700P road sweeper truck for sale
Japan brand ISUZU 190hp diesel street sweeper truck for sale
ISUZU 700P street sweeper adoopts ISUZU 700P original truck chassis, 4175mm wheelbase, ISUZU 4HK1-TCG40 190hp Euro 4 diesel engine, ISUZU MLD 6 speed transmission, air-condtioner with power steering, 4ton front axle/7ton rear axle, 825-16 tyre, oil braking with vacuum booster pump, etc.
ISUZU road cleaning vehicle adopts middle 4pcs cleaning brushs,and rear installate suction mouth,so the truck cleaning effect is good ,and the truck water tanker and garbage box made by SS340 stainless steel ; Garbage box and the water tank is an integral structure, water tank in the dustbin garbage box bottom plate bottom pretilt angle up to 12°, easy to dump clean. Garbage box is arranged on the top of the guide groove and a larger area of the filtering net, can fully improve the efficiency of dust removal, so that garbage piles evenly, increase effective capacity, reduced due to a blocked filter and the air resistance.
And the volume of ISUZU road sweeper truck is 9cbm, That is 3cubic meters water tanker and 6 cubic meters wastes box, etc.
