Best price Standard type asphalt spreading tanker vehicle for sale, hot sale! new 6cbm 5tons bitumen tanker truck
The bitumen distribution truck for sale are consisted with truck chassis, insulated asphalt tank, heater, hydraulic system, conducting oil pipeline, asphalt pump, spray nozzle, etc. The tank volume is from 3m3 to 18m3. The spray nozzle quantity is from 30 to 48 nos.
The liquid bitumen sprayer truck is mainly used to transport asphalt and distribut it for sealing the road.
Our asphalt distributor dopt advanced technology and foreign imported parts. It has more advantages than other asphalt suppliers.
Our asphalt sparyer truck for sale adopt special chassis and Italy imported burner. It has many advantages.
If you're interested in our asphalt tanker truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995
Website: www.trucksinchina.com
More pictures of Dongfeng 6cbm 5tons asphalt spreading tanker truck as below.
The devices of standard type dongfeng brand 6cbm asphalt distributing vehicle manufactured by Chengli Special Automobile Co., Ltd. as below.
1, the asphalt pump adopts high quality QGB450 (high viscosity asphalt pump, 450L/min).
2, hydraulic system: Manual reversing valve; the model of hydraulic motor for asphalt pump: 05-110-BD31; hydraulic pump model: CBQ550-L
3, asphalt distributing width: 4.5m; 39 sets asphalt spraying nozzles for 6m spreading width is selective( 8,000RMB additional).
4, control way: controlled by the operation box at the rear working platform 34 sets pneumatic nozzles (one control one).
5, Heating method: Burner (Italy imported Riello brand burner model G10)+ Automatic heating of heat transfer oil
6, gasoline generator unit: 6KW gasoline generator unit.
Distributing medium: emulsified asphalt, hot asphalt, SBS hot asphalt, etc.
Main technical parameter of Dongfeng asphalt spreading tanker truck manufactured by Chengli Special Automobile CO., Ltd. as below.
| Main technical parameters |
| Product name |
CLW5100GLQ3 6cbm asphalt spreading vehicle for sale
|
| Total mass(Kg) |
9750 |
Tanker volume (m3) |
6 |
| Rated mass(Kg) |
3955 |
Overall dimension(L*W*H)(mm) |
7080×2300×2650 |
| Curb mass(Kg) |
5600 |
Driver cab seated person |
3 |
| Approach/departure angle(°) |
22/10 |
Front/rear suspension(mm) |
1180/2100 |
| Axle nos. |
2 |
wheelbase(mm) |
3800 |
| Axle load(Kg) |
3400/6350 |
Max speed(Km/h) |
80 |
| Chassis main parameters |
| Truck chassis model |
EQ1110T9ADJ3AC |
Manufacturer |
Dongfeng |
| Approach/departure angle(°) |
22/13 |
Tire specification |
7.50R16*6 |
| Steel spring |
11/9+7 |
tread(mm) |
1831 |
| Fuel type |
Diesel |
Rear tread(mm) |
1640 |
| Emission standard |
Euro Ⅲ |
| Engine model |
Manufacturer |
displacement(ml) |
power(Kw) |
|
CY4102-E3C
YC4FA120-33
|
Chaocahi
YUchai
|
3856
2982
|
88
88
|
