customized Dongfeng D9 4*2 LHD 210hp diesel Euro 6 10cbm asphalt spreading tanker truck for sale, bitumen distributing tanker truck for sale
The bitumen distribution truck for sale are consisted with truck chassis, insulated asphalt tank, heater, hydraulic system, conducting oil pipeline, asphalt pump, spray nozzle, etc. The tank volume is from 3m3 to 18m3. The spray nozzle quantity is from 30 to 48 nos.
The liquid bitumen sprayer truck is mainly used to transport asphalt and distribut it for sealing the road.
Asphalt distributor is a kind of pavement construction machinery; it is a highway, urban road, airport and port construction of major equipment.It can be used to transport and makes liquid asphalt (including hot asphalt, emulsified asphalt and residue) . The bitumen distributor truck are consisted with truck chassis, insulated asphalt tank, heater, hydraulic system, conducting oil pipeline, asphalt pump, spray nozzle, etc. The tank volume is from 3m3 to 18m3. The spray nozzle quantity is from 30 to 48.
The emulsified asphalt distributor truck is also called asphalt paver, asphalt sprayer truck, bitumen sprayer truck, asphalt distributor truck, asphalt bitumen tank truck, road sealer truck, asphalt truck, etc. The liquid bitumen sprayer truck is mainly used to transport asphalt and distribut it for sealing the road.
The asphalt distributor trucks manufactured by Chengli Special Automobile Co., Ltd. adopt advanced technology and foreign imported parts. It has more advantages than other asphalt suppliers.Our asphalt sparyer truck for sale adopt special chassis and Italy imported burner. It has many advantages.
If you're interested in our bitumen spreading truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
More pictures of dongfeng D9 210hp Euro 6 diesel 10cbm 8tons asphalt spreading tanker truck as below.
HOT SALE! Dongfeng D9 10cbm bitumen distributing tanker truck FOR SALE
Dongfeng D9 10cbm bitumen distributing tanker truck, adopts dongfeng D9 2135mm one row and a half luxurious driver cab, 4500mm wheelbase, B6.2NS6B210 Cummins 210hp Euro Ⅵ diesel engine, 295/80R22.5 tires, 4.5t front axle/10t rear axle, DT0690 dongfeng 6 speed manual gearbox, air conditioner, ABS, Electric doors and windows, central control lock, air brake, exhaust brake, etc.
The devices of dongfeng D9 10cbm asphalt tanker truck manufactured by Chengli Special Automobile Co., Ltd. is as below.
1, the asphalt pump adopts high quality QGB950 (high viscosity asphalt pump, 950L/min).
2, hydraulic system: Proportional valve (Taiwan EFBG-03-160-HF); Automatic reversing valve and overflow valve; radiator adopts Risheng brand; the model of hydraulic motor for asphalt pump: 05-110-BD31; hydraulic pump model: CBQ550-L or Power take off after engine GPC4-50R.
3, control way: Intelligent touch screen computer control at the driver cab; control system: (Siemens, Germany), 36 sets intelligent asphalt spraying nozzles (one controls one).
4, Heating method: Burner (Italy imported Riello brand burner model G20) + Automatic heating of heat transfer oil
5, gasoline generator unit: 6KW
6, spreading amount: 0.25-3.5L/㎡;
7, asphalt distributing width: 4.5m, 48 sets spraying nozzles for 6m spreading width is selective (10000RMB additional).
8, Distributing medium: emulsified asphalt, hot asphalt, SBS hot asphalt, etc.
Main technical parameters of dongfeng D9 10cbm asphalt tanker spreading vehicle manufactured by Chengli Special Automobile Co., Ltd. is as below.
| Main technical parameters |
| Product name |
CLW5180GLQ6 asphalt spreading vehicle for sale |
| Total mass(Kg) |
18000 |
Tanker volume(m3) |
10.0 |
| Rated mass(Kg) |
8690,8625 |
Overall dimension(L*W*H)(mm) |
8160×2500×3060 |
| Curb mass(Kg) |
9180 |
Driver cab seated person |
2,3 |
| Approach/departure angle(°) |
19/15 |
Front/rear suspension(mm) |
1260/2400 |
| Axle no. |
2 |
wheelbase(mm) |
4500 |
| Axle load(Kg) |
6500/11500 |
Max speed(Km/h) |
105 |
| Chassis main technical parameters |
| Chassis model |
EQ1185LJ9CDE |
Manufacturer |
Dongfeng company |
| Approach/departure angle(°) |
19/13,19/17 |
Tire specification |
10.00R20 18PR, |
| Steel spring |
8/10+7, |
Front tread(mm) |
1933, |
| Fuel type |
Diesel |
Rear tread(mm) |
1865 |
| Emission standard |
Euro Ⅲ |
| Engine model |
Manufacturer |
Displacement (ml) |
Power(Kw) |
| ISD180-43 |
Cummins |
4500 |
132 |
